HIK VISION DS-2CD726F-PT(W) User manual
Hikvision Technical Manual
DS-2CD726F-PT(W) IP Camera
Cost-effective Network Camera
Technical Manual
©2006 – 2010 by HIKVISION. All rights reserved.
1
Hikvision Technical Manual
©2006 – 2010 by HIKVISION. All rights reserved.
2
Notices
The information in this documentation is subject to change without notice and does not represent any
commitment on behalf of HIKVISION. HIKVISION disclaims any liability whatsoever for incorrect data
that may appear in this documentation. The product(s) described in this documentation are furnished
subject to a license and may only be used in accordance with the terms and conditions of such license.
Copyright © 2006-2010 by HIKVISION. All rights reserved.
This documentation is issued in strict confidence and is to be used only for the purposes for
which it is supplied. It may not be reproduced in whole or in part, in any form, or by any means or
be used for any other purpose without prior written consent of HIKVISION and then only on the
condition that this notice is included in any such reproduction. No information as to the contents or
subject matter of this documentation, or any part thereof, or arising directly or indirectly therefrom,
shall be given orally or in writing or shall be communicated in any manner whatsoever to any third party
being an individual, firm, or company or any employee thereof without the prior written consent of
HIKVISION. Use of this product is subject to acceptance of the HIKVISION agreement required to use
this product. HIKVISION reserves the right to make changes to its products as circumstances may
warrant, without notice.
This documentation is provided “as-is,” without warranty of any kind.
Please send any comments regarding the documentation to:
Find out more about HIKVISION at www.hikvision.com
Hikvision Technical Manual
©2006 – 2010 by HIKVISION. All rights reserved.
3
Contents
1. Key Features
2. Specifications
3. Dimension
Hikvision Technical Manual
©2006 – 2010 by HIKVISION. All rights reserved.
4
1.Key Features
z200 Presets
z20°/s Pan and Tilt Preset Speed
z0.3-20°/s Pan and Tilt Manual Speed
zEmbedded Linux OS
zH.264 video compression
z1 channel Audio Compression
zSupport 4CIF / DCIF / 2CIF / CIF / QCIF Real Time Compression
zSupport SD Card for Local Recording
zSupport Dual Stream Compression
zSupport Motion Detection, and Notification on PC Client
zSupport both Variable Bit Rate and Variable Frame Rate
zSupport TCP/IP, HTTP, DHCP, DNS, RTP/RTCP, PPPoE, etc.
zSupport IE for Network Preview
zSupport HIKVISION Watermark
zSupport Sensor Alarm Input and Relay Output
zSupport Network Voice Talk Function
zCompatible with Current HIKVISION DVR/DVS SDK and Client Software
Hikvision Technical Manual
©2006 – 2010 by HIKVISION. All rights reserved.
5
2.Specifications
Parameter
Model DS-2CD726F-PT
Camera
Image Sensor 1/4 inch CMOS
Effective Pixels 640 (H) × 480 (V)
Lens mount M12×0.5
Lens 3.6mm
Min. Illumination 0.4Lux @ F1.2
Infrared Function ---
Video Output Test Monitor OUT 1Vp-p Composite Output (75Ω/BNC)
Compression standard
Video Compression H.264
Video Output 32 K ~ 2M, adjustable (8Mbps maximum)
Audio Compression OggVorbis
Image Resolution 704 × 576, 640 × 480, 528 × 384, 704 × 288, 352 × 288, 176 × 144
Frame Rate 25fps (704 × 576)
Function
Pan and Tilt Range Pan: 0-170°;
Tilt: 0-90°
Horizontal Speed 0.3 ~ 20°/s(adjustable)
Vertical Speed 0.3 ~ 20°/s(adjustable)
Pan and Tilt Preset Speed 20°/s
RS-485 Protocols HIKVISION, PELCO-P/D (addible)
Scan Mode Cameras controlled by the client software or remote control can scan
≤170°range
Number of Preset 200
Privacy Protection Prevent Previewing through Network, just Preview on the Monitor.
Menu Language Chinese and English, 10 characters
Mouse Control Support Mouse Drag while select HIKVISION protocol in Client Software
Motion Detect Support
Dual Stream Support
SD Card Local Recording Support
Heartbeat Support
Password Protection Support
Protocols TCP / IP, HTTP, DHCP, DNS, RTP / RTCP, PPPoE (FTP, SMTP, NTP, SNMP addible)
Interface
Hikvision Technical Manual
©2006 – 2010 by HIKVISION. All rights reserved.
6
Voice Input 2channels ,1 channel 3.5mm audio interface (2.0 ~ 2.4Vp-p,1kΩ) and MIC
internal channel.
Voice Output 1 channel 3.5mm audio interface (Line level, 600Ω)
Communication 1 RJ45 10M / 100M self-adaptive Ethernet port , 1 RS-485 interface (802.11g
WLAN option, IR Remoter option)
Alarm Input 2 channels signal input
Alarm Output 1 channel relay output
Others
Working Temperature -10℃~ 60℃
Power Supply 12V DC, ±10%
Power Consumption 9W MAX
Dimension(mm) φ125 × 136.5
Weight 450g
Hikvision Technical Manual
3.Dimension
©2006 – 2010 by HIKVISION. All rights reserved.
7
