Konica Minolta REGIUS 190 User manual

REGIUS MODEL 190

(DD-941)

OPERATION MANUAL

No. 26-2, Nishishinjuku 1-chome, Shinjuku-ku, Tokyo 163-0512, Japan

DIRECT DIGITIZER

CODE NO. : 0676

REGIUS MODEL 190 OPERATION MANUAL Ver.1.03 2004.12

Table of Contents

Foreword ……………………………………………………………………… 1

About this Manual …………………………………………………………… 3

Ch.1 Safety Precautions & Warnings……………………………………… 7

Ch.2 Product Outline ……………………………………………………… 19

Name of Parts ……………………………………………………………… 20

Operation Flow ……………………………………………………………… 23

Ch.3 Operation ……………………………………………………………… 25

Handling the Cassette ……………………………………………………… 26

Power ON …………………………………………………………………… 31

Daily Start Up (When connected to CS-1 or CS-3) …………………………… 32

Daily Start Up (When connected to CS-2) …………………………………… 33

Inserting/Reading/Ejecting the Cassette ………………………………… 34

Erasing the REGIUS Plate ………………………………………………… 36

Daily Shut Down (Sleep) (When connected to CS-1 or CS-3) ……………… 39

Daily Shut Down (Sleep) (When connected to CS-2) ……………………… 40

Power OFF ………………………………………………………………… 41

Ch.4 Troubleshooting ……………………………………………………… 43

Error Messages and Remedies …………………………………………… 44

Handling Cassette Jams …………………………………………………… 48

Removal of Foreign Objects from Cassette Insertion Slot……………… 54

Troubleshooting for Cassette ……………………………………………… 56

Ch.5 Care & Maintenance ………………………………………………… 57

Specifications ………………………………………………………………… 61

Appendix ……………………………………………………………………… 63

LCD Display ………………………………………………………………… 64

Index ………………………………………………………………………… 65

1REGIUS MODEL 190 OPERATION MANUAL Ver.1.03 2004.12

We thank you for purchasing the "Direct Digitizer DD-941" (henceforth referred

to as REGIUS MODEL 190).

The REGIUS MODEL 190 is designed to read REGIUS Plates.

The basic operational procedures for the REGIUS MODEL 190 such as start

up/shut down, patient registration and parameter settings, are carried out using

a REGIUS CONSOLE CS-1/CS-2/CS-3 (henceforth referred to as CS-1/CS-

2/CS-3) available separately.

Before proceeding with usage of the REGIUS MODEL 190, time should be taken

to fully familiarize yourself with the contents of this operation manual as well as

the operation manual for the console (CS-1/CS-2/CS-3). Please note also that

since safety precautions regarding handling of and operational procedures for

the product are set out in this manual, the manual should at all times be kept in a

readily accessible place for easy reference.

Features

1 Realization of "Ultimate Resource Sharing Concept"

The reader and console may be separated, allowing maximum freedom of layout.

System architecture best suited to the number of examinations carried out or the room

space available may be realized.

2 Space-saving

The product is compact with a footprint of only 58 X 58 cm.

3 High-speed Processing

Throughput for 14" X 14" size is approximately 90 plates/hr.

4 Comfort Operability

Insertion and ejection slots are independent.

Next cassette can be set in the cassette insertion slot. (+1 stack)

Up to four processed cassettes can be stacked on the cassette stacker.

Foreword

REGIUS CONSOLE CS-1

REGIUS CONSOLE CS-3

This console (controller)

controls communication,

processing, and output of the

image data read by the

REGIUS MODEL 170, 190

and/or REGIUS MODEL 350,

550.

REGIUS CONSOLE CS-2

This console (controller)

controls communication,

processing, and output of the

image data read by the

REGIUS MODEL 190.

REGIUS MODEL 190 OPERATION MANUAL Ver.1.03 2004.12

Notes

(1) Unauthorized reproduction of this manual in whole or in part is prohibited.

(2) The content of this manual is subject to change without prior notice.

(3) Should any discrepancies, errors or omissions be discovered, KONICA MINOLTA should be contacted.

(4) Notwithstanding item(3) above, KONICA MINOLTA shall accept no responsibility of any claims made against loss or

loss of profits arising from use of the product.

Trademarks

Corporate names, brands, product names are the trademarks or registered trademarks of their respective owners.

Please that , or “TM”, representing these ownerships are omitted in the following pages.

3REGIUS MODEL 190 OPERATION MANUAL Ver.1.04 2004.12

Be sure to read this section before using this

manual.

About

this Manual

REGIUS MODEL 190 OPERATION MANUAL Ver.1.03 2004.12

How to use this manual

This manual consists of the chapters listed below.

Chapter1 Safety Precautions & Warnings

This chapter details warnings and cautions for operation of the REGIUS

MODEL 190.

Chapter2 Product Outline

This chapter gives an outline of the REGIUS MODEL 190.

