IMV CardVibro Air2 User manual
WiFi Portable Vibrometer
VM-2012 Air2 1/52
WIFI PORTABLE VIBROMETER
CARDVIBRO AIR2
USER’S GUIDE
VM-2012 AIR2
VM-2012C AIR2 CONNECT
Document Number
: TVE-6-3852E
Issued on: Sept. 11, 201
Pages: 52
Version: 2.5.0
WiFi Portable Vibrometer
VM-2012 Air2
2/52
Revision History
Date Rev Details
Feb 14, 2013 0.8.0 New Issue
Feb 21, 2013 0.8.1 Added a clause.
Feb 22, 2013 0.8.2 Added description o vibration criteria.
Feb 28, 2013 1.0.0 Added options o connectors.
Mar 18,2013 1.0.1 Added a status o charge completion
April 17, 2013
1.6.0 Added the unctions, Cursor, Top5, Dictionary
Added the battery change,
Change Evaluation criteria or ISO & Bearing
April 19,2013 1.6.2 Added setting o Android Tablet
March 14,2014
2.0.1 Added IP Code, Manu actured Country,
Radio Certi ication, Distributor
Revised Application Screen
User Judgment and its criteria level editor
March 3,2017
2.0.2
Change
Corporate logo
Sept 11,2017 2.5.0 Improve graph manipulation
Add USB wired measurement
WiFi Portable Vibrometer
VM-2012 Air2 3/52
Table of Contents
1. INTRODUCTION............................................................................................................................5
2. CONTENTS OF A PAC AGE ...........................................................................................................6
2-1. Product and Parts ......................................................................................................................6
2-2. Free Data...................................................................................................................................6
2-3. Optional Accessories..................................................................................................................7
3. FRONT VIEW.................................................................................................................................8
3-1. Power Button.............................................................................................................................9
3-2. LED Indicator.............................................................................................................................9
3-3. USB Outlet.................................................................................................................................9
3-4. Battery.......................................................................................................................................9
3-5. Strap Mount...............................................................................................................................9
3-6. Vibration Sensor ........................................................................................................................9
3-7. Socket (M6 Thread)...................................................................................................................9
3-8. Sensor Connector ......................................................................................................................9
4. DIMENSIONS...............................................................................................................................10
4-1. Standard Model .......................................................................................................................10
4-2. Connector Model......................................................................................................................11
5. HOW TO INSTALL THE SOFTWARE.............................................................................................12
6. OPERATING INSTRUCTIONS.......................................................................................................12
6-1. Activation of the Software and Setting of the Tablet PC (Nexus 7)..........................................12
6-2. Measurement Method..............................................................................................................13
6-2-1. Connection with the Air2..................................................................................................... 14
6-2-2. OA Vibration Measurement ................................................................................................. 16
6-2-3. Quick Diagnosis................................................................................................................... 16
6-2-4. Data Save............................................................................................................................ 19
6-2-5. FFT/Wav Analysis................................................................................................................ 20
6-2-6. Cursor ................................................................................................................................. 22
6-2-7. Top5.................................................................................................................................... 23
6-2-8. Route Settings..................................................................................................................... 25
6-2-9. Settings............................................................................................................................... 26
6-3. Battery Exchange.....................................................................................................................27
6-4. USB Connection.......................................................................................................................28
7. UTILITIES ...................................................................................................................................29
7-1. Sensor .....................................................................................................................................29
7-2. Saved Data ..............................................................................................................................30
WiFi Portable Vibrometer
VM-2012 Air2
4/52
7-3. Units ........................................................................................................................................32
7-4. Memory ...................................................................................................................................33
7-5. A Filter.....................................................................................................................................33
7-6. Dictionary ................................................................................................................................34
7-7. Hierarchy .................................................................................................................................34
7-8. Tx Settings ..............................................................................................................................35
7-9. User Judgment Edit .................................................................................................................36
8. SPECIFICATIONS.........................................................................................................................37
8-1. Basic Specifications .................................................................................................................37
8-2. Measurement Specifications ....................................................................................................37
8-3. VM-2012 Air2 Specifications ....................................................................................................40
8-4. VM-2012C Air2 Connector Model Specifications ......................................................................40
9. VIBRATION EVALUATION STANDARD .........................................................................................41
9-1. ISO Vibration Evaluation Standard – Vibration Evaluation Standard by Vibration Severity ......41
9-2. Bearing Evaluation...................................................................................................................42
10. VM-2012C CONNECTOR MODEL..............................................................................................43
10-1. VP-2012PS1 – Low Frequency Vibration Measurement Pickup.............................................43
10-2. CA-2012 Charge Amplifier....................................................................................................46
11. Advanced Setting of Android Tablet.........................................................................................48
12. RADIO CERTIFICATION ...........................................................................................................50
13. NOTES .....................................................................................................................................51
14. CONTACT INFORMATION ........................................................................................................51
15. DISRIBUTOR............................................................................................................................52
WiFi Portable Vibrometer
VM-2012 Air2 5/52
1. INTRODUCTION
We truly appreciate your purchase.
