Kentucky MMP User manual

MMP

Digital Length Measuring Gauge

*shown with optional measuring surface

I NS TR U CT IO N M A NU AL

Hymark Ltd. –427 Bark cove–Owensboro, KY 42303

(270) 683-3500 –Fax (270) 683-2500

www.kentuckygauge.com

Table of contents

1. Product Description 4

1.1 Intended use 4

2. Basic Safety Hints 5

2.1 Notice hints inside manual 5

2.2 Owner obligations 5

2.3 Operator obligations 5

2.4 Intended use 5

3. Maintenance Requirements 7

3.1 Lubricants and Detergents 7

3.2 Maintenance Schedule 7

3.3 Cleaning the Guide Rail 7

3.4 Cleaning the Magnetic Tape 7

3.5 Cleaning the Carriage 8

3.6 Cleaning the Contact Plates 8

4. DRO Operation 9

4.1 Setting the Datum 9

4.2 Entering/Changing the Datum Value 9

4.3 Setting the Display Mode (Inch-to-metric) 9

4.4 Changing from Absolute to Incremental Measuring 9

5. DRO Parameter Mode 10

5.1 Entering Parameter Mode 10

5.2 Editing Paramters 10

5.3 How to exit Paramter Mode 10

5.4 Parameter List 10

6. DRO Specs 13

6.1 Dimensional Drawing 13

6.2 Technical Data 13

6.3 Integrated Sensor Specs 13

7. Warranty 14

1. Product Description

1.1 Intended Use

The only acceptable use for the MMP is as a length measuring gauge system. Never place

any material on the measuring surface except the piece to be measured. Any other use is

not intended and is a misuse of the gauging system.

Contact

Plates

Optional Measuring

Surface

Digital

Readout

Guide

Rail

Carriage

2. Basic safety hints

2.1 Read and follow all hints inside the Instruction Manual

Basic requirements for the correct use of the gauging system or the machine are the

knowledge of the basic safety hints and the safety precautions.

This instruction manual contains the most important safety hints.

This instruction manual, especially the safety hints and precautions must be followed by

every person working with this gauge or machine.

Also follow all general plant safety rules and precautions not mentioned in this manual.

2.2 Owner obligations

The owner agrees to only allow the gauge or the machine to be used by qualified and trained

persons who

-Have been instructed in the general safety rules and precautions

-Have been instructed in the correct use of the gauge and machine

-Have read and understood the safety chapters and caution hints of this instruction

manual.

2.3 Operator obligations

All persons working with this gauge and machine agree before starting to work

-To follow the general safety rules

-To read and understand the safety chapters and caution hints of this instruction manual.

2.4 Intended use

The only acceptable use for this gauge is as a length gauging system. Any other use is not

intended and is a misuse of the gauging system.

Hymark is not liable for any damages resulting from misuse.

Intended use also means:

-Following all safety hints and precautions mentioned in this manual

-Following the maintenance and inspection procedures as mentioned

in this manual.

Note: LCD displays is powered by 1 ‘C’ battery and will not power off.

Battery will need to be replaced approximately every 12 months.

Contact

Plates

Optional Measuring

Surface

Digital

Readout

Guide

Rail

Carriage

3Maintenance Requirements

Maintenance jobs as described in this chapter may only be done by authorized and trained

personnel.

**Prior to any maintenance of the Kentucky Gauge or accessories, please ensure the

machine is not in operation and corresponding equipment is in “off” position.

3.1 Lubricants and Detergents

Detergent

Use commercially available detergents.

Don’t use any acids or alkaline solutions

Don’t use any high pressure water jet cleaners

3.2 Maintenance Schedule

See

chapter

Device

Cleaning

Lubricate

In addition

Frequency

3.3

Guide Rail

daily

3.4

Magnetic tape mounted to

bottom side of aluminum

extrusion

daily

3.5

Carriage

daily

3.6

Contact Plates

daily

Legend: X - has to be done -- Nothing to do

3.3 Cleaning the Guide Rail

Remove chips, grease and any items on the conveyor/table that would be

deemed in the pathway of, or causing an unwanted obstruction of, the

carriage/gang stop. This should be done several times per day if the machine

is in heavy use.

