INTRODUCTION
1. INTRODUCTION
1.1 PREFACE
The wall-mount product family is designed to be installed in a fixed location for long-term flow
measurement.
The flow meter is based on transit-time flow measurement principle. It measures the flow rate of liquid in a
closed pipe by using a pair of clamp-on or wetted ultrasonic transducers. In general, the liquid should be full in
the pipe, and should contain no or small amount of particles or air bubbles. Examples of applicable liquids are:
water (hot water, chilled water, city water, sea water, etc.); sewage; oil (crude oil, lubricating oil, diesel oil, fuel
oil, etc.); chemicals (alcohol, acids, etc.); waste water; beverage, liquid food, solvents and other liquids.
The utilizes state-of-the-art technologies such as advanced signal processing, low-voltage transmitting,
small signal receiving, self-adaptation, the latest electronics, etc., to achieve high accuracy and reliable
performance. Besides, the EUROSONIC 2000 product provides versatile output interfaces, both analogue and
digital, which can be easily used by a host computer or a flow controller.
1.2 FEATURES
• Better than 1% linearity.
• ±0.2% of repeatability.
• ±1% of accuracy at velocity above 0.6ft/s (0.2m/s).
• Positive / negative / net flow totalizer.
• Proprietary low-voltage transmission and self-adaptation technologies.
• Anti-interference design.
• Dual CPU. 100 Pico-second time measurement resolution.
• Operates with all Euromag transducers.
• Die-cast aluminium weather-resistant enclosure (standard version).
• Able to measure electrically conductive and non-conductive liquids.
• RS-232 interface. Complete communication protocol for instrument networking.
• Can be used as a flow RTU.
• Up to 5 channel 12 bits analogue 4-20mA input
• 1 channel programmable 4-20mA output
• 2 channel programmable digital output (isolated OCT and Relay)
• Frequency output.
• Internal batch process controller.
• 2x20 letters backlight LCD display. 4x4-key, tactile-feedback membrane keypad.
