Haier HWMP55-918 User manual

Fully Automatic Washing Machine User manual

This manual is for

HWMP55-918

Please read this manual

carefully before using.

Retain it for future

reference.

CONTENTS

CONTENTS I

Parts 1

Safety precautions 2

Installation and adjustment 4

Install the drain hose 5

Install the water inlet hose 6

Preparation before washing 7

Detergent

peration 9

Trouble-shooting 15

Packing list 17

Specification

nside cover

Load the laundry 8

Cycle completed

Maintenance

Back page

Drain connector

Control pannel

Inner tub

Detergent box

Top lid

Balance ring

Lint filter

Pulsater

Front control

board

Cabinet

Adjustable leg

Fixed leg

(2 pieces)

Instruction for adjustable leg

Back cover

Parts

Contents marked with this symbol are related to the

safety of the product and the personal safety of the

users. Please operate in strict conformity to the

contents, otherwise it may cause damage of the

machine or injure the personal safety of the user.

Contents marked with this symbol are actions forbidden.

Performing of those actions may result in damage of

the machine or injure the personal safety of the user.

Meaning and description of symbols

Warning sign

Forbidden sign

Power cord

Cold water valve Hot water valve

Handle

Drain hose

Screw cover

Back

cover

(2pieces)

Please check if power

condition before using to guarantee your safety

point has been earthed

Safety precautions

The ventilation

holes at the bottom

Soft object

Back

Front

A separate earthed socket is required

for the power supply.Hold the plug

not the electric cable when

unplugging the washing machine.

Do not insert or remove the power

plug with wet hands.

After installation of the washing

machine, the power plug should

be accessible. Ensure the plug is

removed and the taps turned off

in the following cases:power

failure, cleaning, moving,

installation and when not in use.

Do not block the ventilation holes with

carpet Ensure carpet does not obstruct

the apening in the base

Safety precautions

Install the bottom plate

Please install and adjust the machine according to the requirement of

the manual. It is very important to your

operating the machine.

safety and the correct

Installation and adjustment

The largest allowable slope of the base of the machine is 2 .

Slanting or rough ground will result in unstable running or stoppage of the

machine. Please adjust it by the following method:

Confirm it is level

Adjust the adjustable leg:

Adjust the position

1 .To twist the adjustable leg, please first

lift up the side of the leg slightly, loosen

the adjustable nut, and twist the leg.

2 .After adjustment, fasten the nut.

After opening the package, please take out the lint

filter from the document bag, install it to the inner

tub. See the figure opposite.

Install the lint filter

Inner tub

Lint filter

Back

Front

Soft object

Screw

Bottom plate

Fasten

Loosen

High Low

adjustable nut

Adjustable

feet

The purpose of the bottom plate is to block noise

and give a quiet performance from the washing

machine during operation.

Steps:

1. Lay the washer on its back.

2. Place the plate on to the bottom of the machine.

3.Use a screwdriver to tighten the screws securing

the panel to bottom of the washer.

4.Once all screws are tight and the panel is secure return

the washer to its standing position.

Please ensure the lint filter is installed correctly and in

good condition to ensure the water outlet is not blocked

or the flow altered. If the lint filter is lost please contact

the local after -sales service department.

Install the drain hose

First install the drain hose hook on the part of

outer drain hose component.

Put the drain hose clamp on the outer drain hose,

Insert the outer drain hose into the joint for it, and

then clutch tightly with drain hose hoop.

Drain hose neck

Drain hose joint

Drain hose hoop

4.Usage of the drain hose-4

0.8m h 1.2m

Ensure the drain hose is mounted at a suitable height.

( above the floor).

Do not it too far down the drain pipe or will occur.

Between 800-1200mm

push siphoning

Install the water inlet hose

1. Insert a new flat washer into each end of the inlet hose. Firmly put the

washers in the coupling.

2. Connect the water inlet hose to the water faucet.

Use the new hose supplied with the washer.

Any other old hoses should not be used.

You may have to use pliers to tighten the coupling.

