Maytag MDG-75 Administrator Guide

Part No. 113065

MDG-75

Installation/Operator's Manual

For replacement parts, contact the distributor from which the dryer

was purchased or

MAYTAG

403 West Fourth Street North

Newton, Iowa 50208

(515) 792-7000

111898JEV/mt

WARNING: For your safety the

information in this manual must be

followed to minimize the risk of fire or

explosion or to prevent property damage,

personal injury or death.

Do not store or use gasoline or other flammable

vapor and liquids in the vicinity of this or any

other appliance.

WHAT DO YOU DO IF YOU SMELLGAS

* Do not try to light any appliance.

* Do not touch any electrical switch; do not use

any phone in your building.

* Clear the room, building or area of all

occupants.

* Immediately call your gas supplier from a

neighbor's phone. Follow the gas supplier's

instructions.

* If you cannot reach your gas supplier, call the

fire department.

Installation and service must be performed by a

qualified installer, service agency or the gas

supplier.

AVERTISSEMENT: Assurez-vous de bien

suivre les instructions données dans cette

notice pour réduire au minimum le risque

dincendie ou dexplosion ou pour éviter tout

dommage matériel, toute blessure ou la mort.

Ne pas entreposer ni utiliser dessence ni

dautres vapeurs ou liquides inflammables dans

le voisinage de cet appareil ou de tout autre

appareil.

QUE FAIRE SI VOUS SENTEZ UNE ODEUR

DE GAZ:

* Ne pas tenter dallumer dappareil.

* Ne touchez à aucun interrupteur. Ne pas

vous servir des téléphones se trouvant dans

le bâtiment où vous vous trouvez..

* Évacuez la pièce, le bâtiment ou la zone.

* Appelez immédiatement votre fournisseur de

gaz depuis un voisin. Suivez les instructions

du fournisseur.

* Si vous ne pouvez rejoindre le fournisseur

de gaz, appelez le service des incendies.

Linstallation et lentretien doivent être assurés

par un installateur ou un service dentretien

qualifié ou par le fournisseur de gaz.

Retain This Manual In A Safe Place For Future Reference

For replacement parts, contact the distributor from which the dryer was purchased or contact:

MAYTAG

403 West Fourth Street North

Newton, Iowa 50208

(515) 792-7000

The illustrations on the following pages may not depict your particular dryer exactly. The illustrations are a composite of the

various dryer models. Be sure to check the descriptions of the parts thoroughly before ordering.

DATE OF PURCHASE MODEL NO.

DISTRIBUTORS NAME

Serial Number(s)

IMPORTANT NOTE TO PURCHASER

Information must be obtained from your local gas supplier on the instructions

to be followed if the user smells gas. These instructions must be posted in a

prominent location near the dryer.

Our products embody advanced concepts in engineering, design, and safety. If this product is properly maintained, it will

provide many years of safe, efficient, and trouble-free operation.

ONLY qualified technicians should service this equipment.

OBSERVE ALL SAFETY PRECAUTIONS displayed on the equipment or specified in the installation/operator's manual

included with the dryer.

The following FOR YOUR SAFETY caution must be posted near the dryer in a prominent location.

FOR YOUR SAFETY

Do not store or use gasoline or

other flammable vapors or liquids

in the vicinity of this or any other

appliance.

POUR VOTRE SÉCURITÉ

Ne pas entreposer ni utiliser dessence

ni dautres vapeurs ou liquides

inflammables dans le voisinage de cet

appareil ou de yout autre appareil.

We have tried to make this manual as complete as possible and hope you will find it useful. Manufacturer reserves the right

to make changes from time to time, without notice or obligation, in prices, specifications, colors, and material, and to change

or discontinue models.

Important

For your convenience, log the following information:

IMPORTANT

YOU MUST DISCONNECT and LOCKOUT THE ELECTRIC SUPPLYand THE GAS

SUPPLY BEFORE ANY COVERS or GUARDS ARE REMOVED FROM THE

MACHINE TOALLOWACCESS FOR CLEANING,ADJUSTING, INSTALLATION,

or TESTING OF ANY EQUIPMENT per OSHA (Occupational Safety and Health Adminis-

tration) STANDARDS.