Chapter3 Operation

This chapter details the procedures for operation of the REGIUS

MODEL 190.

Chapter4 Troubleshooting

This chapter details procedures to be followed upon occurrence of errors

in the REGIUS MODEL 190.

Chapter5 Care & Maintenance

This chapter details the procedures for care and maintenance of the

REGIUS MODEL 190.

Specification This chapter details the specification of the REGIUS MODEL 190.

Appendix The messages displayed on the LCD panel are described in this chapter

as an appendix.

Index The index to this REGIUS MODEL 190 Operation Manual is described in

this chapter.

Basic operation procedures are detailed in the chapters 2 and 3. Chapter 4 should be referred to

for details of errors such as cassette jams.

An example page layout is explained on the next page.

5REGIUS MODEL 190 OPERATION MANUAL Ver.1.03 2004.12

REGIUS MODEL 190 OPERATION MANUAL Ver. 1.00 2004/10

LCD Panel

"operation" button

"operation" Lamp

1Check if the power plug is

connected to the power outlet.

2Turn ON the power breaker of the

REGIUS MODEL 190.

•Ensure that the CS-1/CS-2/CS-3 is

running. If the system includes an

external JM-1, ensure that the JM-1 is

running.

4Initialization of the REGIUS

MODEL190 will be started.

•The LCD panel will show the message

"INITIALIZING" and the counter

■ ■ ■

• • •".

•When the counter "

■ ■ ■

• • •"

reaches the left end, "READY" will be

shown.

•The REGIUS MODEL 190 is ready for

operation.

Power Breaker

3Depress the "operation" button.

•The "operation" lamp will illuminate.

(Green)

•The LCD panel will show

"REGIUS MODEL 190".

:OFF

:ON

REGIUS MODEL 170

READY

INITIALIZING

Be careful not to push the

"erase" button by mistake

when pushing the "operation"

button.

JM-1

This is an application software

that controls the network

between REGIUS MODEL

190 and CS-1/CS-2/CS-3.

(There are two types of JM-1;

One is built-in, the other is

external.)

Contact your system

administrator to ensure which

of the two types is used.

p.29 Daily Start Up

p.35 Daily

Shut Down

(Sleep)

The power breaker of the

REGIUS MODEL 190 does

not have to be operated in a

daily usage.

Only when the power

breaker is turned OFF, for

instance, the unit is not

used for an extended

period, the power breaker

should be turned ON.

The following is a description of the procedure for switching on the REGIUS MODEL 190.

Start and shut down of the REGIUS MODEL 190 are carried out from the REGIUS Console CS-1/CS-

2/CS-3 that controls it. The power should always be left on. In the case of emergencies or power

failure, the power should be switched on, by following the procedure below.

Power ON

Hint

Points to be noted.

Technical Term

Technical terms are

explained.

Title

This title stands for the

general meanings for

the descriptions.

Display or Illustration

Display or Illustration with

the operational procedure

is shown.

Operation Procedure

Operation procedure is

explained in order.

Caution

Cautions for

operating the

machine.

Details should be

carefully noted.

Reference

Shows the reference

pages or sections.

See the page for

more details.

Page Layout

Quotation Marks, " ".

The word in quotes shows that it is displayed on the LCD panel

of REGIUS MODEL190.

Ex. "READY"

LCD display in procedures

When the LCD message as shown in the right is illustrated in the

procedure, it indicates that the message is actually shown on the

LCD of REGIUS MODEL190 at the time of implementing the

procedure.

Messages will be displayed

here.

REGIUS MODEL 190 OPERATION MANUAL Ver.1.03 2004.12

7REGIUS MODEL 190 OPERATION MANUAL Ver.1.03 2004.12

Safety

Precautions &

Warnings

When using the REGIUS MODEL 190, the

cautions detailed in this chapter must be strictly

followed in order to correctly use the device.

● Symbols indicating the need for caution (including danger and warnings)

● Symbols indicating prohibited acts

● Symbols indicating essential acts (compulsory or indicated acts)

● Other Symbols

REGIUS MODEL 190 OPERATION MANUAL Ver.1.03 2004.12

This is the safety alert symbol and is intended to draw the attention

of the user to potential dangers to the user him/herself or to others

that may arise during the use or operation of this system.

These messages must be read thoroughly and strictly observed.

All safety related precautions should be carefully read and fully

understood before proceeding with assembly or usage of this

system.

Safety Alert Symbol

NOTE : If the contents of this page are not legible, order a new manual.

Description of Graphic Symbols

Normal caution

Danger of fire Danger of electrocution

Prohibited

Main power supply OFF Main power supply ON

Power supply standby

Do not touch

Do not disassemble Do not touch

with wet hand

Do not expose to

moisture

AC voltage

(power supply)

Alert and Symbol Marks

Ground Remove the plug from

the power outlet
