Dimplex DFB4047 Quick start guide

PARTS AND SERVICE MANUAL

FOR

COMPACT FIREPLACE

Model DFB4047

TABLE OF CONTENTS

OPERATION PAGE 1

PARTS DRAWING PAGE 3

PARTS LIST PAGE 4

LIGHT BULB REPLACEMENT PAGE 5

HEATER ON/OFF SWITCH REPLACEMENT PAGE 6

THERMOSTAT CONTROL REPLACEMENT PAGE 7

FLAME MOTOR/FLAME ROD REPLACEMENT PAGE 8

HEATER ASSEMBLY REPLACEMENT PAGE 9

CIRCUIT BOARD REPLACEMENT PAGE 10

POWER CORD REPLACEMENT PAGE 11

TERMINAL BLOCK/CAPACITOR REPLACEMENT PAGE 12

DFB4047

OPERATION

The fireplace is supplied with an integrated on/off remote control.

Note: Ensure that the fireplace 3 position switch is set to

the remote control setting.

To operate, push the ON button to turn fireplace on, push the

OFF button to turn the fireplace off.

BATTERY REPLACEMENT

To replace the battery, slide battery cover open on the hand

held transmitter.

Correctly install one 12 volt (A23) battery in the battery holder.

Close the batter cover.

Resetting the temperature cutoff switch

The heater is protected with a safety device to prevent overheating. Should the heater

overheat, an automatic cut out will turn the heater off and it will not come back on without

being reset. It can be reset by switching the ON/OFF SWITCH to OFF and waiting 5

minutes before switching the unit back on.

Caution

If you need to continuously reset the heater, unplug the unit and call your local dealer.

ON OFF

BATTERY

COVER

Three position ON/OFF switch

The switch has two ON positions marked with “-“ and “=”.

The “-“ position is for manual operation.

In this position the built-in remote control is bypassed.

The “=” position is for operating the unit with the provided remote control.

When in “=” position the unit is operated with the ON and OFF buttons of the remote

control.

When the switch is in the center position the unit is off.

Heat switch

The HEAT ON/OFF SWITCH supplies power to the heater fan and the heater element.

When the switch is in the ON position the heater operates if the thermostat calls for heat.

Heater thermostat control

To adjust the temperature to your individual requirements, turn the thermostat control

clockwise all the way to turn on the heater. When the room reaches the desired

temperature, turn the thermostat knob counter clockwise until you hear a click. Leave in

this position to maintain the room temperature at this setting. For additional heat, turn

clockwise until you hear the click again and the heater will turn on.

MAIN THREE

POSITION

ON/OFF

SWITCH

THERMOSTAT

HEAT

SWITCH

MANUAL

OPERATION

OFF

REMOTE

CONTROL

DFB4047

REPLACEMENT PARTS

COMPACT FIREPLACE

PART NO. 6901740000

MOD LEVEL: NONE

MADE IN: CHINA

REPLACEMENT PART REPLACEMENT PART NO.

1. LOGSET 0438200700RP

2. FLAME MOTOR 2000220100RP

3. HEATER ASSEMBLY 2200490300RP

4. CUTOUT 2300270100RP

5. THERMOSTAT 2300150100RP

6. HEATER SWITCH 2800070200RP

7. ON/OFF SWITCH 2800071100RP

8. CAPACITOR 3200030100RP

9. TERMINAL BLOCK 4000070100RP

10.CORD SET 4100090100RP

11.REFLECTOR ROD 5900340100RP

12.MIRROR 5900350100RP

13.FRONT GLASS 5900380100RP

14.BUSHING, SNAP-IN 8500000400RP

15.FLICKER CONNECTOR 8500680100RP

16.CONTROL KNOB 8800000300RP

17.LAMPHOLDER ASSEMBLY 4200120800RP

18.HEYCO STRAIN RELIEF 8500260003RP

19.REMOTE (INTEGRAL) 3000400100RP

DFB4047

If unit was operating prior to servicing allow at least 10 minutes for light bulbs and

heating element to cool off to avoid accidental burning of skin.

