Hubbell CHANCE PSC4033710 User manual

CHANCE® Multi-Range Voltage Indicator

Hubbell has a policy of continuous product improvement. Please visit hubbellpowersystems.com to conﬁrm current design speciﬁcations.

Revision A

10/16

Operating Instructions Model No. PSC4033710

For use with Capacitive Test Point through 80 kV AC

NOTICE: Before operating a Chance® Multi-Range

Voltage Indicator (MRVI), thoroughly read, understand

and follow these instructions. Keep these instructions

with product for future reference.

Multi-Range Voltage Indicator Operating Instructions

Guide to Warnings within Manual

The following is a list of warnings used within this manual and should be read in their entirety to

ensure safe practices.

A DANGER refers to operating procedures, techniques, etc., that, if not followed carefully could

RESULT IN DEATH.

A WARNING refers to operating procedures, techniques, etc., that, if not followed carefully could

RESULT IN INJURIES OR DEATH.

A CAUTION refers to operating procedures, techniques, etc., that, if not followed carefully could

RESULT IN DAMAGE TO EQUIPMENT or LOSS OF SERVICE to customers.

A NOTICE refers to information that is considered important but not hazard related.

! DANGER

! WARNING

! CAUTION

NOTICE

Multi-Range Voltage Indicator Operating Instructions

Product Safety

Before and after each use, always test the unit on a known energized voltage source or with the

Voltage Indicator Tester to verify proper operation.

The equipment covered in this manual must be used and serviced only by competently trained

personnel familiar with and following approved work and safety practices. This equipment is for

use by such personnel and this manual is not intended as a substitute for adequate training and

experience in safe procedures for this type of equipment.

These instructions neither cover all details or situations in equipment use, nor do they provide for

every possible contingency to be encountered in relation to installation, operation or maintenance.

Should additional information and details be desired or if situations arise which are not covered

adequately for the user’s purpose, the speciﬁcs should be referred to Hubbell Power Systems.

! WARNING

Always use an appropriate length insulated Hot Stick even when wearing rubber gloves. Contact

with the universal coupling or other parts, even with rubber gloves, will cause erroneous voltage

indication. Always use with a universal pole to maintain its calibration.

! WARNING

! CAUTION

CORRECT USE INCORRECT USE

Minimum Approach Distances (MAD) should be adhered to at all times. For the latest information

and charts refer to the ofﬁcial OSHA website: https://www.osha.gov

! DANGER

Do not allow the universal coupling or housing to become grounded in any way, or to contact

another phase as this will cause erroneous voltage indication and could cause severe personal

injury or damage to equipment.

! WARNING

Multi-Range Voltage Indicator Operating Instructions

Function and Design Overview

Features

The CHANCE® Multi-Range Voltage Indicator® (MRVI), model number PSC4033710, is a portable tool

to conﬁrm that an AC (Alternating Current) high voltage circuit is energized or de-energized prior to

performing maintenance. It provides ﬁeld practicality over the two points of contact measurement

method. Readings from the MRVI represent the class of voltage that is present on the line. The MRVI is

designed to determine approximate Phase-to-Phase and Phase-to-Ground nominal voltage up to 80

kV AC, 50/60 Hz. This unit is a direct contact electric ﬁeld intensity indicator.

The MRVI is used as a secondary means to conﬁrm the condition of a circuit after principal work

procedures such as visible open gaps, dispatcher hold orders, and apparatus tag-outs have rendered

the circuit de-energized.

• Meets intent of OSHA 1910.269 to test for absence of nominal voltage

• Used to determine if power lines are at rated voltage, have induced voltage, or are de-energized

• Capacitive test point through 80 kV AC for overhead and underground systems

• Stepper motor technology

• Illuminated ﬂuorescent pointer

• Power-saving sleep mode (auto-off)

• Checks battery voltage on initial startup

• Positive interface power button

• Equivalent Phase-to-Phase and Phase-to-Ground reading ranges

• Manually activated Hold Mode

• Bluetooth technology

• New lightweight design (19.8 oz without batteries)

• Battery drawer for simple battery replacement

• Comes with a storage bag with a snaphook designed to attach to a lineman's belt

• QR code located in the instructions, Quick Reference guide, and on the unit itself

This device is an AC (alternating current/alternating voltage) only indicator; do not use it to detect

DC (direct current/non-alternating voltage).