Please read this manual care ully be ore use and ollow the cautions below or your sa ety.
Should you have any inquiries or ind a problem during use, please consult our sales o ice near you or IMV
quality assurance department.
1. I the subject o the measurement could be hot, rotating, or near the movable parts,
assure the sa ety and ix the pickup or measurement.
Do NOT hold the pickup manually in these cases to avoid any possible accidents;
including burning yoursel , and entangled cables.
2. Follow the instructions printed on the battery or replacement and disposal o used
batteries. Pay attention to the polarity o the battery or installation.
CAUTION
WiFi Portable Vibrometer
VM-2012 Air2
6/52
2. CONTENTS OF A PAC AGE
2-1. Product and Parts
1. CardVibro Air2
(Image: Standard Model) 2. USB Battery Charger 3. USB Cable
4. Standard Probe 5. Ni-MH (Rechargeable) Batteries 6. Quick User’s Guide
2-2. Free Data
1. Android Application
/ Google Play 2. User’s Manual 3. User’s Manual Video /YouTube
WiFi Portable Vibrometer
VM-2012 Air2 7/52
2-3. Optional Accessories
1. Data Management So tware 2. Equipment Diagnosis So tware 3. Carrying Case
4. Magnet 5. Long Probe 6. Cable
Available for the VM-2012 only.
Available for the VM-2012C only.
7. Piezoelectric Acceleration Pickup
8. Low Frequency Vibration
Measurement Pickup 9. Charge Ampli ier
Available for the VM-2012C only.
Available for the VM-2012C only.
Available for the VM-2012C only.
10. Holder 11. Sensor Input Cable
Available for the VM-2012C only.
Available for the VM-2012C only.
WiFi Portable Vibrometer
VM-2012 Air2
8/52
3. FRONT VIEW
(1) Power Button
(2) LED Indicator
(3) USB Outlet Cover
(4) Battery Cover
(5) Strap Mount
(6) Vibration Sensor
(7) Socket (M6 size screw)
(8) Sensor Connector
(1)
(2)
(3)
(4)
(5)
(6)
(7)
Standard Model: VM-2012 Connector Model: VM-2012C
(8)
WiFi Portable Vibrometer
VM-2012 Air2 9/52
3-1. Power Button
Press the power button to turn on the device. When it is on, the LED is on.
Press the power button to turn o the device. When it is o , the LED is o .
When the device is on, WiFi goes standby and be ready to be connected.
3-2. LED Indicator
Below shows the meaning o LED indications:
Color Light Device
Red ● Blinking Connection Standby/Complete Charging
On Error
Orange ● Blinking Shutting Down or USB Connecting
On USB Connected
Green ● Blinking Wi-Fi Connecting
On Wi-Fi Connected
Red & Orange ●● Blinking Charging
3-3. USB Outlet
Loosen two screws and slide the cover counterclockwise to open. You can connect a micro USB cable or
charging or vibration measurement with wired connection.
With the USB cover open, you may ail to attain waterproo e ects.
3-4. Battery
Use a Philips screwdriver to loosen two screws to open the cover in order to replace batteries. Only AAA
rechargeable batteries can be used in the Air2. Do not use non-rechargeable batteries.
3-5. Strap Mount
You can attach a strap to the device.
3-6. Vibration Sensor
Fix the sensor to the area where you want to measure the vibration. For direct measurement, screw the
standard probe in the socket at the tip o the sensor. You may screw the magnet in the socket or
hands- ree measurement.
3-7. Socket (M6 Thread)
Air2 standard model has an M6 thread. The probe or the optional magnet that can be secured in position
with an M6 screw.
3-8. Sensor Connector
You can use the external pickup by connecting it to the Air2 connector model.
WiFi Portable Vibrometer
VM-2012 Air2
10/52
4. DIMENSIONS
4-1. Standard Model
