Dell™OptiPlex™GX270ServiceManual



Safety Instructions

Opening the Computer Cover

Chassis Intrusion Switch

Control Panel

I/O Panel

Power Supply

System Board

Closing the Computer Cover

To remove or replace all other GX270 components, see the Dell OptiPlex GX270 Systems User's Guide.

Information in this document is subject to change without notice.

©2003–2004DellInc.Allrightsreserved.

Reproduction in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden.

Trademarks used in this text: Dell, the DELL logo, and OptiPlex are trademarks of Dell Inc.

Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Dell Inc. disclaims any

proprietary interest in trademarks and trade names other than its own.

June 2004 Rev. A01

NOTE: A NOTE indicates important information that helps you make better use of your computer.

NOTICE: A NOTICE indicates either potential damage to hardware or loss of data and tells you how to avoid the problem.

CAUTION: A CAUTION indicates a potential for property damage, personal injury, or death.

Back to Contents Page

Chassis Intrusion Switch

Dell™OptiPlex™GX270ServiceManual

Removing the Chassis Intrusion Switch

Replacing the Chassis Intrusion Switch

Resetting the Chassis Intrusion Detector



1. Shut down the computer through the Start menu.

2. Ensure that your computer and attached devices are turned off. If your computer and attached devices did not automatically turn off when you shut

down your computer, turn them off now.



3. Disconnect any telephone or telecommunication lines from the computer.

4. Disconnect your computer and all attached devices from their electrical outlets, and then press the power button to ground the system board.

5. Remove the computer stand, if it is attached.



6. Open the computer cover.



Removing the Chassis Intrusion Switch

1. Disconnect the chassis intrusion switch cable from the control panel on the front of the computer.



Note the routing of the chassis intrusion cable as you remove it from the chassis. Chassis hooks may hold the cable in place inside the chassis.

2. Slide the chassis intrusion switch out of its slot, and remove the switch and its attached cable from the computer.

Small Form-Factor Computer



Small Desktop Computer



CAUTION: Before you begin any of the procedures in this section, follow the steps in "Safety Instructions."

NOTICE: Before you disconnect a device from the computer or remove a component from the system board, verify that the standby power light on the

system board has turned off. To locate the light, see "System Board."

NOTICE: To disconnect a network cable, first unplug the cable from your computer and then unplug it from the network wall jack.

CAUTION: To guard against electrical shock, always unplug your computer from the electrical outlet before opening the cover.

NOTICE: Before touching anything inside your computer, ground yourself by touching an unpainted metal surface, such as the metal at the back of the

computer. While you work, periodically touch an unpainted metal surface to dissipate any static electricity that could harm internal components.

Small Mini-Tower Computer



Replacing the Chassis Intrusion Switch

1. Slide the chassis intrusion switch into its slot and reconnect the cable to the connector on the control panel.

2. Close the computer cover.

3. Attach the computer stand, if it is used.



4. Connect your computer and devices to electrical outlets, and turn them on.

Resetting the Chassis Intrusion Detector

1. Enter system setup by pressing <F2> during the computer's start-up.



2. Under the System Security tab, reset the Chassis Intrusion option by pressing the left-or right-arrow key to select Reset. Change the setting to

Enabled, Enabled-Silent, or Disabled.



NOTICE: To connect a network cable, first plug the cable into the network wall jack and then plug it into the computer.

NOTE: For instructions on using system setup, see the User's Guide.



3. Press <Alt><b> to restart the computer and implement your changes.

Back to Contents Page



NOTE: The default is Enabled-Silent.

NOTE: If a setup password has been assigned by someone else, contact the network administrator for information on resetting the chassis intrusion

detector.

Back to Contents Page

Control Panel

Dell™OptiPlex™GX270ServiceManual

Removing the Control Panel

Replacing the Control Panel



1. Shut down the computer through the Start menu.

2. Ensure that your computer and attached devices are turned off. If your computer and attached devices did not automatically turn off when you shut

down your computer, turn them off now.



3. Disconnect any telephone or telecommunication lines from the computer.

4. Disconnect your computer and all attached devices from their electrical outlets, and press the power button to ground the system board.

