Elmos AP11-37 Guide
Panel Meter AP 11
Technical documentation U-19
www.apoelmos.cz
ISO 9001
AP11 - 37 - Counter
A.P.O. - ELMOS v.o.s., Pražská 90, Nová Paka 509 01
tel. +420 493 504 261, fax: +420 493 504 257, e-mail: apo@apoelmos.cz
january 2015, TD-U-19-25
A.P.O. - ELMOS v.o.s., Pražská 90, Nová Paka 509 01
tel. +420 493 504 261, fax: +420 493 504 257, e-mail: apo@apoelmos.cz
1 Introduction .............................................................................................. 5
1.1 Ordering code ........................................................................................ 6
2 Technical data ........................................................................................... 7
3 Panel meter description ............................................................................. 9
3.1 Front panel ........................................................................................... 9
3.2 Dimensions of panel meter and assembly opening ....................................... 10
4 Connection ................................................................................................ 11
4.1 Description of back panel ........................................................................ 11
4.2 Instruction for making installations and connections to panel ...................... 11
4.2.1 Reducing of interference influence ....................................................................... 11
4.3 Connection to supply voltage. ................................................................... 12
4.3.1 Connection of power supply conductors in terminal board ....................................... 12
4.4 Connection of input signals ..................................................................... 13
4.4.1 Current signal 4 - 20 mA ..................................................................................... 14
4.4.2 Current signal 0/4 - 20 mA .................................................................................. 14
4.4.3 Auxiliary digital inputs ........................................................................................ 14
4.4.4 Pulse signal input (max. 10 kHz) .......................................................................... 15
5 Analogue output ......................................................................................... 16
5.1 Connection of analogue output ................................................................. 16
5.2 Block diagram of analogue output function ................................................. 17
6 Communication .......................................................................................... 18
7 Connection of contact outputs .................................................................... 19
8 Panel meter functions ................................................................................. 20
8.1 Block diagram of counter ....................................................................... 20
8.2 Panel meter switch on ............................................................................. 20
8.3 Panel meter reset ................................................................................... 20
8.4 Display setting ....................................................................................... 21
8.5 Bargraph ............................................................................................... 22
8.6 Functions of limit switch ......................................................................... 23
8.6.1 Functional characteristics of limit switches ............................................................ 24
9 Panel meter menu functions ....................................................................... 26
9.1 Functions of buttons in setting mode ......................................................... 26
9.2 Working mode ........................................................................................ 26
CONTENTS
A.P.O. - ELMOS v.o.s., Pražská 90, Nová Paka 509 01
tel. +420 493 504 261, fax: +420 493 504 257, e-mail: apo@apoelmos.cz
9.3 Configuration mode ................................................................................ 27
9.3.1 Simplified block diagram of counter menu ........................................................... 27
9.3.2 Configuracetion of pulse input in menu CONF ....................................................... 28
9.3.3 Configuration of limit switches ALA-1 up to ALA-4 ................................................ 29
9.3.4 Configuration of current sensor SENS .................................................................. 30
9.3.5 Configuration of analogue output - DACO ............................................................. 31
9.3.6 Configuration of parameters OSTAT ..................................................................... 32
9.3.7 Configuration bargraph - BARGF ......................................................................... 33
9.3.8 Configuration of diplay - DIS-1, DIS-2 ................................................................. 34
9.3.9 Reset of sum CL-S1, CL-S2 ................................................................................. 35
9.3.10 Reseting thre measured value CL-IN .................................................................... 35
9.4 Limit values of parameters ........................................................................ 36
10 Control software ...................................................................................... 37
11 ES Declaration of conformity .................................................................... 38
12 Certificate of quality and completness ....................................................... 39
13 Guarantee conditions ............................................................................... 39
CONTENTS
5
A.P.O. - ELMOS v.o.s., Pražská 90, Nová Paka 509 01
tel. +420 493 504 261, fax: +420 493 504 257, e-mail: apo@apoelmos.cz
AP11-37 Counter is 5 digit programmable panel meter for measuring in time dependent current signal.De-
vice is controlled with digital signal processor with A/D transducer.Counter is operated with key-board pla-
ced on front panel or with control software that is used for setting of all parameters and archiving measu-
red values. Panel meter has tobe provided with communication line, variants of communication lines are in
ordering code. Control software is included in standard delivery. Counter is equipped with three-colour dis-
play allowing for a quick check of limits within measured value oscillates. Visually interesting element is au-
xiliary horizontal bargraph. AP11 Counter inputs are assembled for unified outputs from sensors of techno-
logical processes
(0/4-20 mA, 0/2-10 V).There is an variant with analogue output that can be galvanic separated in panel me-
ter ordering code.With multi-stage types of panel meters analogue output can be assigned to any input by a
program, eventually to sum. Any of the communication line variants can be used for communication of panel
meter with PC.Communication lines RS232 or RS485 (can be galvanic separated) are in ordering code. Com-
bination of two communication lines RS232 and RS485 can be used for above standard applications. Com-
munication enables not only setting of parameters and data archiving, but regarding the possibility of ad-
dressing of individual panel meters it can be also used for interconnection of bigger number of panel me-
ters and controlling of complete technological lines.
