INSTRUCTION MANUAL

MODEL 2016-8085 Downconverter

TABLE OF CONTENTS PAGE

Warranty 2

1.0 General 3

1.1 Equipment Description 3

1.2 Technical Characteristics 4

1.3 Monitor & Control Interface 6

1.4 Environmental Use Information 10

2.0 Installation 11

2.1 Mechanical 11

2.2 Rear Panel Inputs & Outputs 12

2.3 Front Panel Controls & Indicators 12

2.4 Operation 13

2.5 Menu Settings 14

WARRANTY - The following warranty applies to all Cross Technologies, Inc. products.

All Cross Technologies, Inc. products are warranted against defective materials and

workmanship for a period of one year after shipment to customer. Cross Technologies,

Inc.’s obligation under this warranty is limited to repairing or, at Cross Technologies, Inc.’s

option, replacing parts, subassemblies, or entire assemblies. Cross Technologies, Inc. shall

not be liable for any special, indirect, or consequential damages. This warranty does not

cover parts or equipment which have been subject to misuse, negligence, or accident by the

customer during use. All shipping costs for warranty repairs will be prepaid by the

customer. There are not other warranties, express or implied, except as stated herein.

CROSS TECHNOLOGIES, INC.

6170 Shiloh Road

Alpharetta, Georgia 30005

(770) 886-8005

FAX (770) 886-7964

Toll Free 888-900-5588

WEB www.crosstechnologies.com

E-MAIL [email protected]

2016-8085 Manual_Rev. 0 Page 2 05/10/22

MODEL 2016-8085 Downconverter

1.0 General

1.1 Equipment Description

The 2016-8085 Downconverter converts 8.0 to 8.5 GHz to 70 ± 18 MHz in 125 kHz steps (1 kHz steps, option

X1006) with low group delay and flat frequency response. Synthesized local oscillators (LO) provide low phase

noise and ±0.01 ppm stability frequency selection. Multi-function push button switches select the RF

frequency, gain, and other parameters. Front panel LEDs provide indication of DC power (green), PLL alarm

(red), and remote operation (yellow). Gain is adjustable manually over a +30 to +50 dB range as adjusted by

the front panel multi-function push-button switches. Remote operation allows selection of frequency and gain.

Parameter selection and frequency and gain settings appear on the LCD display. Connectors are BNC (female)

for IF output and the 10MHz reference input and output, and Type N (female) for the RF input. External 10

MHz is standard. A 10 MHz output connector contains either the internal or external 10 MHz reference signal.

It is powered by a 100-240 ±10% VAC power supply, and in a 1 3/4” X 19“ X 16” rack mount chassis.

EXECUTE

MODEL 2016

CROSS TECHNOLOGIES INC.

REMOTE

POWER

ALARM

DOWNCONVERTER

F=8150.125 G=30

REF=INT

FRONT

GND

J10

J18

RF IN

10 MHZ REF

OUTPUT

10 MHZ

EXT REF

INPUT

MONITOR

AND

CONTROL

IF OUT

J20

REAR

FIGURE 1.1 Model 2016-8085 Front and Rear Panels

8.0

8.5

GHz

MHz

OUT

CONTROLLER

F=8150.125 G=30

REF=INT

VAR

ATT

EXT

10 MHz

VAR

ATT

INT

10 MHz

Block Diagram

FIGURE 1.2 Model 2016-8085 Downconverter Block Diagram

2016-8085 Manual_Rev. 0 Page 3 05/10/22

1.2 Technical Characteristics

Technical Characteristics continued on page 5...

2016-8085 Manual_Rev. 0 Page 4 05/10/22

Other

100-24 ±10% VAC, 47-63 Hz, 45 watts maximum

Power

19 inch, 1 RU Standard Chassis 1.75” high X 16.0” deep

Size

DB9 - NO or NC Contact Closure on Alarm

Alarm/Remote Connector

BNC (female), 75Ω, works with 50 or 75 ohms

10 MHz Connectors

RF Type N (female), 50Ω/RF - BNC (female), 75Ω

RF Connectors

TABLE 1.0 2016-8085 Downconverter Specifications*

15 dB (maximum gain)

Nosie Figure, maximum

-70 to -40 dBm

Level Range

8.0 to 8.5 GHz

Frequency

+10 dBm

1dB Compression

-20 to 0 dBm

Level Range

Output Characteristics (IF)

Input Characteristics (RF)

70 ±18 MHz

Frequency

75Ω/ 20 dB minimm, 18 dB minimum

Impedance / Return Loss

50Ω/ 20 dB typical; 18 dB minimum

Impedance / Return Loss

Technical Characteristics continued from page 4...

2016-8085 Manual_Rev. 0 Page 5 05/10/22

- W7 RF/IF Monitor Ports (Front)

- W31 Extended Temperatue 0C to +50C

- W1006 1 kHz fequency step

-50ΩType N (RF), 75ΩBNC (IF)

- STD

Ethernet with TCP/IP, Telnet®

- W28

50ΩSMA (RF), 75ΩBNC (IF)

- S7

50ΩSMA (RF), 50ΩBNC (IF)

- S

50ΩType N (RF), 50ΩBNC (IF)

- M

Contact Cross for other options.

