Fluke 985 User manual
PN 4136462
March 2012
© 2012 Fluke Corporation. All rights reserved. Printed in U.S.A. Specifications are subject to change without notice.
All product names are trademarks of their respective companies.
985
Airborne Particle Counter
Getting Started
LIMITED WARRANTY AND LIMITATION OF LIABILITY
Each Fluke product is warranted to be free from defects in material and workmanship under normal use and service. The warranty period is one year
and begins on the date of shipment. Parts, product repairs, and services are warranted for 90 days. This warranty extends only to the original buyer or
end-user customer of a Fluke authorized reseller, and does not apply to fuses, disposable batteries, or to any product which, in Fluke's opinion, has
been misused, altered, neglected, contaminated, or damaged by accident or abnormal conditions of operation or handling. Fluke warrants that
software will operate substantially in accordance with its functional specifications for 90 days and that it has been properly recorded on non-defective
media. Fluke does not warrant that software will be error free or operate without interruption.
Fluke authorized resellers shall extend this warranty on new and unused products to end-user customers only but have no authority to extend a
greater or different warranty on behalf of Fluke. Warranty support is available only if product is purchased through a Fluke authorized sales outlet or
Buyer has paid the applicable international price. Fluke reserves the right to invoice Buyer for importation costs of repair/replacement parts when
product purchased in one country is submitted for repair in another country.
Fluke's warranty obligation is limited, at Fluke's option, to refund of the purchase price, free of charge repair, or replacement of a defective product
which is returned to a Fluke authorized service center within the warranty period.
To obtain warranty service, contact your nearest Fluke authorized service center to obtain return authorization information, then send the product to
that service center, with a description of the difficulty, postage and insurance prepaid (FOB Destination). Fluke assumes no risk for damage in transit.
Following warranty repair, the product will be returned to Buyer, transportation prepaid (FOB Destination). If Fluke determines that failure was caused
by neglect, misuse, contamination, alteration, accident, or abnormal condition of operation or handling, including overvoltage failures caused by use
outside the product’s specified rating, or normal wear and tear of mechanical components, Fluke will provide an estimate of repair costs and obtain
authorization before commencing the work. Following repair, the product will be returned to the Buyer transportation prepaid and the Buyer will be
billed for the repair and return transportation charges (FOB Shipping Point).
THIS WARRANTY IS BUYER'S SOLE AND EXCLUSIVE REMEDY AND IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED,
INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. FLUKE
SHALL NOT BE LIABLE FOR ANY SPECIAL, INDIRECT, INCIDENTAL, OR CONSEQUENTIAL DAMAGES OR LOSSES, INCLUDING LOSS OF
DATA, ARISING FROM ANY CAUSE OR THEORY.
Since some countries or states do not allow limitation of the term of an implied warranty, or exclusion or limitation of incidental or consequential
damages, the limitations and exclusions of this warranty may not apply to every buyer. If any provision of this Warranty is held invalid or
unenforceable by a court or other decision-maker of competent jurisdiction, such holding will not affect the validity or enforceability of any other
provision.
Fluke Corporation
P.O. Box 9090
Everett, WA 98206-9090
U.S.A.
Fluke Europe B.V.
P.O. Box 1186
5602 BD Eindhoven
The Netherlands
11/99
i
Table of Contents
Title Page
Introduction ....................................................................................................................1
How to Contact Fluke .....................................................................................................1
Safety Information ..........................................................................................................2
Battery............................................................................................................................3
Product Overview...........................................................................................................3
The Buttons ...............................................................................................................5
Product Connections .................................................................................................6
Charge Base Connections.........................................................................................7
Product Test ..............................................................................................................8
How to Purge the Product Sensor .............................................................................8
How to Take a Sample ..............................................................................................8
Navigation Menu........................................................................................................9
Sample Setup Submenus..........................................................................................9
Communication Setup Submenus .............................................................................10
Sample Screen Menu ................................................................................................10
985
Getting Started
ii
Maintenance .................................................................................................................. 11
Specifications ................................................................................................................ 12
General ..................................................................................................................... 12
Environmental ........................................................................................................... 13
1
Introduction
The Fluke 985 Airborne Particle Counter (the Product) is
a portable instrument that measures and reports air
contamination.
The Product stores 10,000 samples in memory and
records the date, time, counts, and sample volume of
each sample.
Use the supplied USB cable, an Ethernet connection, or a
flash USB drive (not supplied) to download data to a PC.
See the 985 Users Manual on the Product CD for
complete use instructions.