1
INTRODUCTION
A.P.O. - ELMOS v.o.s., Pražská 90, Nová Paka 509 01
tel. +420 493 504 261, fax: +420 493 504 257, e-mail: apo@apoelmos.cz
6
This technical documentation refers to the following chart of ordering codes
fig.1
1.1 Ordering code
1INTRODUCTION
AP 11 - XX - X - X - X - X - X - XXX
Input
37 1 x current signal input 0/4 - 20 mA
1 x pulse signal input
Contact output
0empty
12 x relay (switching contacts 250 VAC, 2A)
24 x relay (switching contacts 250 VAC, 2A
Analogue output
0empty
1current/voltage without galvanic separ
2current/voltage with galvanic separ. GS
Communication
0empty
1RS232
3RS485 with GS
6RS485 with GS + RS232
Power supply
180 - 253 VAC
218 - 36 V AC/DC
Display
4three colour
Software
001 Counter
xxx special requirement
AP 11 - 37 - 2 - 2 - 3 - 1 - 4 - 001
Example of order code
7
A.P.O. - ELMOS v.o.s., Pražská 90, Nová Paka 509 01
tel. +420 493 504 261, fax: +420 493 504 257, e-mail: apo@apoelmos.cz
2
TECHNICAL DATA
Power supply
Power supply voltage 80 - 253 VAC, 50 Hz
18 - 36 VDC / 18 - 36 VAC, 50 Hz
Consumption max. 12 VA
Display
Display -9999 ~ 0 ~ 99999 (5-digit LED)
Height of digits 14 mm
Decimal point Adjustable with program
Bargraph 30 LED
Resolution According to position of decimal point
Auxiliary power
supply
> 18 VDC @ 25 mA for feeding of sensors
Max. load of auxiliary power supply 40 mA
Outputs
Contact 2x relay (switching contact 250 VAC, 2A or 30 VDC, 2A)
or 4x relay (switching contact 250 VAC, 2A or 30 VDC, 2A)
Analogue 13.5 bit D/A transducer without galvanic separation or with galvanic se-
paration current 0 (4) – 20 mA, loading resistance max. 400 Ω
voltage 0 – 10 V, loading resistance min. 10 kΩ
Communication
RS485 without galvanic separation or with galvanic separation,
two way communication
RS232 without galvanic separation
Input signals, accuracy
Type Input signal meas.range Accuracy of
measurement
(% of sca-
le)
Code
Process 1x current signal (AI) 1x 0/4-20mA ± 0,25% 37
Pulse 1x pulse signal (CI) 0-10KHz 37
Comparator level LOW 3,9 V/2,4 V ± 0,5 V
HIGH 7,5 V/6 V
A.P.O. - ELMOS v.o.s., Pražská 90, Nová Paka 509 01
tel. +420 493 504 261, fax: +420 493 504 257, e-mail: apo@apoelmos.cz
8
2TECHNICAL DATA
Operating conditions
Working conditions 0 - 60 °C
Temperature coefficient 25 ppm/°C
Stabilizing time Within 5 min after activation
Shielding IP 54 (front panel)
IP 20 (terminal board)
Calibration at 25 °C and 40% relative humidity
Data back-up electrically (EEPROM), bat.CR2032SLF (RAM)
Auxiliary input Voltage free contact, digital inputs
Connection
Connector terminal board
Max. section of condu-
ctor
2.5 mm2 for power supply and contact outputs
1 mm2 for other connectors
Safety class I
Electromagnetic compatibility
ČSN EN 61326
Seismic resistibility
ČSN IEC 980: 1993, čl. 6
Electric safety
ČSN EN 61010-1: 2003
Mechanical properties
Type AP11 panel meter
Dimensions 96 x 48 x 119 mm
Opening in panel 90,5 x 43,5 (openings in corners ø 3 mm with pitch 89,5 x 42,5 mm)
Keyboard 4 keys, foil
Weight 400 g
9
A.P.O. - ELMOS v.o.s., Pražská 90, Nová Paka 509 01
tel. +420 493 504 261, fax: +420 493 504 257, e-mail: apo@apoelmos.cz
3
PANEL METER DESCRIPTION
1
2
3
4
1
2
3
4
Menu
UP
DOWn Set
Ap 11
In Out
1
2
3456 7
8
2 - Input „IN“ indicators
No. of of selected input (functions IN-1,IN-2,SUM1,SUM2 )is indicated with respective indicator. Individual
inputs are selected with keys „UP“ and „DOWN“.
1 - Display
Five-digit display for indication of measured value. With parameter programming display show clear reports.
8 - Output „OUT“ indicators
Indicators OUT 1 to OUT 4 indicates state of individual outputs in the following manner: indicator flashing
– output switched, indicator is not flashing – output is off.
7 - Key „SET“
Key „SET“ is used for setting data, programming termination, data uploading into EEPROM and return to
operating mode.
6 - Key „DOWN“
Key „DOWN“ is used for browsing parameters and setting of numeric data when programming. Pushing and
keeping down of the key speeds up browsing and setting procedure.
5 - Key „UP“
Key „UP“ is used for browsing parameters and setting of numeric data when programming. Pushing and kee-
ping down of the key speeds up browsing and setting procedure.
4 - Key „MENU“
Key „MENU“ is used for entering configuration menu and setting mode.
fig. 2
3 - Bargraph
Bargraph relates to measured value that is determined with pre-set range of STR and END.
E.g. if start of range (STR) is 0 and end (END) 200 and measured value shall be on level 100, bargraph shall in-
dicate half of the scale. Bargraphs is formed with column of LED diodes.
3.1
Front panel
A.P.O. - ELMOS v.o.s., Pražská 90, Nová Paka 509 01
tel. +420 493 504 261, fax: +420 493 504 257, e-mail: apo@apoelmos.cz
10
3PANEL METER DESCRIPTION
fig. 3a
Dimensions for power supply 80 - 253 VAC, 50 Hz (g. 3a)
Dimensions for power supply 18 - 36 VDC / 18 - 36 VAC, 50 Hz (g. 3b)
fig. 3b
3.2 DIMENSIONS OF Panel meter AND ASSEMBLY OPENING
Front view
Front view Side view
Side view
