Haier HLP21N User manual

User Manual

HLP21

Guide de l’Utilisateur

Manual del Usuario Modelo

Quality ßInnovation ßStyle

HLP21

User Manual

HLP21

Guide de l’Utilisateur

Manual del Usuario Modelo

Quality ßInnovation ßStyle

HLP21

Space-Saving Portable Compact

Laveuse électronique portative

compacte à chargement par le

Lavadora electrónica con carga

superior, compacta y portátil

para el ahorro de espacio

Load Washe

Electronic 1 cubic Ft.

Top

de 1 pie cúbico

haut 1 p.i3/28 litres

DANGER

Risk of child entrapment. Before throwing away your old

appliance, remove the door so that children may not easily

become trapped inside.

Thank you for purchasing our Haier

product. This easy-to-use manual will

guide you in getting the best use of

your washer.

Remember to record the model and

serial number. They are on a label in

back of the washer.

UNPACKING YOUR WASHING MACHINE

English

1. Inspect and remove all packing materials. This includes the foam and any

adhesive tape both inside and outside of the unit.

2. Inspect and remove any remains of packing, tape or printed materials before

powering on the Washer.

PRODUCT REGISTRATION

Staple your receipt to your manual.

You will need it to obtain warranty service.

Please register your product online at www.prodregister.com/haier

Model number

Serial number

Date of purchase

IMPORTANT SAFETY

INSTRUCTIONS

Warning – To reduce the risk of fire, electric shock, or injury

to persons when using your appliance, follow basic

precautions, including the following:

1. Read all instructions before using the appliance.

2. Use this appliance only for its intended purpose as described in this use and

care guide.

3. Use only detergents or softeners as recommended for use in this manual and

keep them out of the reach of children.

4. This appliance must be properly installed in accordance with the installation

instructions before it is used.

5. Never unplug your appliance by pulling on the power cord. Always grasp

the plug firmly and pull straight out from the outlet.

6. Replace immediately any worn power cords, loose plugs and power outlets.

7. Unplug your appliance before cleaning or before making any repairs.

8. If your old appliance is not being used, we recommend that you remove the

door. This will reduce the possibility of danger to children.

9. Do not operate your appliance in the presence of explosive fumes.

10. Do not use this appliance to wash clothes that have been soaked, spotted or

washed in gasoline, dry cleaning solvents or any other explosive or

flammable substances that may ignite and explode.

11. Clothes or rags used to clean flammable or explosive materials should not be

washed in this appliance until all traces of this material have been removed.

12. Do not add or mix any flammable or explosive substances to the wash.

13. Do not try to remove clothes while the tub is moving. Allow it to come to a

complete stop before reaching in.

14. The appliance’s loading door must be closed when the tub is spinning.

15. Do not operate your appliance when parts are missing or broken.

16. Do not use this appliance for commercial uses.

17. Do not operate this appliance unless all enclosure panels are properly in

place.

18. Do not tamper with controls.

19. To reduce the risk of injury, do not allow children to play in or on the

appliance. Close supervision of children is necessary when the appliance is

used near children. 2

English

20. This appliance must be connected to a proper electrical outlet with the

correct electrical supply.

21. Proper grounding must be ensured to reduce the risk of shock and fire. DO

NOT CUT OR REMOVE THE GROUNDING PLUG. If you do not have a

three-prong electric receptacle outlet in the wall, have a certified electrician

install the proper receptacle. The wall receptacle MUST be properly

grounded.

22. Hydrogen gas may be produced if the water heater has not been used in

more than 2 weeks. This may be explosive under certain circumstances.

If this is the case turn on all the hot faucets and let the hot water run for a

few minutes before using this appliance. This will let the trapped hydrogen

escape. Avoid accidents during this process by refraining from turning

ON any electrical appliances, smoking, lighting a match/lighter, or using

flames.