NOTICE

Before and after each use, always test the unit on a known energized voltage source or with the

Voltage Indicator Tester to verify proper operation.

! WARNING

Multi-Range Voltage Indicator Operating Instructions

Accuracy

This instrument is not a voltmeter; hence, the manufacturer claims no speciﬁc accuracy and therefore

no speciﬁc accuracy is to be assumed by the user. Readings will vary with the ﬁeld intensity,

determined by a great variety of ﬁeld conditions including proximity, size, and orientation of all system

components in the vicinity, both energized and grounded. Erroneous readings may result from being

placed near other energized conductor, sources, or grounds. To avoid such ﬁeld distortions: keep the

unit as far away as practical from all system components other than the speciﬁc conductor being

tested.

Front Panel Information

1. Pointer Stop

2. Mode LED

3. Sense LED

4. Phase to Phase Scale

5. Phase to Ground Scale

6. LED Legend

7. Audible Alarm

8. Power Button

9. "BAT" Battery Voltage Level

Indicator

Multi-Range Voltage Indicator Operating Instructions

Operations for Overhead

To Turn the Unit On:

1. Momentarily depress the “Power Button.”

a. The “Mode LED” (Light Emitting Diode) will continuously illuminate green, indicating the unit

is active. The pointer will rotate counter-clockwise against the "Stop" and will momentarily

move clockwise to the zero mark. The audible alarm will sound once to indicate the power is

on.

b. The pointer will pause at the zero mark for approximately 1 to 2 seconds before proceeding

in the clockwise direction to a zone on the dial face marked, “BAT.” The pointer will remain in

this zone for approximately 4 to 5 seconds to indicate the current condition of the batteries. If

the pointer is in the green “BAT” zone the batteries are good. If the pointer is in between the

green and red “BAT” zones the batteries should be replaced soon. If the pointer is in the red

“BAT” zone or the “Mode LED" is ﬂashing green the batteries should be replaced immediately.

c. After the pointer has indicated the condition of the batteries, the pointer will recalibrate its

position by rotating counter-clockwise below the zero mark (to the "Stop") and then move

clockwise to the zero mark. The audible alarm will sound once and the “Sense LED" will

illuminate, ﬂashing red, if no electric ﬁeld is currently being detected.

d. The MRVI is ready for use once it is installed on an appropriate length insulated Hot Stick.

Taking a Reading:

2. Place the installed Shepherd Hook in contact with the power line conductor.

a. The "Sense LED" has been designed to change from ﬂashing to continuously illuminated as

the electric ﬁeld increases in intensity and reaches a potential that is greater than or equal to

600 V AC Phase-to-Phase.1

b. The pointer will rotate and indicate a voltage level present on the power line conductor.

Hold Mode: Refer to page 8.

Turning the Unit Off:

3. To turn the MRVI off:

a. Press and hold the "Power Button" for 3 seconds:

i. The "Mode LED" and "Sense LED" will turn off.

ii. The pointer will rotate counter-clockwise until it rests against the Stop.

iii. The audible alarm will generate three tones in decreasing pitch.

b. Or the MRVI will automatically power itself down (auto-off) after approximately 15 minutes of

inactivity.

Before and after each use, always test the unit on a known energized voltage source or with the

Voltage Indicator Tester to verify proper operation.

! WARNING

1 The “Sense LED” may change from ﬂashing to continuously illuminated at voltages less than 600 V AC Phase-to-Phase due to

the inﬂuences of other nearby energized conductors, static charges and other environmental conditions.

Multi-Range Voltage Indicator Operating Instructions

Operations for Overhead (Cont.)

Both the electromagnetic action of current and electrostatic action of voltage can induce a high

static condition on the de-energized circuit. Activity effects can exist between all conductor pairs.

