AT-110

ALTIMETER

MULTISPORTS

マルチスポーツアルティメータ

ALTIMETRE MULTISPORT

MULTI-SPORT-HÖHENMESSER

MULTISPORTS ALTIMETER

MODEL AT-110

Instruction Manual

INDEX

FOR SAFE OPERATIONS (IMPORTANT) ------------------------------ 2

NAMES --------------------------------------------------------------------------- 2

PREPARATIONS

1. Battery Installation ------------------------------------------------------ 3

2. Data Scale Set Up ------------------------------------------------------ 3

3. Time Set Up -------------------------------------------------------------- 3

4. Attaching Wrist Band--------------------------------------------------- 3

5. Attaching to Your Body ------------------------------------------------ 3

HOW TO USE AS AN ALTIMETER

1. Functions and Button Operations ----------------------------------- 4

2. Hike Mode ---------------------------------------------------------------- 6

3. Ski Mode ------------------------------------------------------------------ 8

4. Fly Mode ---------------------------------------------------------------- 10

5. Altitude Correction ---------------------------------------------------- 12

BASIC KNOWLEDGE OF ALTITUDE MEASURING --------------- 12

TROUBLESHOOTING ------------------------------------------------------ 13

DAILY CARE ------------------------------------------------------------------ 13

SPARE ACCESSORIES --------------------------------------------------- 13

SPECIFICATIONS ----------------------------------------------------------- 14

LIMITED WARRANTY ------------------------------------------------------ 14

INTRODUCTION

Thank you for purchasing CATEYE Model AT-110.

This altimeter is designed to help quantify altitude

data for vertical sports such as, skiing, hiking, climbing, mountaineering, hang-gliding,

parasailing, ballooning, sail-planing and sky-surfing, etc. The patented temperature

compensated pressure captures atmospheric pressure and gives accurate altitude read-

ing in 1 meter or 5 foot resolution. Three types of measuring mode (Hike, Ski and Fly)

allow for meaningful data collection for each sport. The screen has an EL (electro-

luminescent) backlight for night viewing.

Features:

•Displays altitude with 1 meter or 5 feet resolution up to 6000m or +20,000ft.

•Temperature compensated atmospheric pressure sensor.

•Measures atmospheric temperature.

•Audible and visible alarm in the Fly Mode to easily note any ascent or decent.

•Three types of measuring modes designed for the characteristics of different activi-

ties; (Hike, Ski and Fly).

•Shows current altitude in the large display with clock time, temperature, stopwatch,

speed of ascend/descend, altitude gain and loss, on the small display.

•Displays LOG-Book data of highest trip altitude, lowest trip altitude, sum of ascends,

sum of descends.

•Preserves LOG-Book data in memory even after replacing battery.

•Displays in feet or meters, fahrenheit or celsius.

•EL (electro-luminescent) back-lit screen for viewing data at night.

•Audible beep with each button operation.

Before operating, thoroughly familiarize yourself with this manual so that you under-

stand the functions completely. Please keep this manual, along with the warranty card,

for future reference.

FOR SAFE OPERATIONS (IMPORTANT)

For safe and appropriate use, always observe the following.

Caution:

• This altimeter is not intended to be a definitive measuring device.

• Give due consideration to your surroundings. Don’t pay too much atten-

tion to the data on the screen when using.

• Safely dispose of old batteries. Don’t place within reach of children. If swal-

lowed, consult a physician immediately.

Note:

• Please note that atmospheric pressure is effected by the weather. The AT-110 cal-

culates altitude from the changes in atmospheric pressure. Even during stable weather

condition, the altitude reading may change as much as 40m or 130ft, over the course

of the day.

• Select the best-suited mode for your activity.

• Never disassemble the main unit. It can not be re-assembled.

• The main unit is loaded with highly sensitive components. A strong impact may result

in malfunctions.

• Never intentionally submerge the main unit under water. Although the main unit is

water-resistant to normal weather conditions it is not designed to be used underwater.

• Don’t leave the main unit exposed to direct sunlight for extended periods of time.

