Harbor Breeze 42299 User manual

ATTACH YOUR RECEIPT HERE

Purchase Date _________________________

RR20389

ITEM #3025022

MAC CEILING FAN

MODEL #42299

Español p. 18

Questions, problems, missing parts? Before returning to your retailer, call our customer

service department at 1-888-251-1003, 8 a.m. - 8 p.m., EST, Monday - Sunday. You could also

HARBOR BREEZE and logo design are trademarks or

TABLE OF CONTENTS

Package Contents .................................................................3

Hardware Contents ................................................................4

Safety Information .................................................................5

Preparation ......................................................................6

Initial Installation ..................................................................7

Wiring ..........................................................................9

Final Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Operating Instructions .............................................................13

Care and Maintenance ............................................................14

Troubleshooting..................................................................14

Limited Lifetime Warranty ..........................................................16

Replacement Parts List ............................................................17

PACKAGE CONTENTS

PART DESCRIPTION QUANTITY

A Mounting Bracket (preassembled to Canopy [B]) 1

B Canopy (preassembled to Motor Assembly [C]) 1

C Motor Assembly 1

D Fitter Plate (preassembled to Motor Assembly [C]) 1

E Fitter Plate Screw (preassembled to Fitter Plate [D]) 3

F Light Pan 1

G Light Pan Screw (preassembled to Light Pan [F]) 3

H Light Kit 1

I Glass Bowl 1

J Blade 3

K Blade Arm (preassembled to Motor Assembly [C]) 3

L Remote Pack 1

M Mounting Bracket Scew (preassembled to Mounting Bracket [A]) 4

D E

HARDWARE CONTENTS (shown actual size)

Wire Connector

Qty. 1

+ 1 extra

Blade Screw

Qty. 9

+ 1 extra

Blade Washer

Qty. 9

+ 1 extra

Screw Cap

Qty. 9

+ 1 extra

AA BB CC LL

SAFETY INFORMATION

Please read and understand this entire manual before attempting to assemble, operate or install the

product.

• Before you begin installing the fan, disconnect the power by removing fuses or turning o󰀨 the circuit

breakers.

• Make sure all electrical connections comply with local codes, ordinances, the National Electrical

Code and ANSI/NFPA 70-199. Hire a qualied electrician or consult a do-it-yourself wiring

handbook if you are unfamiliar with installing electrical wiring.

• Make sure the installation site you choose allows a minimum clearance of 7 ft. from the blades to

the oor and at least 30 in. from the end of the blades to any obstruction.

• The net weight of this fan is: 16.34 lb (7,41 kg).

DANGER: When using an existing outlet box, make sure the outlet box is securely attached to

the building structure and can support the full weight of the fan. Failure to do this can result in serious

injury or death. The stability of the outlet box is essential in minimizing wobble and noise in the fan

after installation is complete.

WARNING: To avoid personal injury, the use of gloves may be necessary while handling fan

parts with sharp edges.

WARNING: Using a full-range dimmer switch to control fan speed will cause a loud humming

noise from the fan. To reduce the risk of re or electric shock, do NOT use a full-range dimmer switch

to control the fan speed.

WARNING: To reduce the risk of re, electric shock or personal injury, mount the fan to an

outlet box marked “ACCEPTABLE FOR FAN SUPPORT” and use the mounting screws provided with

the outlet box. Most outlet boxes commonly used for the support of lighting xtures are not acceptable

for fan support and may need to be replaced. Consult a qualied electrician if in doubt. Secure the

outlet box directly to the building structure. The outlet box and its support must be able to support the

moving weight of the fan (at least 35 lbs.).

WARNING: To reduce the risk of re, electrical shock or personal injury, wire connectors

provided with this fan are designed to accept only one 12-gauge house wire and two lead wires from

the fan. If your house wire is larger than 12-gauge and there is more than one house wire to connect

to the two fan lead wires, consult an electrician for the proper size wire connectors to use.

WARNING: To reduce the risk of re, electric shock or personal injury, do not bend the blade

arms when installing them, balancing the blades or cleaning the fan. Do not insert objects between

the rotating fan blades.

WARNING: To reduce the risk of personal injury, use only parts provided with this fan. The use

of parts OTHER than those provided with this fan will void the warranty.

SAFETY INFORMATION

CAUTION: Be sure the outlet box is properly grounded or that a ground (green or bare) wire is present.

