Miele PW 6080 Vario User manual
Washer-extractorCommissioning,
Programmechart,Settings
PW6080VarioL@
To avoid the risk of accidents or
damage to the machine it is
essential to read these instructions
before it is installed and commissioned. M.-Nr. 09 343 070
en-GB
Commissioning the machine ........................................4
Programme chart .................................................11
Basic programmes ................................................11
Household .......................................................15
Sport ...........................................................15
Hotel............................................................16
Bedding .........................................................17
Disinfection ......................................................18
Maintenance programme ...........................................18
Hygiene .........................................................19
Sluice (AV machines only) ...........................................19
Bakers/Butchers ..................................................20
Beauty salons/Health spas ..........................................21
Buildings maintenance (AV machines only) .............................22
Fire service ......................................................25
Professional cleaners...............................................27
Equestrian (AV machines only) .......................................28
Special programmes ...............................................29
Relay control for external dispensing system .........................30
Changing default settings..........................................35
Settings menu J..................................................36
To open the Settings menu ..........................................36
Settings/Supervisor level menu .....................................37
To open the Settings/Supervisor level menu .............................37
Language J......................................................39
Sort languages....................................................39
Suds cooling .....................................................39
Time of day ......................................................40
Supervisor level ..................................................40
Display contrast / Display brightness ..................................40
Standby .........................................................41
Memory .........................................................41
Temperature unit ..................................................41
Special programmes ...............................................42
To create a special programme ....................................42
Favourites .......................................................45
Contents
2
Logo............................................................45
Language menu...................................................45
Intensive water plus ................................................46
Water plus .......................................................46
Save ............................................................46
Auto load control ..................................................46
Pre-wash water ...................................................46
Main wash water ..................................................47
Rinse water ......................................................47
Low water pressure ................................................47
MOPS pre-spin (AV machines only) ...................................47
MOPS final spin (AV machines only) ...................................47
Standard finish (AV machines only)....................................48
Disinfection finish (AV machines only)..................................48
Empty sensor .....................................................48
Water level Cottons ................................................48
Water level Min. iron ...............................................48
Pre-wash temp. Cottons ............................................48
PW duration Cottons ...............................................49
Wash time Cottons.................................................49
Wash time Min. iron ................................................49
Target groups ....................................................49
Pre-wash ........................................................50
No. rinses Cottons .................................................50
No. rinses Minimum iron ............................................50
Pre-rinse Cottons ..................................................50
Pre-rinse Minimum iron .............................................50
Spin free of charge ................................................50
Coin mechanism lock ..............................................51
Demo programme .................................................51
No deterg. .......................................................51
Temp. reduction...................................................51
Controls .........................................................52
Delay start .......................................................52
Settings which can only be changed during the commissioning process ......53
Payment system ................................................53
Supervisor level code ............................................53
Contents
3
Before using for the first time
,Before commissioning the machine, ensure that it is
correctly installed and connected. Please follow the
operating and installation instructions.
,Commissioning must be completed to determine the
settings for daily operation.
Certain settings can only be altered during the
commissioning process. After that, these can only be
changed by a Miele service technician.
Setting the language J
Settings
Language F#eština
dansk
deutsch
english H
^Turn the multi-function selector to highlight the language of
your choice.
^Press the multi-function selector to confirm your choice of
language.
Use this language?
OK
H
Back A
H
^Turn the multi-function selector to select OK, and confirm
by pressing the multi-function selector.
If you wish to select a different language:
^Select and confirm Back.
Commissioning the machine
4
To set the time of day
The time may already have been set at the factory. If it has,
and is correct, you can skip this section. It is possible to alter
the time at any stage via the Settings menu.
Settings
Time of day
24 h clock...
12 h clock...
Time not displayed
^Confirm either 24 h or 12 h. If you confirm Time not
displayed, the following step will be skipped.
9:00
Set the time of day
^Turn the multi-function selector to select the hour and press
it to confirm your selection.
^Then set the minutes.
^Pressing the multi-function selector again saves the time of
day in memory.
Commissioning the machine
5
Determining target groups
By selecting target groups, you are determining the
programme range of the washer-extractor. You can see
which programmes are assigned to each target group
under "Programme chart" later in this booklet.
Settings
Target groups
§Professional cleaners V
~Equestrian
~Special programmes
Confirm selection
^Use the multi-function selector to select and confirm none,
one or several of the target groups, as required.
The 16 permanent basic programmes are always displayed
and cannot be deselected.
– A target group selected will be indicated with a tick: 9.
– Mark the target group programmes that you have selected
with a cross in the box 8.
8Household
8Sport
8Hotel
8Bedding
8Disinfection
8Maintenance programme
8Hygiene
8Sluice high (AV machines only)
8Bakers/Butchers
8Beauty salons/Health spas
8Buildings maintenance (AV machines only)
8Fire service
8Professional cleaners
8Equestrian (AV machines only)
8Special programmes
Only once you have made your selection, select Confirm selection
and press the multi-function selector to confirm your choice.
In the following text:
AV machines: Version with dump valve
LP machines: Version with drain pump
Commissioning the machine
6
Each of these settings must now be
confirmed (and altered if required).
More details about the settings are
given at the end of this booklet.
Place a cross in the box 8to
indicate your selection and fill in the
gaps _____ as required.
Pre-wash water
This setting establishes the temperature
of the water for the pre-wash.