Connectors/Impedance

Ethernet with Web Browser & SNMP

- W18

Ethernet with Web Browser

- W8

Ethernet with W18 + W28

- W828

RS-485/422

- Q

Remote M&C Interfaces

Available Options

*10˚C to 40˚C; Specifications subject to change without notice ® 2022 Cross Technologies, Inc.

1.3 Monitor and Control Interface

A) Remote serial interface

Protocol: RS-232C, 9600 baud rate, no parity, 8 data bits, 1 start bit, and 1 stop bit.

(RS-232C, RS-422, or RS-485 - option -Q)

Female DB-9

PC Com Port

Male DB-9

2015/16/17 M&M&C

Port

M&C Cable Diagram - Cross Technologies Frequency Converters

Connector: Rear panel, DB-9 female

J10 Pinouts (RS-232C/422/485)

Pin Function

1 Rx-

2 Rx+ (RS-232C)

3 Tx+ (RS-232C)

4Tx-

5GND

6 Alarm Relay: Common

7 Alarm Relay: Normally Open

8 Not Used

9 Alarm Relay: Normally Closed

2016-8085 Manual_Rev. 0 Page 6 05/10/22

B) Status Requests

Table 1.1 lists the status requests for the 2016-8085 and briefly describes them.

*PLEASE NOTE: The two character {aa}(00-31) prefix, in the table below,

should be used ONLY when RS-485, (OPTION-Q), is selected.

TABLE 1.1 2016-8085 Status Requests/Inquires

Command Syntax* Description

Frequency Inquiry {aaSF} Returns: {aaSFxxxxxxx}

Where:

• aa = unit address, range = 00 to 31, only used if

interface is RS485, otherwise omit

• F = command code

• xxxxxxx = frequency in kHz

The unit will append the '>' character if the command

is sucessfully processed.

Gain Inquiry {aaSG} Returns: {aaSGxx}

Where:

• aa = unit address, range = 00 to 31, only used

if interface is RS485, otherwise omit.

• G = command code

• xx = unit's gain setting in dB

The unit will append the '>' character if the

command is sucessfully processed.

Reference Mode Inquiry {aaSE} Returns: {aaSEx}

Where:

• aa = unit address, range = 00 to 31, only used if

interface is RS485, otherwise omit.

• E = command code

• x = 0 if reference mode is internal,

x = 1 if external, x = 2 if auto

The unit will append the '>' character if the command is

sucessfully processed.

Alarm Inquiry {aaSA} Returns: {aaSAx}

Where:

• aa = unit address, range = 00 to 31, only used if

interface is RS485, otherwise omit

• A = command code

• x = 0 if alarm is off, x = 1 if alarm is on.

The unit will append the '>' character if the

command is sucessfully processed.

2016-8085 Manual_Rev. 0 Page 7 05/10/22

C) Commands - Table 1.1 lists the commands for the 2016-8085 and briefly describes them. After a

command is sent, the 2016-8085 sends a return “>” indicating the command has been received and executed.

General Command Format - The general command format is {aaCND...}, where:

{ = start byte

aa = address (RS-485 only - option -Q)

C = 1 character, either C (command) or S (status)

N = 1 character command or status request

D = 1 character or more of data (depends on command)

} = stop byte

*PLEASE NOTE: The two character {aa}(00-31) prefix, in the table below,

should be used ONLY when RS-485, (OPTION-Q), is selected.

Table 1.2 2016-8085 Commands

Command Syntax* Description

Set Frequency {aaCFxxxxxxx} Where:

• aa = unit address, range = 00 to 31, only used if

interface is RS485, otherwise omit

• F = command code

• xxxxxxx=frequency in kHz, range = 8000000 to 8500000

(8000.000 to 8500.000 MHz, 0.125 MHz steps)

example: {CF8175125}

Will set the unit's frequency to 8175.125 MHz

The unit will reply with the '>' character if the command

is sucessfully processed.

Set Gain {aaCGxx} Where:

• aa = unit address, range = 00 to 31, only used if interface

is RS485, otherwise omit.

• G = command code

• xx = gain in dB, range = 30 to 50 in 1.0 dB steps.

example: {CG34}

Will set the unit's gain to 34.0 dB

The unit will reply with the '>' character if the

command is sucessfully processed.

Set Reference Mode {aaCEx} Where:

• aa = unit address, range = 00 to 31, only used if

interface is RS485, otherwise omit

• E = command code

• x = 0 to set to internal reference,

• x = 1 to set to external reference

example: {CE1}

Will set the reference mode to External.

The unit will reply with the '>' character

if the command is sucessfully processed.

(Continued on page 9)...

2016-8085 Manual_Rev. 0 Page 8 05/10/22

(Continued from page 8)...