CAUTION: Carefully check all screws, bolts and nuts on the fan motor assembly to ensure they are

secured.

CAUTION: This device complies with part 15 of FCC Rules. Operation is subject to the following

two conditions: 1) This device may cause harmful interference, and 2) this device must accept any

interference received, including interference that may cause undesired operation.

CAUTION: This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be determined by turning the

equipment o󰀨 and on, the user is encouraged to try to correct the interference by one or more of the

following measures:

--Reorient or relocate the receiving antenna.

--Increase the separation between the equipment and receiver.

--Connect the equipment into an outlet on a circuit di󰀨erent from that to which the receiver is

connected.

--Consult the dealer or an experienced radio/TV technician for help.

Please note changes or modications not expressly approved by the party responsible for compliance

could void the user’s authority to operate the equipment.

HKC-US

3350 Players Club Parkway, Suite 225

Memphis, TN 38125

1-888-251-1003

PREPARATION

Before beginning the assembly of this product, ensure that all parts are present. Compare all parts

with the package contents list and hardware contents list. If any part is missing or damaged, do not

attempt to assemble the product.

Estimated Assembly Time: 120 minutes

Tools Required for Assembly (not included): Electrical Tape, Phillips Screwdriver, Pliers, Safety

Glasses, Step Ladder, Wire Cutters and Wire Strippers

Helpful Tools (not included): AC Tester Light, Tape Measure and Wiring Handbook

INITIAL INSTALLATION

1. Turn o󰀨 the circuit breakers and the wall switch to the

fan supply line leads.

DANGER: Failure to disconnect the power supply

prior to installation may result in serious injury or death.

2. This fan is intended for Flushmount Installation.

Standard Mounting, Angle Mounting, and Closemount

installations are not available.

3. Ensure the blades (J) will be at least 30 in. from any

obstructions and will be at least 7 ft. above the oor. 3

Standard Mounting

Flushmount Closemount

Angle Mounting

7 ft. Min

30 in. Min

INITIAL INSTALLATION

4. Loosen all four mounting bracket screws (M), then

completely remove two mounting bracket screws (M)

from the round holes in the canopy (B). Set them

aside for later use. Remove mounting bracket (A) from

canopy (B).

5. Feed the supply wires from the outlet box through the

center hole in the mounting bracket (A). Then, secure

the mounting bracket (A) to the outlet box (not included)

using screws and washers provided with the outlet box.

CAUTION: It is very important you use the proper

hardware when installing the mounting bracket (A) as it

will support the fan.

Outlet Box

Round

Hole

WIRING

WARNING: To reduce the risk of re, electrical shock or personal injury, wire connectors

provided with this fan are designed to accept only one 12-gauge house wire and two lead wires

from the fan. If your house wire is larger than 12-gauge and/or there is more than one house wire to

connect to the two fan lead wires, consult an electrician for the proper size wire connectors to use.

CAUTION: Be sure the outlet box is properly grounded or that a ground (green or bare) wire is present.

1. Connect supply and fan wires according to the

diagram and these steps:

• Connect the Green wire from the mounting bracket

(A) to the Bare/Green (ground) supply wire.

• Push the White (neutral) supply wire into the

empty wire hole of the push-in wire connector

preassembled to the White wire from the receiver of

remote pack (L).

• Push the Black (hot) supply wire into the empty wire

hole in push-in wire connector preassembled to the

Black wire from the receiver of remote pack (L).

Note: The Black wire is hot power for the fan. The

White wire is neutral for the fan and light kit. The

Green wire is the ground wire. If supply wires are

di󰀨erent colors than referred to above, a professional

electrician should determine the proper wiring.

Hardware Used

AA Wire Connector x 1

2. Raise the fan and place the canopy (B) on the hook

on the mounting bracket (A). Connect the 3-pin

connector from the fan to the 3-pin connector from

the receiver. Important: Receiver should not come in

contact with hook on mounting bracket.

3. Wrap electrical tape (not included) around the wire

connector (AA) down to the wire.

Turn the spliced/taped wires upward and gently push

the wires and wire connector (AA) into the outlet box.

WARNING: Ensure no wire strands are visible

after making connections. Place the Green and White

wire connections on the opposite side of the outlet

box from the Black.