• If the main unit is heated by strong direct sunlight, the temperature sensor inside of

the main unit may give incorrect temperature readings.

• The atmospheric pressure is continually changing. Thus, the data of the current alti-

tude of one location might fluctuate from day to day depending on the weather.

• The Current altitude should be calibrated (corrected) before each use.

• Sudden temperature change such as moving from inside a heated building to a cold

outside can cause temporary incorrect altitude data.

• Static electricity might cause incorrect data.

• In pressurized aircraft the unit will not give a correct altitude.

• If the sensor cover is clogged with mud or sand, it will not measure accurately. Clean

according to “Daily Care” instructions.

• If the main unit or accessories/attachments become dirty with mud etc., gently wash

with mild soap and wipe dry with a soft cloth. Never apply paint thinner, benzine or

alcohol; damage will result.

NAMES

53 61

4 2 5

ADisplay

1Large Display

2Small Display

3Icon of Ascend

4Icon of Descend

5Icon of Scales/Function

6Icon of Mode

BS/S Button

CMode Button

DLight Button

ESet Button

FAC (All Clear) Button

GBattery Cover

HSensor Cover/Filter

IWrist Band (Accessory)

PREPARATIONS

1. Battery Installation

1. Remove the battery cover on the back, with a coin.

2. Insert a new lithium battery (CR2032) with the (+) pole outward,

as illustrated. Close the cover securely.

3. Press the AC (All Clear) button on the back.

* Battery Life: approx. 4 months (average use of one hour per day;

varies depending on frequency of use)

Note: If the display disappears while press of the Light button,

or often shows irregular altitude, replace the battery.

Caution: Dispose of old batteries properly. Keep batteries out of

reach of children. If swallowed, consult a physician immediately.

2. Data Scale Set Up

First, press the AC (All Clear) button; the entire display will illumi-

nate and then “m”and “°C”symbols appear. Press the S/S button

to chose between “°C”(celsius) and “°F”(fahrenheit). Press the

Mode button to chose between “m (meter)”and “ft (feet)”. Select

the desired scale and press the Set button to fix the scale.

Note: If “°C”(celsius) scale is selected a 24-hour clock is dis-

played. If “°F”(fahrenheit) is selected a 12-hour clock is displayed.

3. Time Set Up

After the data scale is set, the display displays clock set up mode.

With each press of the S/S button, the digits for hours increase by

one. (To increase rapidly, hold down the button.) Press the Mode

button to select the minute digits. Adjust the minutes by pressing the

S/S button. Press the Set button to set the time. After the clock

time is set, the AT-110 defaults to Hike mode.

4. Attaching Wrist Band

Press the main unit onto the ring of the wrist band. It can be mounted

perpendicularly or parallel to the belt. To remove the unit, twist it to

the left or the right.

5. Attaching to Your Body

By using a longer mounting belt (option), the unit can also be at-

tached on your leg, not only on your arm.

1. Adjust the belt length tentatively, according to the part to put the

unit on. (Make it a bit longer than it looks necessary.)

2. Roll the belt around the part to wear the unit, and hook the buckle

on the ring with the buckle lever lifted.

3. Pull the belt end to tighten, and lay down the buckle lever.

4. Pass the belt end through the belt loop.

5. To remove the unit, lift the buckle lever and detach the buckle

from the ring.

Note: Lift the buckle lever, when the buckle is attached to/de-

tached from the ring.

Open CR2032

3-1

3-2 4

Buckle

Belt loop

Ring

E D

Alt. simbol

Temp. simbol

Ring

Hours

Minutes

Twist

Press

HOW TO USE AS AN ALTIMETER

1. Functions and Button Operations

Before Operation:

The initial value of the Current altitude shown on the display may

not indicate the correct altitude of your location. First read through

this section, and then correct the altitude according to the instruc-

tions on page12.

Modes

This unit has three modes; Hike, Ski and Fly. Each mode has its own

characteristics. Select the best-suited mode for your purpose. You

can change the mode during use.