Table 1.2 2016-8085 Commands, (continued)...

Command Syntax* Description

Set Remote Off {aaCR0} Where:

• aa = unit address, range = 00 to 31, only used if

interface is RS485, otherwise omit.

• R = command code

• 0, ascii number zero.

example: {CR0}

Will disable the unit's serial M&C port.

The unit will reply with the '>' character if the

command is sucessfully processed.

(Note: this command only affects the serial M&C port,

the ethernet port is always on and will not be affected).

Set Remote On # Just the ascii pound sign, (0x23)

Will enable the unit's serial M&C port.

The unit will reply with the '>' character if

the command is sucessfully processed.

(Note: this command only affects the serial M&C port,

the ethernet port is always on and will not be affected).

2016-8085 Manual_Rev. 0 Page 9 05/10/22

1.4 Environmental Use Information

A.Rack-Mounting - To mount this equipment in a rack, please refer to the installation instructions

located in the user manual furnished by the manufacturer of your equipment rack.

B. Mechanical loading - Mounting of equipment in a rack should be such that a hazardous condition

does not exist due to uneven weight distribution.

C.Elevated operating ambient temperature - If installed in a closed or multiunit rack assembly,

the operating ambient temperature of the rack may be greater than room ambient temperature.

Therefore, consideration should be given to Tmra (Maximum Recommended Ambient Temperature).

D. Reduced air flow - Installation of the equipment in a rack should be such that the amount of air flow

required for safe operation of the equipment is not compromised. Additional space between units

may be required.

E. Circuit Overloading - Consideration should be given to the connection of the equipment to the supply

circuit and the effect that overloading of circuits could have on over current protection and supply wiring.

Appropriate consideration of equipment name plate rating should be used, when addressing this concern.

F. Reliable Earthing - Reliable earthing of rack-mounted equipment should be maintained. Particular

attention should be given to supply connections other than direct connection to the Branch

(use of power strips).

G. Top Cover - There are no serviceable parts inside the product so, the Top Cover should not be removed.

If the Top Cover is removed the ground strap and associated screw MUST BE REINSTALLED

prior to Top Cover screw replacement. FAILURE TO DO this may cause INGRESS and/or EGRESS

emission problems.

2016-8085 Manual_Rev. 0 Page 10 05/10/22

Table of contents

Other Cross Technologies Media Converter manuals

Cross Technologies

Cross Technologies 2117-8485 User manual

Cross Technologies

Cross Technologies 2016-25-01 User manual

Cross Technologies

Cross Technologies 4115-41-212 User manual

Cross Technologies

Cross Technologies 3016-2124 User manual

Cross Technologies

Cross Technologies 2017-1727-140 User manual

Cross Technologies

Cross Technologies 3116-145-1600 User manual

Cross Technologies

Cross Technologies 4116-285-2450 User manual

Cross Technologies

Cross Technologies 2017-93 User manual

Cross Technologies

Cross Technologies 2015-123 User manual

Cross Technologies

Cross Technologies 4117-14 User manual

Cross Technologies

Cross Technologies 2015-26 User manual

Cross Technologies

Cross Technologies 2116-116 User manual

Cross Technologies

Cross Technologies 2416 02I Series User manual

Cross Technologies

Cross Technologies 2115-122 User manual

Cross Technologies

Cross Technologies 2005-10 User manual

Cross Technologies

Cross Technologies 2116-182193 User manual

Cross Technologies

Cross Technologies 2016-02-1200 User manual

Cross Technologies

Cross Technologies 3117-3338 720 Series User manual

Cross Technologies

Cross Technologies 2416 25 Series User manual

Cross Technologies

Cross Technologies 2099-2424 User manual

Cross Technologies

Cross Technologies 2016-26 User manual

Cross Technologies

Cross Technologies 2017-03 User manual

Cross Technologies

Cross Technologies 4116-31-184 User manual

Cross Technologies

Cross Technologies 2116-140T120 User manual

Popular Media Converter manuals by other brands

SoundTraxx

SoundTraxx Blunami BLU-2200 user guide

SPROLINK

SPROLINK VA1 user manual

Acclaim Lighting

Acclaim Lighting DDC-1-AC user guide

Nikon

Nikon AF-S TC-20E III user manual

Axis

Axis AXIS Q7406 user manual

Omega

Omega TAC80B-J instruction sheet

Zoom

Zoom Thunderbolt TAC-2R Operation manual

OST

OST iConverter 10/100M quick start guide

Vertiv

Vertiv Netsure user manual

birddog

birddog MINI user guide

Roland

Roland GI-10 owner's manual

Wallenstein

Wallenstein WX310 Operator's manual

Pace

Pace MSS 200-1 Service manual

Solar Converters

Solar Converters EQ 12/24-50 manual

CYP

CYP EL-7400V Operation manual

TIE

TIE MIDI 1i1o user manual

DCS

DCS Vivaldi Upsampler user manual

Westermo

Westermo MCW-211 SERIES user guide