23. Do not repair or replace any part of the appliance or attempt any servicing

unless specifically recommended in the user-repair instructions, which you

understand and have the skill to carry out.

If for any reason this product requires service, we strongly

recommend that a certified technician perform the service.

24. To reduce the risk of electric shock or fire, do not use extension cords or

adapters to connect the unit to an electrical power source.

SAVE THESE INSTRUCTIONS

HOUEHOLD USE ONLY

English

Note:

Tools and Materials Required

You will need to use the following tools when installing your washer:

1. Phillips Screwdriver - For bottom plate

3. Level - To balance washer

1 2 3 4

4. Open End Plyers - To secure ntake hose

ion

2. Tape Measure - Check measurement of washer locat

English

SAFETY INSTRUCTIONS

Avoid fire hazard or

electric shock. Do not use an extension

cord or an adapter plug. Do not remove

any prong from the power cord.

Do not, under any

circumstances,

cut, remove,

or bypass the

grounding prong.

Grounding type

wall receptacle

Power supply

cord with 3-prong

grounding plug

Electrical Requirements

Grounding Instructions

This appliance must be grounded. It is equipped with a 3-wire cord having

a grounded plug. The plug must be plugged into an outlet which is properly

installed and grounded.

Warning! Improper use of the grounded wire can result in the risk of electric

shock. Consult a qualified electrician if necessary. Do not attempt to defeat this

safety feature by modifying the plug.

Avoid the use of an extension cord because it may overheat and cause a risk of

fire. However, if it is necessary to use an extension cord:

A. Use only 3-wire extension cord with 3-blade grounding plug.

B. The marked rating of the extension cord must be equal to or greater

than the rating of this appliance.

C. It should be positioned such that it does not drape over the counter

or tabletop where it can be pulled on children or tripped over.

Attempting any maintenance or cleaning:

To minimize the possibility of electric shock, unplug this appliance from the power

supply or disconnect the dryer at the household distribution panel by removing the

fuse or switching off the circuit breaker before attempting any

maintenance or cleaning (except the removal and cleaning of the lint filter).

Pressing the Power ON/OFF button to an off position or pressing Start /

PAUSE button, does NOT disconnect the appliance from the power supply.

Wiring Requirements

• This appliance must be plugged into at least a 15 AMP

110-120 VOLT 60 HZ GROUNDED OUTLET.

WARNINGS:

Note:

PAGE

UNPACKING YOUR WASHING MACHINE.................................. 1

IMPORTANT SAFETY INSTRUCTIONS.......................................2-4

UNPACKING AND CHECKING PARTS......................................... 6

WASHER PARTS AND FEATURES................................................. 7

CONTROL PANEL ......................................................................... 8

OPERATING YOUR WASHER.....................................................15

CHOOSING A CYCLE ................................................................. 18

PROPER CARE AND CLEANING ................................................ 21

TROUBLESHOOTING GUIDE ......................................................22

WARRANTY................................................................................24

English

TABLE OF CONTENTS

INSTALLATION INSTRUCTIONS .................................................10

Unpacking

1. Remove all packing materials. This includes the foam base and all adhesive

tape holding the washer accessories inside and outside. Slide out and remove

the bottom Styrofoam that is used to protect the washer from shipping damage

due to vibrations and shock.

2. Inspect and remove any remaining packing, tape or printed materials before

using the washer.

The bottom panel is located between the top foam used for

protection and box.

abcd

Check to make sure that the accessories are present and in

good condition. If you find that they are not in good condition

or are missing, please contact our customer service department

for assistance. Our Toll-Free number is

1-877-337-3639.

