Harbor Breeze STONECROFT 41946 User manual

ATTACH YOUR RECEIPT HERE

Purchase Date _________________________

ITEM #0803776

STONECROFT

CEILING FAN

MODEL #41946

Español p. 20

JS21052

RATED FOR

DAMP LOCATIONS

HARBOR BREEZE and logo design are trademarks or

Questions, problems, missing parts? Before returning to your retailer, call our customer

service department at 1-888-251-1003, 8 a.m. - 8 p.m., EST, Monday - Sunday. You could also

TABLE OF CONTENTS

Package Contents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Hardware Contents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Safety Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Preparation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Initial Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Standard or Angle Mounting Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Final Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Operating Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Care and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Limited Lifetime Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Replacement Parts List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

PACKAGE CONTENTS

PART DESCRIPTION QUANTITY

A Downrod 1

B Downrod Pin (preassembled to Downrod [A]) 1

C Downrod Clip (preassembled to Downrod [A]) 1

D Mounting Bracket 1

E Canopy (preassembled to Mounting Bracket [D]) 1

F Canopy Cover (preassembled to Canopy [E]) 1

G Motor Assembly 1

H Light Pan 1

I Light Pan Screw (preassembled to Light Pan [H]) 3

J Light Cage Screw (preassembled to Light Cage [Q]) 3

K Set Screw (preassembled to Motor Assembly [G]) 2

L Yoke Cover 1

M Bulb 3

N Fitter Plate (preassembled to Motor Assembly [G]) 1

O Light Kit 1

P Fitter Plate Screw (preassembled to Fitter Plate [N]) 4

Q Light Cage 1

RBlade Arm 5

S Blade 5

T Remote Pack 1

UMounting Bracket Screw (preassembled to Mounting Bracket [D]) 4

QRS

0000

HARDWARE CONTENTS (shown actual size)

Wire Connector

Qty. 6

+ 1 extra

Blade Screw

Qty. 15

+ 1 extra

Blade Washer

Qty. 15

+ 1 extra

Motor Screw

10 + 1 extra

AA XX

BB CC

SAFETY INFORMATION

Please read and understand this entire manual before attempting to assemble, operate or install the

product.

• Before you begin installing the fan, disconnect the power by removing fuses or turning o󰀨 the circuit

breakers.

• Make sure all electrical connections comply with local codes, ordinances, the National Electrical

Code and ANSI/NFPA 70-199. Hire a qualied electrician or consult a do-it-yourself wiring

handbook if you are unfamiliar with installing electrical wiring.

• Make sure the installation site you choose allows a minimum clearance of 7 ft. from the blades to

the oor and at least 30 in. from the end of the blades to any obstruction.

• The net weight of this fan is: 20.81 lbs.

DANGER: When using an existing outlet box, make sure the outlet box is securely attached to

the building structure and can support the full weight of the fan. Failure to do this can result in serious

injury or death. The stability of the outlet box is essential in minimizing wobble and noise in the fan

after installation is complete.

WARNING: To avoid personal injury, the use of gloves may be necessary while handling fan

parts with sharp edges.

WARNING: Using a full-range dimmer switch to control fan speed will cause a loud humming

noise from the fan. To reduce the risk of re or electric shock, do NOT use a full-range dimmer switch

to control the fan speed.

WARNING: To reduce the risk of re, electric shock or personal injury, mount the fan to an

outlet box marked “ACCEPTABLE FOR FAN SUPPORT” and use the mounting screws provided with

the outlet box. Most outlet boxes commonly used for the support of lighting xtures are not acceptable

for fan support and may need to be replaced. Consult a qualied electrician if in doubt. Secure the

outlet box directly to the building structure. The outlet box and its support must be able to support the

moving weight of the fan (at least 35 lbs.).

WARNING: To reduce the risk of re, electrical shock or personal injury, wire connectors

provided with this fan are designed to accept only one 12-gauge house wire and two lead wires from

the fan. If your house wire is larger than 12-gauge and there is more than one house wire to connect

to the two fan lead wires, consult an electrician for the proper size wire connectors to use.

WARNING: To reduce the risk of re, electric shock or personal injury, do not bend the blade

arms when installing them, balancing the blades or cleaning the fan. Do not insert objects between

the rotating fan blades.

WARNING: To reduce the risk of personal injury, use only parts provided with this fan. The use

of parts OTHER than those provided with this fan will void the warranty.

SAFETY INFORMATION

CAUTION: Read all instructions and safety information before installing your new fan. Review the

accompanying assembly diagrams.

CAUTION: Be sure the outlet box is properly grounded or that a ground (green or bare) wire is present.