Hike Mode: Suitable for hiking, mountaineering, or other general

activities with gradual changes in altitude.

Ski Mode: Suitable for skiing, snow-boarding, mountain biking, or

other activities where you want to record numbers of

runs.

Fly Mode: Suitable for hang-gliding, paragliding, parajumping,

skysurfing, ballooning, sail-planing or other sky-sports

where there are sudden and significant changes in alti-

tude.

ⓦHow to Shift From One Mode to Another

Hold down the Set button and the mode shifts from Hike to Ski to

Fly.

Functions

Each of the three modes has a Main Screen, Sub Functions and LOG-

Book Functions.

ⓦMain Screen:

The Main Screen gives the basic data of current altitude and time of

day. It is necessary to be in this Main Screen in order to shift between

Sub Functions and LOG-Book Functions.

ⓦSub Function:

This function shows current data and conditions, such as tempera-

ture, stopwatch, etc. The data appears on the lower display. This

data is accessed by pressing the Mode button. The icon tells what

data it is being displayed. On the large display, current altitude is

always viewed. To return to the Main Screen, press the S/S but-

ton in any Sub Function.

ⓦLOG-Book Function:

This function shows data stored in memory, such as highest trip alti-

tude, sum of ascends, etc. The data appears on the large display,

and the name of the LOG-Book data is indicated on the small display.

Hold down

HIKE SKI FLY

HIKE MODE SKI MODE FLY MODE

E E

Current Altitude

Clock Time and Icon

Temperature Stopwatch

Ascend/Descend

Speed

Altitude

Gain & Loss

Ascend Descend

SUB FUNCTION

LOG-BOOK FUNCTION

MAIN

SCREEN

Current Altirude

Clock Time

Highest Trip Alt.

Lowest Trip Alt.

Sum of Ascends

Sum of Descends

Alt. Gain & Loss

Asc./Dsc. Speed

Stopwatch

Temperature

Button

To cycle from one LOG-Book data to another, press the S/S button.

To return to the Main screen, press the Mode button in any time.

Using the Stopwatch

In the stopwatch Sub Function the Set button, the stopwatch starts/

stops. To reset it to zero, refer to the following reset operation (press the

S/S button and Mode button simultaneously). When the stopwatch

is active, the stopwatch icon blinks.

Resetting Data

Display the data function you want to reset. Then press the S/S button

and Mode button simultaneously. The data resets to zero. If the stop-

watch is still active (running), when it is reset, the stopwatch continues

counting after returning to 00:00:00.

Note: If this operation is done in the Main screen, the corrected figure of

the current altitude is reset. (Refer to page 12 - "Altitude Correction".)

Note: If you are resetting the data of highest trip altitude or lowest trip

altitude, firstly the screen shows the largest figure of its range; and then

the reset data becomes the same value as the current altitude.

Light Button

Pressing the Light button will illuminate the EL (electro- luminescent)

back-lit screen for approx. 2 seconds.

Set Button

This button is used: •to shift from one mode to another

•to start/stop the stopwatch

•to calibrate (correct) the current altitude, or to fix

the scale/clock time.

AC (All Clear) Button (on the back)

This button is used to set up the programming of the main unit after hav-

ing replaced the battery, or when irregular display occurs during use.

When this button is pressed, all displays illuminate and then only the

scale symbols appears. The scale and clock time must be set again ac-

cording to “PREPARATIONS”.

Preserving LOG-Book Data

The LOG-Book data stored in memory in each mode will not be lost even

after the AC (All Clear) button is pressed, because the data is pre-

served in EE-PROM memory. LOG-Book data is cleared when the S/

S button and the Mode button are pressed simultaneously and only

then is the displayed LOG data reset. EE-PROM calculates the data from

when the clock time of your unit passes 0:00 every day.

Power Saving Function

If no buttons are pressed for five minutes, the power saving function auto-

matically starts. To release this function, press either S/S, Mode or

Set buttons for more than 1 second. If the unit perceives an altitude

change of more than 4 meters or 10 feet, the power saving function is

turned off.

•In the power saving function:

data of altitude and temperature are still updated every 2 minutes.