3-Pin

Connector

Receiver

White (neutral)

Bare/Green (ground)

Push-in

Connector

Black

Black (hot)

White

WARNING: Do NOT wire

the fan to a wall control.

FINAL INSTALLATION

1. Slide the canopy (B) over the mounting bracket (A),

aligning the slotted holes in the canopy (B) with the

previously loosened mounting bracket screws (M) in the

mounting bracket (A). Twist the canopy (B) clockwise

to lock. Then re-insert the mounting bracket screws (M)

(Step 4, page 8) and securely tighten all screws.

2. Attach the blades (J) to the blade arms (K) using the

blade screws (BB), blade washers (CC) and screw caps

(LL).

Hardware Used

BB Blade Screw x 9

CC Blade Washer x 9

Screw Cap x 9

3. Remove one and loosen the other two tter plate

screws (E) but do not remove from tter plate (D).

Feed the 9-pin connector through center hole in light

pan (F). Align the two key slots in the light pan (F) with

the loosened tter plate screws (E). Place the light

pan (F) over the two screws and turn the light pan (F)

clockwise. Then tighten the two tter plate screws (E).

Re-install the previously removed tter plate screw (E)

and tighten rmly.

9-pin connector

Key Slot

Slotted Hole

This manual suits for next models

Table of contents

Other Harbor Breeze Fan manuals

Harbor Breeze

Harbor Breeze Bath Ventilator with Light User manual

Harbor Breeze

Harbor Breeze KEYPORT HUGGER 40141 User manual

Harbor Breeze

Harbor Breeze MERRIMACK 40942 Manual

Harbor Breeze

Harbor Breeze Bath Ventilator with Light User manual

Harbor Breeze

Harbor Breeze CHESHIRE II User manual

Harbor Breeze

Harbor Breeze E-GAL52BC4GRS User manual

Harbor Breeze

Harbor Breeze FLANAGAN User manual

Harbor Breeze

Harbor Breeze 40048 User manual

Harbor Breeze

Harbor Breeze 80202 User manual

Harbor Breeze

Harbor Breeze JP18EB3 User manual

Harbor Breeze

Harbor Breeze BEACH CREEK TG44LW3D1RC User manual

Harbor Breeze

Harbor Breeze FWH60BNK3LRS User manual

Harbor Breeze

Harbor Breeze 40093 User manual

Harbor Breeze

Harbor Breeze BRADBURY BRD48BNK6LRS User manual

Harbor Breeze

Harbor Breeze CAF48BNK5L User manual

Harbor Breeze

Harbor Breeze 52 IN CLASSIC STYLE 40081 User manual

Harbor Breeze

Harbor Breeze RLG52NWZ5C3L Manual

Harbor Breeze

Harbor Breeze ARMITAGE CC52WW5C User manual

Harbor Breeze

Harbor Breeze PLM52CB5D User manual

Harbor Breeze

Harbor Breeze 872 User manual

Harbor Breeze

Harbor Breeze 40314 User manual

Harbor Breeze

Harbor Breeze BDB52BNK5L User manual

Harbor Breeze

Harbor Breeze BRISTLE AR13-44BLK AR13-44BN User manual

Harbor Breeze

Harbor Breeze LP8115LAZ User manual

Popular Fan manuals by other brands

ELTA FANS

ELTA FANS H03VV-F installation guide

Hunter

Hunter 20714 Owner's guide and installation manual

Emerson

Emerson CARRERA VERANDA CF542ORB00 owner's manual

Hunter

Hunter Caraway Owner's guide and installation manual

Panasonic

Panasonic FV-15NLFS1 Service manual

Kompernass

Kompernass KH 1150 operating instructions

VES

VES FALA100/12V/TR Original instructions

Vertiv

Vertiv Liebert DCD user manual

Westinghouse

Westinghouse GFP Series owner's manual

Venmar

Venmar KUBIX HRV PLUS Series user guide

Maico

Maico ECR 31 installation instructions

Sonnenkonig

Sonnenkonig Dinky instruction manual

S&P

S&P ECOWATT HXBR manual

Wider

Wider IMP03369BH instruction manual

Panasonic

Panasonic F-60DHN Operating and installation instructions

Hinkley

Hinkley HIGHLAND instruction manual

Broan

Broan 766BN installation guide

Premium

Premium PFS16022 Use manual