3.4 Cleaning the Magnetic Tape

Remove chips and grease on the magnetic tape and between reader head and

tape. This should be checked daily to ensure there is no development of debris

or obstruction. If heavy chip or debris accumulation occurs, increase frequency

to accommodate suitable maintenance measures.

The sensor to scale gap should be within the range of 0.1mm to 1.0mm

3.5 Cleaning the carriage

Remove chips, grease and any items on the conveyor/table/measuring surface

that would be deemed in the pathway of, or causing an unwanted obstruction

of, the carriage/contact plate. This should be done several times per day if the

machine is in heavy use.

Ensure that the hardware connecting the contact plates to the carriage is

secured. This may be checked on a quarterly basis or implemented in line with

the standard preventative maitneance schedules for the other equipment in

the facility.

3.6 Cleaning the contact plates

Wipe down plates and remove any dirt, grime, or moisture.

Apply a liberal coat of oil (3-n-1 oil or similar) to every exposed surface of the

contact plates to prevent corrosion.

4 DRO Operation

P: Program (programming/change parameters)

: UP (increase value of selected digit)

: Shift left (select digit)

*: Save (save data)

4.1 Setting Datum (Referencing the system)

By setting the datum or referencing the system, the operator is setting up the system so

that the distance from the moving contact plate to the stationary contact plate is correctly

displayed in the digital readout.

NOTE: Your datum value needs to be set before performing this function.

See “4.2 Entering / changing datum value”

1. Move the stop to a known location using a standard or other suitable method.

2. Press the *button for 3 seconds.

3. The display will show “rESEt”

4. Press the * button again to show the current position flashing. Note: at this point the

referencing can be cancelled by pressing “P”

5. Press the * button again to confirm the reference reset by displaying “done”

momentarily. This will set the display to the pre-entered datum value.

4.2 Entering / changing datum value

Push Pand buttons together to display datum value “rEF’. Use and keys to change

value and save with *button.

This feature is only enabled if “F_rEF” parameter is set to “on” (see chapter 5).

4.3 Setting the Display Mode (Toggle from inch to metric)

The display can be easily changed to display inch or metric values by pressing the button

for 3 seconds. Note: inch mode with 3 decimals or fraction display must be selected in

parameter Inch_F (see chapter 5).

4.4 Changing from Absolute Measuring to Incremental Measuring

The display can be changed from absolute measuring (unit displays actual distance from saw

blade) to incremental or relative measuring (unit displays distance from last position).

Pressing the Pand *buttons together toggles these modes.

Note: INC is shown in the display when the unit is running in incremental mode.

Note: Setting the display to zero in incremental mode is not affecting the real absolute value

5. DRO Parameter Mode

5.1 Entering Parameter Mode

Press Pbutton for 3 seconds to enter setup mode. “SEtUP” will be shown in the display.

Press button to enter Menu 1 (parameter mode)

5.2 Editing Parameters

Press Pbutton to select next Parameter and Parameter setting.

Press *button to save entered values

5.3 How to exit Parameter Mode

Press Pbutton until you reach final parameter rESEt.

Now press Pbutton twice to return to operating mode.

5.4 Parameter List

Parameter description Factory Setting User Setting

dG_Ln Degrees/Linear (dG, dG2, Lin) Lin __________

Angular or linear display mode.

Lin = ..0,0..0,1..0,2..0,3 mm

dG1 = angles

..–0,1°..0,0°..+0,1°..+359,9°..0,0°

dG2= angles

..359,9°..0,0°..0,1°..359,9°..0,0°

*= save, P = next parameter

Note: when selecting dG1 or dG2 the next

available parameter will be FrEE not rES.

rES Resolution (10, 50, 100, 1000, FrEE) 10 __________

Linear resolution value in microns.

10 = 0.01mm

50 = 0.05 mm

100 = 0.1 mm

1000 = 1 mm

FrEE allows to enter a resolution factor e.g.

for angular displays (basis of calculation is

max. resolution 0.01 mm).

*= save, P = next parameter

FrEE Ln mode (0,0001, 1,0000) - __________

FrEE dG mode (0,0001, 9,9999)

e.g. angle display with range from 0° to 90°

and 0,1° resolution on a rotating table with

circumference of 785,4 mm. Total working

range is 785,4 mm : 4 = 196.35 mm.

FrEE = 900 : 19635 = 0,045836

*= save, P = next parameter