•In the standard waking mode:

data of altitude is updated every second and temperature is updated

every 20 seconds.

Highest Trip Altitude Lowest Trip Altitude Sum of Ascends Sum of Descends

* The illustration shows an example of Hike mode.

E D

Temperature

Stopwatch

Ascend/

Descend

Speed

Altitude

Gain & Loss

Sum of

Descends

Sum of

Ascends

Lowest

Trip Altitude

Highest

Trip Altitude

In the Sub/LOG-book Functions

How to Reset the Data

How to Shift to

Another Mode

SUB FUNCTION LOG-BOOK FUNCTION

E D

Press

Simultaneously

Hold down

Current Altitude

Clock Time E

MAIN SCREEN

START

STOP

CORRECTION

ACTUAL

ALTITUDE

Shortcut Key

To return to the Main Screen

from the LOG-Book Function,

press Mode button. To return

to the Main Screen from the Sub

Function, press S/S button.

HIKE

Data

Main Screen

Current altitude: Indicates the current altitude (above sea level) of the present spot on

the large display, in 1 meter or 5 foot increments.

Clock Time: Shows the present time on the small display. If the temperature scale

is set as “°C”(celsius), the clock reads as a 24-hour clock; if the scale

is set as “°F”(fahrenheit), the clock becomes 12-hour clock.

Sub Function (Always displays the current altitude on the large display)

Temperature: Measures the atmospheric temperature every 20 seconds and dis-

plays it on the small display, in 1 degree increment.

Stopwatch: Shows the elapsed time from its start to the current point. It is dis-

played in units of minutes and seconds up to ten minutes; and in units

of hours and minutes when it exceeds ten minutes. If the AT-110

clock is set as a 24 hour clock, the stopwatch continues to count up to

24 hours. If the clock-time is set as a 12-hour clock, the stopwatch

continues to count up to 12 hours.

Ascend/Descend Speed: Indicatestheaveraged speed of ascend/descend, in the scale of meter

or feet per second, on the small display in increments of 0.1meter per

second or 0.3 feet per second.

Altitude Gain & Loss: Indicates the altitude difference between the start and the current

point, on the small display. The figure on the display shows the 1/10

value, so the symbol of “x10”appears.

LOG-Book Function

Highest Trip Altitude: Indicates the highest altitude ever made since the start to the current

point, on the large display “Ahi”on the small display stands for “Alti-

tude High”.

Lowest Trip Altitude: Indicates the lowest altitude ever made since the start to the current

point, on the large display. “ALo”on the small display stands for “Alti-

tude Low”.

Sum of Ascends: Indicates the total of ascends (altitude gain) on the large display. The

data of descend (altitude loss) is not included. The figure on the dis-

play shows the 1/10 value, so the symbol of “x10”appears. “ASC”on

the small display stands for “Altitude Sum Count”.

Sum of Descends: Indicates the total of descends (altitude loss) on the large display.

The data of ascends (altitude gain) is not included. The figure on the

display shows the 1/10 value, so the symbol of “x10”appears. “dSC”

on the small display stands for “Descent Sum Count”.

2. Hike Mode

This mode is designed for general activities, such as hiking, mountaineering, cross country, etc.

Its Sub Function and LOG-Book Function is illustrated as follows:

Characteristics of Hike Mode

•Suitable for general activities, such as hiking, etc.

•Desirable for slow change of altitude.

Temperature

Stopwatch

Ascend/

Descend

Speed

Altitude

Gain & Loss

Sum of

Runs

Sum of

Descends

Lowest

Trip Altitude

Highest

Trip Altitude

In the Sub/LOG-book Functions

How to Reset the Data

How to Shift to

Another Mode

SUB FUNCTION LOG-BOOK FUNCTION

E D

Press

Simultaneously

Hold down

Current Altitude

Clock Time E

MAIN SCREEN

START

STOP

CORRECTION

ACTUAL

ALTITUDE

SKI

Shortcut Key

To return to the Main Screen

from the LOG-Book Function,

press Mode button. To return

to the Main Screen from the Sub

Function, press S/S button.