CHILDREN SHOULD NOT BEALLOWED TO PLAYON OR NEAR THE DRYER(S).

WARNING

CHILDREN SHOULD BE SUPERVISED IF NEAR DRYER(S) IN OPERATION.

DRYER(S) SHOULD NEVER BE LEFT UNATTENDED WHILE IN OPERATION.

CAUTION

FOR YOUR SAFETY

DO NOT DRYMOP HEADS INTHE DRYER.

DO NOT USE DRYER IN THE PRESENCE OF DRYCLEANING FUMES.

WARNING

UNDER NO CIRCUMSTANCES should the door switch or the heat circuit devices

ever be disabled.

Caution: Label all wires prior to

disconnection when servicing controls. Wiring

errors can cause improper operation.

«Attention: Lor des opérations dentretien

des commandes étiqueter tous fils avant

de les déconnecter. Toute erreur de

câblage peut étre une source de danger et

de panne.»

WARNING

The dryer must never be operated with any of the back guards, outer tops, or service

panels removed. PERSONAL INJURY or FIRE COULD RESULT.

IMPORTANT

PLEASE OBSERVEALLSAFETY PRECAUTIONS displayed on the equipment and/or

specified in the installation/operator's manual included with the dryer.

Dryer(s) must not be installed or stored in an area where it will be exposed to water and/or

weather.

The wiring diagram for the dryer is located in the front electrical control box area.

DRYER MUST NEVER BE OPERATED WITHOUTTHE LINT FILTER/SCREEN IN

PLACE...EVEN IF AN EXTERNAL LINT COLLECTION SYSTEM IS USED.

WARNING

Dryer MUST NEVER BE operated without the Lint Filter/Screen in Place. Even if an

external lint collection system is used.

Table of Contents

SECTION I

IMPORTANT INFORMATION ............................................................................... 3

A. Receiving and Handling............................................................................................................ 3

B. Safety Precautions ..................................................................................................................... 4

SECTION II

SPECIFICATIONS .................................................................................................... 6

A. Specifications ............................................................................................................................ 6

B. Component Identification .......................................................................................................... 8

SECTION III

INSTALLATION REQUIREMENTS ................................................................... 10

A. Location Requirements ........................................................................................................... 10

B. Unpacking/Setting Up ............................................................................................................. 11

C. Dryer Enclosure Requirements................................................................................................12

D. Fresh Air Supply ..................................................................................................................... 13

E. Exhaust Requirements ............................................................................................................ 14

F. Electrical Information .............................................................................................................. 18

G. Gas Information......................................................................................................................... 24

H. Preparation For Operation/Start-up......................................................................................... 28

I. Preoperational Tests .................................................................................................................. 29

J. Preoperational Instructions ......................................................................................................... 31

K. Shut Down Instructions ............................................................................................................. 32

SECTION IV

SERVICE/PARTS INFORMATION ...................................................................... 33

A. Service ..................................................................................................................................... 33

B. Parts ......................................................................................................................................... 33

SECTION V

WARRANTY INFORMATION .............................................................................. 34

A. Returning Warranty Card(s) ...................................................................................................... 34

SECTION VI

ROUTINE MAINTENANCE .................................................................................. 35

A. Cleaning ................................................................................................................................... 35

B. Adjustments .............................................................................................................................. 37

SECTION VII

PROCEDURE FOR FUNCTIONAL CHECK OF REPLACEMENT

COMPONENTS ....................................................................................................... 38

SECTION VIII

REVERSING TIMER SPIN/DWELL ADJUSTMENTS .................................... 41

SECTION IX

TECHNICAL INFORMATION ....................................................................... 42, 43

Data Label ............................................................................................................................... 42, 43

SECTION X

TROUBLESHOOTING ............................................................................................44

Microprocessor (Computer) Models ............................................................................................... 44

Dual Timer Models ......................................................................................................................... 55

SECTION I

IMPORTANT INFORMATION

A. RECEIVING and HANDLING

The dryer is shipped in a protective stretch wrap cover with protective cardboard corners and top cover (or

optional box) as a means of preventing damage in transit. Upon delivery, the dryer and/or packaging, and wooden

skid should be visually inspected for shipping damage. If any damage whatsoever is noticed, inspect

further before delivering carrier leaves.