How to Contact Fluke
To contact Fluke, call one of the following telephone
numbers:
•Technical Support USA: 1-800-44-FLUKE
(1-800-443-5853)
•Calibration/Repair USA: 1-888-99-FLUKE
(1-888-993-5853)
•Canada: 1-800-36-FLUKE (1-800-363-5853)
•Europe: +31 402-675-200
•Japan: +81-3-6714-3114
•Singapore: +65-6799-5566
•Anywhere in the world: +1-425-446-5500
Or, visit Fluke's website at www.fluke.com.
To register your product, visit http://register.fluke.com.
To view, print, or download the latest manual supplement,
visit http://us.fluke.com/usen/support/manuals.
985
Getting Started
2
Safety Information
*XWWarning
To prevent possible electrical shock, fire, or
personal injury:
•The Product contains a laser device and
a rechargeable lithium battery pack. Do
not disassemble this Product, it contains
no user-serviceable parts.
•Do not use, and disable the Product if it
is damaged.
•Use the Product only as specified or
hazardous laser radiation exposure can
occur.
•Do not open the Product. The laser beam
is dangerous to eyes. Have the Product
repaired only by an approved technical
site.
•Do not look directly into the laser with
optical tools (for example, binoculars,
telescopes, microscopes). Optical tools
can focus the laser and be dangerous to
the eye.
•Do not use the Product if it operates
incorrectly.
•Read the entire Users Manual before
using the Product.
Table 1 tells you about symbols used on the Product and
in this manual.
Table 1. Symbols
Symbol Description
W Risk of Danger. Important information.
See Manual.
XHazardous voltage. Risk of electrical
shock.
~
Do not dispose of this product as
unsorted municipal waste. Go to Fluke’s
website for recycling information.
PConforms to European Union directives.
*Warning. Laser.
;Conforms to relevant Australian
standards.
´
This product contains a Lithium-ion battery.
Do not mix with the solid waste stream.
Spent batteries should be disposed of by a
qualified recycler or hazardous materials
handler per local regulations. Contact your
authorized Fluke Service Center for
recycling information.
Airborne Particle Counter
Battery
3
Battery
After you unpack and examine the Product, fully charge
the battery before the first use. After the initial charge,
charge the battery when the battery icon on the screen
shows that battery power is low.
To charge the battery:
1. Put the Product on the Charge Base.
2. Connect the ac adapter to a power source.
3. Connect the ac adapter to the dc input socket on the
Charge Base.
An amber light on the front of the Charge Base shows
that the base is powered. The light changes to green
when the Product is connected to the base.
If the ac adapter cord is connected to the Product, a
green light shows above the power jack.
If the Product is on, the battery icon flashes as the battery
charges. The icon is solid (does not flash) when the
battery is fully charged. Approximately 3.5 hours is
necessary to charge a discharged battery. The battery is
not user-serviceable.
Product Overview
See Figure 1 and Table 2 to see the items that are
shipped with the Product.
985
Getting Started
4
1
2
7
8
9
10
6
12
11
3
4
5
gud003.eps
Figure 1. Product Components
Airborne Particle Counter
Product Overview
5
Table 2. Product Components
Item Description
AThe Product
BZero-Count Filter
CFilter Adapter
DProbe Cap
EProduct Charge Base
FUSB Cable
GEthernet Cable
HAC Adapter
IInternational Power Plug Adapters
J985 Getting Started
K985 User Manual CD
LProduct Carrying Case
The Buttons
See Table 3 for a description of the Product buttons. For
more information on the buttons, see the “Operation”
section.
Table 3. Buttons
Button Description
Power- Push to turn the Product ON.
Push again and hold for 3 seconds to
turn the Product OFF .
Menu- Push to access the Product
menus. The Menus are: Sample
Screen, Buffered Data Screen, Sample
Setup, Communication Setup, and
Trend Data. Sample Setup and
Communication Setup also have
submenus.
Enter/Select- Push to select a menu
option. Also use to start and stop a
sample when in the Sample Screen.
Navigation- Push to move through the
Product menus, menu selections, and
to change values.
985
Getting Started
6
Product Connections
Power and data connections are on the bottom of the
Product and on the rear of the Charge Base. The
Ethernet connection is only available on the base. Table 4
and Figure 2 show you the Product connections.
Table 4. Product Connections
Item Description
APower Charge LED
BUSB Port
CBase Input
DFlash USB drive Port
ETripod Mount
FDC Power Input
3
2
6
4
5
1
gud001.eps
Figure 2. Product Connections