^Select either:
8Cold
The washer-extractor is only
connected to a cold water supply. Or
8Hot
The washer-extractor is connected to
hot and cold water supplies.
Main wash water
This setting establishes the temperature
of the water for the main wash.
^Select either:
8Cold
The washer-extractor is only
connected to a cold water supply. Or
8Hot
The washer-extractor is connected to
hot and cold water supplies.
See the paragraph "Water
connection" in the "Installation and
connection" section of the Operating
and installation instructions.
Set contrast
The contrast for the display can be set
in 10 steps.
^Select the contrast for the display.
Step _____ (1 to 10)
Set brightness
The brightness for the display can be
set in 10 steps.
^Select the brightness for the display.
Step _____ (1 to 10)
Payment system
Setting for coin-operated machines.
^Select the option you require.
8No coin box
The Coin mechanism lock setting for
operating the machine with a coin
box is skipped.
8Programme operation
The machine is operated using a
coin box.
8Timed operation
The machine is coin-operated using
a time meter.
Commissioning the machine
7
8IK6
Serial interface RS 232 for Interface
card 6 is active in coin operation
mode (an IK6 module must be fitted).
8RS 232
Serial interface RS 232 is active
when the machine is operated with
coins (an RS 232 module must be
fitted).
Coin mechanism lock
The Coin mechanism lock setting
determines when the door is locked
when operated with a coin box after the
start of the programme.
^Select the option you want.
8Immediately
The machine locks straight away.
8In 3 minutes
The machine will lock after a period
of 3 minutes (default setting)
8As soon as cancelled
The machine locks straight away.
Cancel will appear in the display if
the start button is held in for 4
seconds. You can then cancel the
programme in the next 3 minutes.
83 min. after cancelling
The machine will lock after a period
of 3 minutes. Cancel will appear in
the display if the start button is held
in for 4 seconds. You can then
cancel the programme in the next 3
minutes.
Supervisor level code
The Settings/Supervisor level can be
locked with a code to prevent it being
accessed by unauthorised personnel
(the Language Jsetting can still be
altered).
^Select the option you want.
8Code not required
Only some of the settings can be
changed (temporary Language
setting, Suds cooling, Time of day,
contrast, brightness, standby,
memory and temperature unit).
These settings can be changed by
any user.
Other settings can only be changed
by a Miele Service Technician.
8Code required
A code (000) must be entered in
order to change the settings. All
settings (see Settings menu) can be
changed.
Select this option if you only want
users to be able to change settings
via a code.
The Language setting can be
changed temporarily by any user.
Commissioning the machine
8
Transport struts
A message will appear in the display to remind you to remove
the transport struts.
^Remove them (if this has not already been done by your
fitter). Then press the multi-function selector to confirm that
this has been done.
To repeat the commissioning process
If you are not certain that all of the settings are correct, you
will need to repeat the commissioning process.
Set up successful
i
OK
H
Back A
H
^Select Back and confirm your selection.
The commissioning process must then be repeated.
To finish the commissioning process
–1. Confirm
If you are sure that all of the settings are correct.
Set up successful
i
OK
H
Back A
H
^Confirm with OK.
The entry menu will appear.
Commissioning the machine
9
1 Cottons Uni. 60°C Programme selection...
2 Minimum iron 40°C Settings F...
3 Delicates 40°C
4 Woollens H30°C 15:00
To finish the commissioning process completely, a first wash
programme must be started.
If the power to the machine is switched off before the first
wash programme is started (e.g. by pressing the K
button), the commissioning process can be carried out
again. Once a wash programme that is longer than 20
minutes has been run, it is not possible to carry out the
commissioning process again.
–2. Start the first wash programme
For safety reasons, spinning is not possible until the first
wash programme has been run. To activate the spinning
function and to complete the commissioning process, you
must run a wash programme without laundry and without
detergent.
^Open the stopcocks.
^Select Cottons 60°C and confirm your selection.
The main menu for Cottons Universal will then appear.
^Press the flashing Start button.
After this programme has finished, the washer-extractor is
ready for processing laundry.
Commissioning the machine
10
Other manuals for PW 6080 Vario
1
Table of contents
Other Miele Washer manuals
Miele
Miele PW 6321 EL User manual
Miele
Miele W 1215 User manual
Miele
Miele PWM 916 SD User manual
Miele
Miele WWB 020 User manual
Miele
Miele W 3652 WPS User manual
Miele
Miele 11653560 User manual
Miele
Miele PG 8583 WW ADP LD User manual
Miele
Miele W 1945 Operating manual
Miele
Miele WCI 860 User manual
Miele
Miele W 377 WPS User manual
Miele
Miele G 7825 User manual
Miele
Miele PW 6241 D User manual
Miele
Miele NOVOTRONIC W 1612 User manual
Miele
Miele PW 6163 EL/D User manual
Miele
Miele W 4446 WPS User manual
Miele
Miele SUPERTRONIC User manual
Miele
Miele W 916 User manual
Miele
Miele SoftTronic W 418 User manual
Miele
Miele G 7883 User manual
Miele
Miele W 3444 WPS User manual
Popular Washer manuals by other brands
Tricity Bendix
Tricity Bendix AW 1000 W Operating & installation instructions
Panasonic
Panasonic NA-F60L5WRB operating instructions
GE
GE WSLP1500 Dimensions and installation information
Electrolux
Electrolux EWF1284EDW Service manual
Bosch
Bosch WAN2829BSN User manual and installation instructions
LG
LG TV2516DV3B owner's manual