5. Remove the computer stand, if it is attached.



6. Open the computer cover.

Removing the Control Panel



Small Form-Factor Computer

1. Using a flat-blade screwdriver, release the four tabs from the inside of the computer, and remove the computer cover from the computer.



CAUTION: Before you begin any of the procedures in this section, follow the steps in "Safety Instructions."

NOTICE: Before you disconnect a device from the computer or remove a component from the system board, verify that the standby power light on the

system board has turned off. To locate the light, see "System Board."

NOTICE: To disconnect a network cable, first unplug the cable from your computer and then unplug it from the network wall jack.

CAUTION: To guard against electrical shock, always unplug your computer from the electrical outlet before opening the cover.

NOTICE: Before touching anything inside your computer, ground yourself by touching an unpainted metal surface, such as the metal at the back of the

computer. While you work, periodically touch an unpainted metal surface to dissipate any static electricity that could harm internal components.

tabs (2 on each side)

computer

computer cover



2. Remove the metal control-panel shield.

3. Remove the screw that holds the control panel to the computer, and remove the control panel.



Small Desktop Computer

1. Remove the front I/O panel (see I/O Panel).



2. Using an 8-inch #2 Phillips screwdriver, remove the screw that secures the control panel to the computer, and lift the panel away from the computer.



Small Mini-Tower Computer

1. To remove the top and bottom panels of the computer, remove any installed CD drives and release all the tabs on each panel.



metal control-panel shield

screw



2. To prepare the computer cover for removal, release the three computer cover tabs (one tab is located by the CD drive and two tabs are located by the

I/O panel).



3. If necessary, remove the computer cover screw.

4. Close the computer and remove the computer cover.

5. Remove the screw that secures the control panel to the computer, and pull the control panel away from the computer.



Replacing the Control Panel



Small Form-Factor Computer

1. Replace the control panel and the control-panel shield.

computer cover tab (remove the CD drive to access this tab)

bottom panel

top-panel tabs

computer cover screw

top panel

computer cover tabs (2)

NOTE: To release the tab located by the CD drive, you can pry the computer cover away from the computer and pull out the tab.

2. Replace the computer cover. Ensure that the two metal hooks and tabs are securely in position.



To help replace the computer cover, remove the accent door and front mask from the computer cover:

a. Remove the front mask by releasing the tabs on the inside of the computer cover.

b. Remove the accent door by pressing the middle of the door while you lift away the sides of the door.



3. Replace the computer cover and ensure that the two metal hooks and tabs are securely in position.



4. To replace the front mask and accent door, press them into position.



Small Desktop Computer



accent door

front mask

metal hooks (2)

Follow the steps in the "Removing the Control Panel" procedure in the reverse order, ensuring that all tabs are secure.



Small Mini-Tower Computer



Follow the steps in the "Removing the Control Panel" procedure in the reverse order, ensuring that all tabs are secure.

Back to Contents Page



Back to Contents Page

Opening the Computer Cover

Dell™OptiPlex™GX270ServiceManual



1. Shut down the computer through the Start menu.

2. Ensure that your computer and attached devices are turned off. If your computer and attached devices did not automatically turn off when you shut

down your computer, turn them off now.



3. Disconnect any telephone or telecommunication lines from the computer.

4. Disconnect your computer and all attached devices from their electrical outlets, and then press the power button to ground the system board.

5. Remove the computer stand, if it is attached.



Small Form-Factor and Small Desktop Computers

1. Locate the two release buttons shown in the illustration. Then press the two release buttons as you lift the cover.



2. Raise the back of the cover, and pivot it toward the front of the computer.

Small Form-Factor Computer



Small Desktop Computer



CAUTION: Before you begin any of the procedures in this section, follow the steps in "Safety Instructions."

NOTICE: To disconnect a network cable, first unplug the cable from your computer and then unplug it from the network wall jack.

CAUTION: To guard against electrical shock, always unplug your computer from the electrical outlet before opening the cover.

NOTICE: Ensure that there is sufficient space to support the open cover—at least 30 cm (1 ft) of desk top space.

NOTICE: Open the cover slowly to ensure that you do not damage any cables.

security cable slot

padlock ring

release buttons (one on each side)