Do not overtighten because you may cause

damage to the valve.

Note:

3. Connect the other ends to their respective cold and hot water inlet valve

located at the rear of the washer

Check the connection between the

water inlet hose and the water tap

1.Close the water tap.

2. Remove the water inlet hose from the water tap and washer.

Remove the water inlet hose

Install the water inlet hose

4.Fasten the nut. Swing the hose gently to confirm that the hose is

securely fastened.

1.Swing the hose gently to confirm that the hose

is securely fastened.

2.After installation, open the tap to check for leaks..

3.Do not bend the hose unduly.

4.Before every use check the hose connections are

firm at both ends. This is to ensure the connections

remain firm over time.

Water absorption cushion

Nut of the water inlet hose

to Joiner of the water inlet valve

Use the new hose supplied, do not reuse old hoses.

1.Preparation before washing

Preparation before washing

1. Connect the water inlet hose.

2. Inset the power plug into the electrical socket.

3. Ensure the drain hose is mounted at the correct height.

4. Select a suitable location for the washer on a hard, even

surface away from direct sunlight or heat sources, e.g.

radiators, cooking

appliances etc.

5. Any floor unevenness may

result in unstable working

or abnormal noise. Please

ensure the machine is level.

Check the following before washing

Check if the

laundry has

any special

washing

instructions

Clear the

pockets. Take

out loose items

such as coins,

sand, hairpins

etc.

Tie any long

strips, fasten

buttons and

close zippers.

When the machine

is running buttons

may cause noise.

To reduce the noise

turn clothes inside

out or place them in

a laundry bag.

The weight of

the laundry shall

not exceed the

rated capacity.

Loosen the laundry

before placing it

evenly in the tub.

a. Check if the laundry is suitable for machine washing.

b. Divide the laundry into colour fast and non-colour fast items.

c. Place items that do not absorb water easily into the water by hand.

d. For heavily soiled items, please first remove loose dirt, then apply detergent

directly to the stain before washing.

e. For those items that may get lint or are furry or fluffy, please turn them inside out

before washing

f . Do not put laundry polluted by chemicals into the washing machine.

0.8m H 1.2m

2.Load the laundry

The rated washing capacity refers to the largest dry weight of a

load that can be washed.

The thickness, size and type of clothes will influence the actual

capacity. Be careful to only load a reasonable amount of laundry.

Do not select more than 4 water level for clothes less than

1.0kg, to avoid splashing of water

It is suggested not to use high sudsing detergent.Choose a low

suds or high efficiency detergent.

3. Detergent

If you open the lid during spinning the machine will stop and an alarm

will sound.

4. Close the lid

Adding washing powder

Washing powder with poor quality or long-time

storage may get caked. Please clean the detergent

box periodically.

Dissolve directly inside the washing machine: (not

applicable for fuzzy and reserve program)

1.Add some water(select the

2.Add washing powder. Run for about 30s to fully

dissolve the powder. Then push the"start/pause"

button.

3.Put in laundries. Select suitable water level. Push

the "start/pause"button again.

" L " water level)

It is not recommended to use rich-foam washing

powder.

If you select save program, it is suggested to use

liquid detergent instead of washing powder to

guarantee the washing effect.

Please add suitable washing powder as per the

laundries quantity, then set water level and water quantity.

Add washing powder into the box directly under

fuzzy program and reserve program.

It is suggested to

1.Prepare warm water of 35 C and container.

2. Add washing powder while stirring to dissolve it

completely.

dissolve the detergent before you put

them into the tub, see as below:

How to use whitener

Fill water to desired level.

Dilute the whitener in a

container. Pour it slowly

into the washing tub.

Avoid using whitener on

laundry with color or pattern

as they are prone to lose

color.

The whitener shall not touch

the laundry directly.

Refer to the whitener

instructions for the usage

and quantity.

For powder whitener,please

dissolve it before using .

Note: For thebetter wash performance, please use lowing

sudsing or hignefficiency detergent andplease dissolve

the detergent in1L warm waterfirst