Data

Main Screen

Current altitude: Indicates the current altitude (above sea level) of the present spot on

the large display, in 1 meter or 5 foot increments.

Clock Time: Shows the present time on the small display. If the temperature scale

is set as “°C”(celsius), the clock reads as a 24-hour clock; if the scale

is set as “°F”(fahrenheit), the clock becomes 12-hour clock.

Sub Function (Always displays the current altitude on the large display)

Temperature: Measures the atmospheric temperature every 20 seconds and dis-

plays it on the small display, in 1 degree increment.

Stopwatch: Shows the elapsed time from its start to the current point. It is dis-

played in units of minutes and seconds up to ten minutes; and in units

of hours and minutes when it exceeds ten minutes. If the AT-110

clock is set as a 24 hour clock, the stopwatch continues to count up to

24 hours. If the clock-time is set as a 12-hour clock, the stopwatch

continues to count up to 12 hours.

Ascend/Descend Speed: Indicatestheaveraged speed of ascend/descend, in the scale of meter

or feet per second, on the small display in increments of 0.1meter per

second or 0.3 feet per second.

Altitude Gain & Loss: Indicates the altitude difference between the start and the current

point, on the small display. The figure on the display shows the 1/10

value, so the symbol of “x10”appears.

LOG-Book Function

Highest Trip Altitude: Indicates the highest altitude ever made since the start to the current

point, on the large display. “Ahi”on the small display stands for “Alti-

tude High”.

Lowest Trip Altitude: Indicates the lowest altitude ever made since the start to the current

point, on the large display. “ALo”on the small display stands for “Alti-

tude Low”.

Sum of Descends: Indicates the total of descends (altitude loss) on the large display.

The data of ascends (altitude gain) is not included. The figure on the

display shows the 1/10 value, so the symbol of “x10”appears. “dSC”

on the small display stands for “Descent Sum Count”.

Sum of Runs: Calculates the number of runs, judging from the altitude change, and

shows it on the large display. “run”on the small display stands for

“Number of Runs”. The AT-110 counts a “run”when a descent of

more than 10 meters’or 30 feet altitude difference is recorded within

20 seconds. Then next run is counted, only when descend is done

again after ascend of more than 10 meters’or 30 feet altitude differ-

ence is made within 20 seconds (such as when going up with lift).

Thus, a “run”might not be calculated if the ascent is on foot, or slope

is gentle.

3. Ski Mode

This mode is designed for the sport activities, such as skiing, snow-boarding, etc. The special

feature of this mode is that it counts the number of runs or “sum of runs”. The Sub Function and

LOG-Book Function of this mode is illustrated as follows:

Characteristics of Ski Mode

•Suitable for sports that repeat (ascends and descends) runs.

•Desirable for slow change of altitude.

Table of contents

Other Cateye Measuring Instrument manuals

Cateye

Cateye VELO WIRELESS Plus CC-VT210W User manual

Popular Measuring Instrument manuals by other brands

Suaoki

Suaoki D40 user manual

Elster

Elster BK-G1.6 operating instructions

Endress+Hauser

Endress+Hauser Deltabar FMD71 technical information

Duratool

Duratool D03128 manual

Vega

Vega VEGAPULS 65 Quick setup guide

Tonghui

Tonghui TH2618B Operation manual

Tenmars

Tenmars TM-801 user manual

MSR

MSR 145 user manual

TPS

TPS WP-82 manual

ELMETRON

ELMETRON CP-511 user manual

PCB Piezotronics

PCB Piezotronics 003C30 Installation and operating manual

Tenma

Tenma 72-10465 manual

Endress+Hauser

Endress+Hauser Proline Promag 50 Brief operating instructions

Siemens

Siemens SITRANS F Coriolis FCT030 Function manual

KLINGER

KLINGER CMF V Series instruction manual

EXFO

EXFO FTB-2 Notice

Keysight

Keysight M8290A Getting started guide

ADTEK

ADTEK MW-5 operating manual