Dryers damaged in shipment.

1. ALL dryers should be inspected upon receipt and before they are signed for.

2. If there is suspected damage or actual damage, the trucker's receipt should be so noted.

3. If the dryer is damaged beyond repair, it should be refused. Those dryers which were not damaged in a

damaged shipment should be accepted, but the number received and the number refused must be noted

on the receipt.

4. If you determine that the dryer was damaged after the trucker has left your location, you should call the

delivering carrier's freight terminal immediately and file a claim. The freight company considers this

concealed damage. This type of freight claim is very difficult to get paid and becomes extremely difficult

when more than a day or two passes after the freight was delivered. It is your responsibility to file freight

claims. Dryer/parts damaged in transit cannot be claimed under warranty.

5. Freight claims are the responsibility of the consignee, and ALL claims must be filed at the receiving end.

Manufacturer assumes no responsibility for freight claims or damages.

6. If you need assistance in handling the situation, please contact the manufacturer Traffic Manager at (508)

678-9000.

IMPORTANT: The tumbler section of the dryer must be transported and handled in an upright

position at all times.

B. SAFETY PRECAUTIONS

WARNING: For your safety, the information in this manual must be followed to minimize the

risk of fire or explosion or to prevent property damage, personal injury, or loss of

life.

WARNING: The dryer must never be operated with any of the back guards, outer tops, or

service panels removed. PERSONAL INJURY or FIRE COULD RESULT.

1. DO NOT store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other

appliance.

2. Purchaser/user should consult the local gas supplier for proper instructions to be followed in the event the

user smells gas. The instructions should be posted in a prominent location.

3. WHAT TO DO IF YOU SMELL GAS..

a. DO NOT try to light any appliance.

b. DO NOT touch any electrical switch.

c. DO NOT use any phone in your building.

d. Clear the room, building, or area of ALL occupants.

e. Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's instructions.

f. If you cannot reach your gas supplier, call the fire department.

4. Installation and service must be performed by a qualified installer, service agency, or gas supplier.

5. Dryer(s) must be exhausted to the outdoors.

6. Although the manufacturer produces a very versatile machine, there are some articles that, due to fabric

composition or cleaning method, should not be dried in it.

WARNING: Dry only water-washed fabrics. DO NOT dry articles spotted or washed in dry

cleaning solvents, a combustible detergent, or "all purpose" cleaner.

EXPLOSION COULD RESULT.

WARNING:DO NOT dry rags or articles coated or contaminated with gasoline, kerosene, oil,

paint, wax.

EXPLOSION COULD RESULT.

WARNING:DO NOT dry mop heads. Contamination by wax or flammable solvents will create

a fire hazard.

WARNING:DO NOT use heat for drying articles that contain plastic, foam, sponge rubber, or

similarly textured rubber materials. Drying in a heated basket (tumbler) may

damage plastics or rubber and also may be a fire hazard.

7. A program should be established for the inspection and cleaning of lint in the heating unit area, exhaust

duct work, and inside the dryer. The frequency of inspection and cleaning can best be determined from

experience at each location.

WARNING: The collection of lint in the burner area and exhaust duct work can create a

potential fire hazard.

8. For personal safety, the dryer must be electrically grounded in accordance with local codes and/or the

National Electric Code ANSI/NFPA NO. 70-LATEST EDITION.

NOTE: Failure to do so will VOID THE WARRANTY.

9. UNDER NO CIRCUMSTANCES should the dryer door switches or heat safety circuit ever be disabled.

WARNING: PERSONAL INJURY or FIRE COULD RESULT.

10. This dryer is not to be used in the presence of dry cleaning solvents or fumes.

11. Remove articles from the dryer as soon as the drying cycle has been completed.

WARNING: Articles left in the dryer after the drying and cooling cycles have been completed

can create a fire hazard.