CAUTION: Carefully check all screws, bolts and nuts on the fan motor assembly to ensure they are

secured.

CAUTION: This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates, uses and

can radiate radio frequency energy and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful interference

to radio or television reception, which can be determined by turning the equipment o󰀨 and on, the user

is encouraged to try to correct the interference by one or more of the following measures:

-- Reorient or relocate the receiving antenna.

-- Increase the separation between the equipment and receiver.

-- Connect the equipment into and outlet on a circuit di󰀨erent from that to which the receiver is

connected.

-- Consult the dealer or an experienced radio/TV technician for help.

Please note changes or modications not expressly approved by the party responsible for compliance

could void the user’s authority to operate the equipment.

PREPARATION

Before beginning the assembly of this product, ensure that all parts are present. Compare all parts

with the package contents list and hardware contents list. If any part is missing or damaged, do not

attempt to assemble the product.

Estimated Assembly Time: 120 minutes.

Tools Required for Assembly (not included): Electrical Tape, Phillips Screwdriver, Pliers, Safety

Glasses, Step Ladder and Wire Strippers

Helpful Tools (not included): AC Tester Light, Tape Measure, Wiring Handbook and Wire Cutters

HKC-US

3350 Players Club Pkwy. #225

Memphis, TN 38125

1-888-251-1003

INITIAL INSTALLATION

1. Turn o󰀨 the circuit breakers and the wall switch to the

fan supply line leads.

DANGER: Failure to disconnect the power

supply prior to installation may result in serious injury

or death.

2. Determine the mounting method to use.

Standard Mounting is best suited for ceilings 8 ft.

or higher. For taller ceilings you may want to use a

longer downrod (not included).

Angle Mounting is best suited for angled or vaulted

ceilings. A longer downrod is sometimes necessary to

ensure proper blade clearance.

Important: If using the angle mount, check to ensure

the ceiling angle is not steeper than 10°.

Flushmount installation is not available for this item.

Closemount installation is not available for this item.

3. Ensure the blades (S) will be at least 30 in. from any

obstructions. Also check the downrod (A) length to

ensure the blades (S) will be at least 7 ft. above the

oor.

Standard Mounting

Flushmount Closemount

Angle Mounting

7 ft.

Minimum

30 in.

Minimum

INITIAL INSTALLATION

4. Loosen all four mounting bracket screws (U) on

mounting bracket (D), then completely remove the two

mounting bracket screws (U) from the round holes of

canopy (E). Set aside for later use.

Detach mounting bracket (D) from canopy (E).

5. Secure the mounting bracket (D) to the outlet box

using screws and washers provided with the outlet

box.

CAUTION: It is very important you use the proper

hardware when installing the mounting bracket (D) as

this will support the fan.

6. Remove the downrod pin (B) and downrod clip (C)

from the downrod (A). Then partially loosen the

set screws (K) in the yoke at the top of the motor

assembly (G).

Standard

Mount

Angle Mount

Yoke

STANDARD OR ANGLE MOUNTING INSTRUCTIONS

7. Insert the downrod (A) through the canopy (E)

and yoke cover (L). Feed the wires from the motor

assembly (G) through the downrod (A).

8. Slide the downrod (A) into the yoke of the motor

assembly (G), align the holes, then re-install the

downrod clip (C) and downrod pin (B). Secure with set

screws (K) and slide the yoke cover (L) down until it

rests on top of the motor assembly (G).

9. Depending on the length of downrod you use, you

may need to cut the lead wires back to simplify the

wiring. If you decide to cut back the lead wires, it is

suggested you do so in the following manner: Take

the lead wires and make sure you have pulled them

all the way through the top of the downrod. Measure

8 inches of lead wire, then cut the excess wire o󰀨 with

wire cutters (not included).

8 in.

STANDARD OR ANGLE MOUNTING INSTRUCTIONS

10.If you decided to cut back the lead wire in Step 9, strip

1/2 in. of insulation from the end of the wires. Twist

the stripped ends of each strand of wire within the

insulation with pliers (not included).

Note: If you did not cut back the lead wires in Step 9,

Step 10 is not necessary and you may proceed to Step

11 instead.

11. Install the ball end of the downrod (A) into the opening

of the mounting bracket (D). Align the slot in the

ball in the downrod (A) with the tab in the mounting

bracket (D). Note: The downrod (A) should not rotate if

installed correctly.

DANGER: Failure to align the slot in the ball with

the tab could cause the fan to fall, which may result in

serious injury or death.

12.Insert the receiver from remote pack (T) into the

mounting bracket (D) with the at side facing the

ceiling.

Slot

Tab

Receiver