The MRVI indicates the combined ﬁeld intensity from all other conductors, including ground wires.

NOTICE

Multi-Range Voltage Indicator Operating Instructions

Hold Mode for Overhead and Underground

Hold Mode:

To place the MRVI in the Hold Mode:

a. Make certain that the MRVI is powered on and active by momentarily depressing the “Power

Button.”

b. While holding the installed Shepherd Hook (or Bushing Adapter for underground) away from

the high voltage source, press the "Power Button" twice in rapid succession to place the MRVI

into the Hold Mode.

c. Once the MRVI is in its Hold Mode the "Mode LED" will ﬂash orange and the audible alarm will

chirp continuously to let you know the MRVI is in the Hold Mode.

d. The pointer will rotate counter-clockwise until it encounters the "Stop" and then it will return

to the zero mark on the dial.

e. Place the installed Shepherd Hook (or Bushing Adapter for underground) in contact with the

power line conductor:

i. The "Mode LED" will begin to ﬂash orange.

ii. The audible alarm will begin to beep in higher and higher pitch.

iii. The pointer will rotate to indicate the voltage level present on the power line conductor.

f. Once the MRVI has sensed a constant value of the voltage level present on the power line

conductor:

i. The "Mode LED" will change from ﬂashing to a continuously illuminated orange color.

ii. The audible alarm will sound a continuous tone and the pointer will hold on the peak value.

g. Once the MRVI is removed from the power line conductor, the pointer will remain on hold until

the “Power Button” is rapidly depressed a single time, placing the MRVI back into the active

state.

h. Once the "Power Button" is depressed:

i. The pointer will rotate counter-clockwise until it encounters the "Stop" and then it will

return to the zero mark on the dial.

ii. The audible alarm will cease to generate a tone.

iii. The "Mode LED" will illuminate green to indicate the MRVI is in its active state and is ready

to resume taking readings.

In the Hold Mode the MRVI is waiting for a steady (consistent) voltage reading before holding a

reading. Movement of the MRVI's Shepherd Hook (or the Bushing Adapter) in the electric ﬁeld

during the Hold Mode will cause a delay in capturing the reading. Keep the MRVI steady and in

constant contact with the conductor until the "Mode LED" is continuously illuminated (orange

color) and the audible alarm produces a continuous tone. To return to an active state, the indicator

must be reset.

! CAUTION

Multi-Range Voltage Indicator Operating Instructions

Operations for Underground

Always use appropriate length insulated Hot Stick even when wearing rubber gloves. Contact with

universal coupling or other parts, even with rubber gloves, will cause erroneous voltage indication.

Also, due to the close proximity of conductive metals, the readings taken in URD cabinets will

typically be higher than on an overhead line.

As with overhead, the same basic rules and procedures apply when using the CHANCE® Multi-Range

Voltage Indicator (MRVI) on underground systems. Follow these three very important additional

instructions when using the tool on underground equipment:

1. When testing dead-front URD equipment, use an appropriate Bushing Adapter rather than the

short probe or the Shepherd Hook.

2. Use extreme caution when testing live-front URD equipment. Use applicable safe work

practices and procedures. Do not use any probes on the MRVI when testing live-front URD

equipment. In place of a probe, use a small hex head machine screw (1/4-20 X 3/8" long).

3. When testing live-front URD equipment, the MRVI may detect ﬁelds from adjacent conductors,

energized parts or grounds, including grounded cabinet components. Indication of an

energized ﬁeld may not be sufﬁcient to isolate one speciﬁc conductor. Should the user wish to

conﬁrm a speciﬁc conductor is energized (or de-energized) further testing with a non-wireless

Phasing Set designed for this application will be required.

! DANGER

Before and after each use, always test the unit on a known energized voltage source or with the

Voltage Indicator Tester to verify proper operation.

! WARNING

Taking a reading with the MRVI with

Bushing Adapter on dead-front equipment

Screenshot of MRVI app

Multi-Range Voltage Indicator Operating Instructions

Operations for Underground (Cont.)