12. READ and FOLLOW ALL CAUTION and DIRECTION LABELS ATTACHED TO THE DRYER.

WARNING: YOU MUST DISCONNECT and LOCKOUT THE ELECTRIC SUPPLY and

THE GAS SUPPLY BEFORE ANY COVERS or GUARDS ARE REMOVED

FROM THE MACHINE TO ALLOW ACCESS FOR CLEANING,

ADJUSTING, INSTALLATION, or TESTING OF ANY EQUIPMENT per

OSHA (Occupational Safety and Health Administration) STANDARDS.

SECTION II

SPECIFICATIONS/COMPONENT IDENTIFICATION

A. SPECIFICATIONS

* For non-reversing models.

** A minimum of 3/4" pipe must be supplied to the gas inlet for each dryer.

NOTE: Manufacturer reserves the right to make changes in specifications at any time, without notice or

obligation.

0$;,080&$3,&,7<

'5< :(,*+

W OEV NJ

%$6.(7 ',$0(7(5  FP

%$6.(7 '(37+  FP

%$6.(702725 +3 NZ

'22523(1,1*'LDPHWHU  FP

%$6.(792/80( FXIW FXP

'5<(563(5&217$,1(5 

'5<(563(5758&. 

92/7$*($9$,/$%/( Y¡¡+]

$3352;:(,*+78QFUDWHG OEV NJ

$3352;:(,*+7&UDWHG OEV NJ

+($7,1387 EWXKU NFDOKU

$,5)/2: FIP FPP

,1/(73,3(6,=(  FP

6KDGHGDUHDVDUHLQPHWULFHTXLYDOHQWV

GAS

Other manuals for MDG-75

Table of contents

Other Maytag Dryer manuals

Maytag

Maytag MGDE300VF - Performance Series 27-in Gas... User manual

Maytag

Maytag MGD5700TQ1 User manual

Maytag

Maytag MGDC400VW - Centennial 29" Gas Dryer User manual

Maytag

Maytag MED5920TW0 User manual

Maytag

Maytag MDE18PD User manual

Maytag

Maytag MDG120PHVW User manual

Maytag

Maytag EPIC z MEDZ600T User manual

Maytag

Maytag MDE17MN User manual

Maytag

Maytag MGDX5SPAW0 User manual

Maytag

Maytag MED4200BW0 User manual

Maytag

Maytag MGDC700VW - Centennial Gas Dryer User manual

Maytag

Maytag MGDC300BW User manual

Maytag

Maytag MGDB955FC User manual

Maytag

Maytag MLG35PD User manual

Maytag

Maytag MD6200 User manual

Maytag

Maytag Bravos MEDX600XW0 User manual

Maytag

Maytag LD9824 User manual

Maytag

Maytag SD-5 User manual

Maytag

Maytag MLE24PN User manual

Maytag

Maytag Neptune MDE7550AGW User manual

Maytag

Maytag Centennial MEDC500 User manual

Maytag

Maytag MGDB835DW4 User manual

Maytag

Maytag ELECTRONIC DRYER User manual

Maytag

Maytag W10150608A User manual

Popular Dryer manuals by other brands

Bosch

Bosch WTA79200GB Installation and operating instructions

Amana

Amana W10233410A Use and care guide

Miele

Miele TWH 780 WP operating instructions

Asko

Asko T760 user guide

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Original instructions

Bosch

Bosch Logixx 10 WTB76556GB Instruction manual and installation instructions

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Operation and installation

Electrolux

Electrolux EW2H328R2 user manual

Beko

Beko DS8433RX1M user manual

Dawlance

Dawlance Spinner DS 6000 C owner's manual

Electrolux

Electrolux TP5080TW user manual

AEG

AEG TR838P4OB user manual

Indesit

Indesit IDV 75 instruction manual

Infiniton

Infiniton SD-DG85C manual

BOMANN

BOMANN WT 5019 instruction manual

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Installation

Asko

Asko T793C operating instructions

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer installation instructions