Disconnect power before attempting any maintenance or cleaning to reduce the risk of

electric shock or damage to persons.

Light bulbs need to be replaced when you notice a dark section of the flame. There are

four bulbs under the log set which generate the flames and embers.

It is a good idea to replace all of the light bulbs at one time if they are close to the end of

their rated life. Group replacement will reduce the number of times you need to open

the unit to replace the light bulbs.

BULB REPLACEMENT

1. Open the front control cover.

2. Remove front glass by removing the 2 outer screws holding the class clips.

3. Remove the log grate by removing the 4 mounting screws.

4. Remove the log set by lifting straight up.

5. Slide the light assembly slightly out of the insert approximately 1”.

6. Examine bulbs to determine which bulbs require replacement.

7. Hold the socket while unscrewing the old bulb.

8. Hold the socket while screwing in the new bulb.

9. Reassemble in the reverse order as above.

LIGHT BULB REQUIREMENTS

Quantity of 4 clear chandelier or candelabra bulbs with an E-12 (small) socket base,

60 watt rating.

DFB4047

If unit was operating prior to servicing allow at least 10 minutes for light bulbs and

heating element to cool off to avoid accidental burning of skin.

Disconnect power before attempting any maintenance or cleaning to reduce the risk of

electric shock or damage to persons.

TO REPLACE MAIN ON/OFF AND HEATER SWITCHES

1. Open the front control cover.

2. Remove front glass by removing the 2 outer screws holding the class clips.

3. Remove the log grate by removing the 4 mounting screws.

4. Remove the log set by lifting straight up.

5. Lay the insert on its back and remove the 2 switch control cover screws located on

the bottom of the insert.

6. Locate the switch to be replaced and disconnect the wiring clips and connections

noting their original locations.

7. Depress the retainer clips on the rear of the switch and push the switch out of the

rear of the cover.

8. Reassemble in the reverse order as above.

DFB4047

If unit was operating prior to servicing allow at least 10 minutes for light bulbs and

heating element to cool off to avoid accidental burning of skin.

Disconnect power before attempting any maintenance or cleaning to reduce the risk of

electric shock or damage to persons.

TO REPLACE THERMOSTAT CONTROL

1. Open the front control cover.

2. Remove front glass by removing the 2 outer screws holding the class clips.

3. Remove the log grate by removing the 4 mounting screws.

4. Remove the log set by lifting straight up.

5. Lay the insert on its back and remove the 2 switch control cover screws located on

the bottom of the insert.

6. Locate the thermostat control and disconnect the wiring clips and connections noting

their original locations.

7. Remove the thermostat control knob by pulling straight out.

8. Remove the 2 mounting screws and remove the old thermostat control.

9. Reassemble in the reverse order as above.

DFB4047

If unit was operating prior to servicing allow at least 10 minutes for light bulbs and

heating element to cool off to avoid accidental burning of skin.

Disconnect power before attempting any maintenance or cleaning to reduce the risk of

electric shock or damage to persons.

TO REPLACE FLAME MOTOR/REFLECTOR ROD

1. Open the front control cover.

2. Remove front glass by removing the 2 outer screws holding the class clips.

3. Remove the log grate by removing the 4 mounting screws.

4. Remove the log set by lifting straight up.

5. Slide the light assembly slightly and lift out of the insert being careful not to damage any

of the wiring.

6. Remove the reflector rod from the flame motor by pulling the end of the rod to the left

and separating it from the rubber sleeve.

7. Remove the rubber sleeve from the motor shaft.

8. Disconnect the flame motor wire from the terminal block, noting their original locations

9. Remove the 2 motor mounting screws and remove the flame motor.

10.Discard the old flame motor.

11.Reassemble in the reverse order as above
