MFSC 3000W-4000W CW Fiber Laser Series
Copyright Notation
Copyright © Maxphotonics Co., Ltd (hereafter referred to as
Maxphotonics). All rights reserved. You may not copy, modify, transmit or
publish this publication, in any form, in any media or by any means, without
the prior written permission of Maxphotonics, except as allowed under
applicable copyright laws. Permitted copies shall bear the same copyright
and proprietary notices that were contained on the original version.
Maxphotonics believes that the information provided is accurate and
reliable; however Maxphotonics makes no warranty, representation,
expression or implication that this document can be used as reference
in other occasions. Furthermore, Maxphotonics does not assume
responsibility for any infringement of patents or other rights of third parties
due to use of the information contained in this document. Maxphotonics
shall not be liable for errors contained in this document or for direct or
indirect damages of relevant equipment.
Maxphotonics and the Maxphotonics Logo are registered trademarks of
Maxphotonics Co., Ltd., and the Logo does not break any regulations
of Trademark law.Maxphotonics grants no rights for patent or other
intellectual property mentioned herein.
All information contained in this document is subject to change and
revision without notice.
Subject to change without notice.
Maxphotonics Co.,Ltd.
Address: Maxphotonics Industrial Park, 3rd Furong Road,
Furong Industrial Area, Shajing, Baoan, Shenzhen, China.518125
E-Mail: [email protected]
http://en.maxphotonics.com
1
Preface
Thank you for using the MFMC Series CW fiber laser from Maxphotonics.
We compile this document for you in order that the laser is used and
maintained properly. Due to the limited level of the writers, coupled with
time constraints, there are some careless mistakes in this document, your
understanding and suggestion to help us make an improvement will be
much appreciated . Thank you again for using Maxphotonics' products.
Please take time to read and understand this User's Guide and familiarize
yourself with the operating and maintenance instructions before you use
the product. We strongly recommend that the operator read the Section 2
titled “Safety Information” prior to operating the product.
This User's Guide should stay with the product to provide you and all future
users and owners of the product with important operating, safety and other
information.
We identify the parts to which you need to pay special attention in the
document with underscore. Please notice those information to prevent the
unnecessary damages.
2
Company Profile
As a large laser manufacturer founded in 2004, Maxphotonics Co., Ltd.
specializes in research and development, production and sales of lasers
and ancillary products. Maxphotonics owns a number of independent
intellectual property rights and patents as well as high-power pulsed fiber
laser, high-power fiber laser and high-power fiber amplifier etc.
So far, with intellectual property rights and patents, Maxphotonics owns
industrial pulsed fiber laser series, CW fiber laser series,QCW laser
series,fiber laser for scientific researches, tunable fiber laser, fiber
amplifier, ASE light source, etc. Those products are widely applied to fields
of laser marking, 3D print，DTS system and scientific research.
Maxphotonics offers laser, relevant solution and ancillary facility to
domestic and foreign customers. We adhere to the enterprise mission
statement of ''Maxphotonics leads the industry'', take customer satisfaction
as the start point, completely implement ISO9001 quality management
system, introduce ERP information management system and provide all-
round pre-sales and after-sales service for customers.
Relying on excellent ability of product design and development, we carry
out all-round exchanges and cooperation with international famous
laser companies and various research institutions of China, continuously
increase the investment of science research, constantly update
diversification of production types, lead the trend of the industry and create
maximum value for customers, so as to strive perseveringly for the world-
class laser manufactures and forge ahead.