English

UNPACKING AND CHECKING PARTS

Parts

a) 1 Bottom Panel

c) 1 Water Inlet Hose

d) 1 Drain Hook (Gooseneck)

1 Quick Sink Faucet Adapter

Note:

FRONT

FACE TO FLOOR

Optional Caster

Wrench

Optional 4 Pack

g) Optﬁonal 4 Casters

h) Caster wrench

2 Locki

6 Screws for the Bottom Plate ng ands

Quick Sink

Faucet

Adapter

Silver Faucet

Connector

f )

2. Control Panel

3. Washer Cabinet

5. Cabinet Handle (located on both

sides of the washer)

6. Water Inlet Fitting

7. Rubber Washer

Drain Hose

10. Water Inlet Hose

Power Cord (120 Volt / 60 Hz)

WASHER PARTS AND FEATURES

Front View

Back View

English

4. Front Level ng Leg1. Top Lid i

English

CONTROL PANEL

Choose washing cycle

Normal - Normal Wash

Heavy - Huge and heavy garments

Quick Wash - Small wash loads that are slightly soiled

Indicates cycle chosen with stages of cycle in operation.

With Power "ON" Press the "Start/Pause" button to start washing cycle, pause

operation, or resume operation.

Press in the "Power On/Off" button to turn on the power of the washer.

Select water height in drum based on laundry being washed.

STAT US

QUICK WASH NORMAL

WASH RINSE

SPIN

POWER

ON/OFF

START

PAUSE

CYCLE

HIGH

HEAVY

WATER

LEVEL

MEDIUM

LOW

HLP21N

Water Level

Button

Power ON/OFF

Start/Pause Button

Cycle Button

Status In icator Lights

yltceridro,gnitttcennockciuQehtgnisu,esohtelniretawehttcennoC.3

connect to faucet.

.kooHniarDehtgnisuk

nisehtedisnironiardniesohniardecalP.4

.murdehtfoedisehtnodellatsnisitI.ecalpnisi

retltnilehterusekaM.5

aotnidrocrewopgulpneht,rehsawehtnisignihtolctubgnihtonerusnE

15 AMP 110-120 VOLT, 60 HZ GROUNDED OUTLET ONLY.

7. Proceed by pressing the "POWER ON" button.

8. Select water height.

ehtsserpneht,nottub”ELCYC“ehtgnisugnihsaw”LAMRON“tceleS.9

"START" button.

Power

English

NORMAL

WASH

WATER

LEVEL

START

PAUSE

LAMRONROFSNOITCURTSNIPU-TESKCIUQ

WASH

.rehsawelbatroptcapmocWENruoygnisurofecalptsebehtetacoL.1

Make sure it is near a 120 volt outlet and a water source, like a sink,

with a drain.

FRONT

FACE TO FLOOR

CYCLE

Sink Faucet

Quick Sink

Faucet

Adapter

Silver Faucet

Connector

Washer

Water inlet hose

Drain hose

Rear View of Washer

Drain

Hook

SINK

2. Screw on the bottom plate with the six (6) screws provided.

Other manuals for HLP21N

Table of contents

Languages:

Other Haier Washer manuals

Popular Washer manuals by other brands

Tricity Bendix

Tricity Bendix AW 1000 W Operating & installation instructions

Panasonic

Panasonic NA-F60L5WRB operating instructions

GE WSLP1500 Dimensions and installation information

Electrolux

Electrolux EWF1284EDW Service manual

Bosch

Bosch WAN2829BSN User manual and installation instructions

LG TV2516DV3B owner's manual

LG TH2517DSAV owner's manual

VESTEL

VESTEL CMH-XL 7510 TE user manual

AEG

AEG 74335 User information

Johnson

Johnson JWF721A user manual

Beko

Beko WTE7604XLW0 owner's manual

Danby

Danby DTT100A1WDB Owner's use and care guide

Amica

Amica WA 14 Ex operating instructions

Daewoo

Daewoo DWD-F1222 instruction manual

Bosch

Bosch WAS28461AU instruction manual

Miele

Miele PW 6080 Vario manual

Finlux

Finlux FLX108CF220 user manual

Whirlpool

Whirlpool 3LBR5132AN0 Use and care guide
