Lenovo IdeaCentre Q180 Guide Manual

Front view Install optical drive (selected

models only)

Initial setup instructions Rear view

Tiny Desktop PC

Q180 Series

1

2

Power button

Hard disk drive indicator

Optical drive

Memory card reader

USB ports (2)

Headphone connector

Microphone connector

SPDIF port

VGA connector

USB ports (5)

HDMI-out port

Ethernet connector

Power connector

Connect to power

Version: 1.0 2011.08

31500792

Read the detailed information in the Safety and Warranty Guide

before using this computer.

Notes:

• FiguresandillustrationsinthisQuickReferenceare

provided for reference only and may differ from actual

product appearance.

• Productdesignandspecicationsmaybechangedwithout

notice.

• Thecolorandshapemayvarydependingonthemodel.

Attention: Be sure not to block any air vents on the computer.

Blocked air vents may cause thermal problems.

Install metal bracket Stand

Thecomputerchassiscanbeplacedinaverticalposition.

Note: Make sure to install the base stand before placing the

chassis in a vertical position.

Thecomputerchassiscanalsobeplacedinahorizontalposition.