More informations，please visit our website：
http://en.maxphotonics.com
CONTENT 3
Company Profile ……………………………………………………………… 2
Chapter 1 Characteristic Description ………………………………… 5
Chapter 2 General Safety Information ……………………………… 6
1-Safety Conventions ………………………………………………………… 6
2-Laser Protection …………………………………………………………… 7
3-Reference Standard ……………………………………………………… 8
4-General Safety Instructions ……………………………………………… 9
5-Additional Safety Information …………………………………………… 14
Chapter 3 Product Description ………………………………………… 15
1-Features ……………………………………………………………………… 15
2-Module Configuration ……………………………………………………… 15
3-Laser Model Designation Codes ……………………………………… 15
4-Certification ………………………………………………………………… 16
5-Front Panel Description …………………………………………………… 16
6-Back Panel Description …………………………………………………… 17
7-Optical Output Terminal …………………………………………………… 17
Chapter 4 Specification …………………………………………………… 18
1-Optical Characteristic Parameters ……………………………………… 18
2-General Characteristic Parameters …………………………………… 19
3-Water Cooling Condition ………………………………………………… 20
4-Structural Layout …………………………………………………………… 21
CONTENT
4
Chapter 5 Unpacking Guide ……………………………………………… 22
1-Unpacking Steps …………………………………………………………… 22
2-Packing List ………………………………………………………………… 24
Chapter 6 Operation Guide ……………………………………………… 25
1-Notice ………………………………………………………………………… 25
2-Electrical Power Connection …………………………………………… 25
3-Extension Interface ………………………………………………………… 25
4-Start Steps …………………………………………………………………… 27
5-Mode Description …………………………………………………………… 27
6-Monitor Software …………………………………………………………… 28
7-Error List ……………………………………………………………………… 28
Chapter 7
Fiber Connector Inspection and Cleaning Guide
…… 30
1-Notice ………………………………………………………………………… 30
2-Operating Procedures …………………………………………………… 31
Chapter 8 Service and Maintenance ………………………………… 35
1-Maintenance Notes ………………………………………………………… 35
2-Service Statements ………………………………………………………… 36
Chapter 9 Warranty Statements………………………………………… 37
1-General Items ……………………………………………………………… 37
2-Warranty Limitations ……………………………………………………… 37
5
MFSC Series CW Fiber Laser products provide a wide range of
wavelength from 1060nm to 1100nm.The lasers are water-cooled and
maintenance-free and with a wall plug efficiency of more than 30% and
deliver high efficiency, high reliability and high performance.
Maxphotonics' MFSC Series CW Fiber Laser Series are Class 4 laser
products and are designed and tested with safety. By following this User
Guide and applying sound laser safety practices, it will be a safe and
reliable device.
Laser light exhibits unique characteristics that may pose safety hazards.
Therefore, the laser light can’t be normally associated with other light
sources, and all operators and people near the laser must be aware of
these special hazards.
In order to ensure the safe operation and optimal performance of the
product, please follow all warnings and safety instructions in this guide
during process of operation, maintenance and service.
For ensuring the safety of operators, operators are urged not to open
the equipment privately at all times. There are no user serviceable
parts, equipment or assemblies associated with this product. Lasers of
unauthorized disassembly shall not be subject to warranty.
Chapter 1
Characteristic Explain
6
Chapter 2
General Safety Information
1-Safety Conventions
All safety warning symbols during operating process of the laser include:
SYMBOLS DESCRIPTION
WARNING: Refers to a potential Electrical Hazard to
human body. It requires a procedure that, if not correctly
followed, may result in bodily harm to you and/or others.
Do not proceed beyond the WARNING sign until you
completely understand and meet the required conditions.
CAUTION：Refers to a potential hazard on product. It
requires a procedure that, if not correctly followed, may
result in damage to the product or components. In order
to ensure normal use of equipment, do not violate the
requirement of the CAUTION sign.
WARNING:Refers to a potential Laser Hazard.The symbol
represents laser radiation. The symbol is pasted on laser
output end.
NO SYMBOL
IMPORTANT：Refers to any information regarding the
operation of the product. Please do not overlook this
information.
7
Chapter 2 General Safety Information
NOTE :
◎ This device is classified as a high power Class IV laser instrument. It may
emit up to 4000W average power from 1060nm to 1100nm. This level of
light may cause damage to the eye and skin. Despite the radiation being
invisible, the beam may cause irreversible damage to the retina. Laser
safety eyewear is not provided with this instrument, but must be worn at all
times while the laser is operational.
2-Laser Protection
1、Laser Protection Requirements
You must wear the safety protective glasses while operating the laser,
and rationally select the safety protective glasses according to the lasing
wavelength of the laser. If the device is a tunable laser or Raman product,
it emits light over a range of wavelengths and the end user should confirm
the laser safety eyewear used protects against light emitted by the device
over its entire range of wavelength.
2、Laser Protective Equipment Suppliers
Maxphotonics recommends material or equipments provided by following
laser protective equipment suppliers for you, including LaserVision USA,
Kentek Corporation, Rochwell Laser Industries, etc. All the supplier
information is provided by Maxphotonics only for the convenience to use,
so Maxphotonics assumes no responsibility for any problem caused by
using the products of abovementioned suppliers.
8Chapter 2 General Safety Information
3-Reference Standard
Anti-interference Performance on Electromagnetic Compatibility：
EN 61000-6-4:2007 + A1:2011
EN 61000-6-2:2005 + AC: 2005
EN 61000-3-2:2014
EN 61000-3-3:2013
Power Supply Security:
EN 61010-1:2010
EN60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013
Laser Security:
EN 60825-1:2014
CDRH 21 CFR 1040.10
NOTE:
◎ In accordance with relevant EU and national standards and requirements,
the laser must be classified according to its output power and laser
wavelength. All MFSC-3000W-4000W-Series laser products with high power
belong to Class 4 products (according to article 8, EN 60825-1).
