MAP 5000

ICP‑MAP5000‑2 / ICP‑MAP5000‑COM / ICP‑MAP5000‑S /

ICP‑MAP5000‑SC

en Installation manual

MAP 5000 Table of contents | en 3

Bosch Sicherheitssysteme GmbH Installation manual 2018.08 | 23 | F.01U.168.332

Table of contents

1Introduction 5

1.1 Short information 5

1.2 Listings and approvals 5

1.3 Battery handling 5

1.4 Installation considerations 5

1.5 Planning the system 6

1.5.1 Planning the system with IPP-MAP0005 power supply 7

1.5.2 Planning the system with ICP-MAP0012 CAN splitter module 11

1.6 System overview 12

2Installation 15

2.1 Removing the enclosure knockouts 15

2.2 Installing the tamper switch rail 16

2.3 Mounting the enclosure 17

2.4 Checking the AC connection 19

2.5 Installing the power supply and power supply accessories 19

2.6 Installing the TAE box 23

2.7 Installing the accessory mounting plate 24

2.8 Installing the 12 V converter 26

2.9 Installing the fuse plate (SIV) 27

2.10 Installing the AT 2000 communicator 28

2.11 Installing the hinged mounting plate 33

2.12 Mounting the main panel 36

2.13 Installing the ICP-COM-IF relay module 37

2.14 Installing and connecting the ITS-MAP0008 wireless modem 38

2.15 Antennas 40

3Connections 41

3.1 Connecting the data bus 41

3.1.1 Internal / external data bus 43

3.1.2 Topology of the external data bus 43

3.1.3 Splitting the external data bus with a CAN splitter module 44

3.2 Connecting the control center 44

3.3 Connecting the main panel 45

3.4 Connecting the power supply 46

3.5 Connecting the LSN gateway 47

3.6 Optional connections 49

3.7 Installing and connecting the tamper switch 51

3.8 Installing the ICP-MAP0060 enclosure lockset 53

3.9 Installing the control center 55

3.10 Final power connections 55

3.11 IP Interface 56

4Initial set-up and programming 57

4.1 Initial set-up 57

4.2 Programming 57

4.2.1 Help for the programming software 58

4.2.2 Standard-compliant programming 58

4.3 Panel software 58

4.3.1 Checking the software version 58

4.3.2 Software updates 59

4en | Table of contents MAP 5000

2018.08 | 23 | F.01U.168.332 Installation manual Bosch Sicherheitssysteme GmbH

4.3.3 Manufacturer authorization 59

4.4 Completing the installation 59

4.5 Point types and point evaluation 59

4.6 Output functions 60

4.6.1 Programmable output signals 60

4.6.2 Sirens and communicator in accordance with EN50131 grade 3 62

5Enclosure options 64

5.1 ICP-MAP0115 power enclosure 64

5.2 Rack mount option for ICP-MAP0120 expansion enclosure 65

6Maintenance and service 66

6.1 General information 66

6.2 Installer button 66

7Technical Specifications 68

8Appendices 71

8.1 Requirements in accordance with VdS class C 71

8.1.1 Selecting the default setting 71

8.1.2 Power supply for areas 71

8.1.3 Control centers 71

8.1.4 Connection to a management system 71

8.1.5 Printer connection 71

8.1.6 Access levels 71

8.2 Requirements in accordance with EN 50131 grade 3 74

8.2.1 Selecting the default setting 74

8.2.2 Connectable peripherals 74

8.2.3 Arming / disarming without entry / exit delay 74

8.2.4 Arming / disarming with entry / exit delay 74

8.2.5 Arming with automatic bypass 76

8.2.6 Automatic arming / disarming 76

8.2.7 Alarm output via siren and communicator 77

8.2.8 Connection to a management system 77

8.2.9 Printer connection 77

8.2.10 Access levels 77

8.2.11 Additional functions of the main panel 80

8.3 Requirements in accordance with SES 80

8.3.1 Selecting the default setting 80

8.3.2 Automatic arming / disarming 81

8.3.3 Areas with blocking time 81

8.3.4 Access Levels 81

8.3.5 Tamper surveillance of the main panel 84

8.4 Alarm reporting 85

8.5 History log 86

MAP 5000 Introduction | en 5

Bosch Sicherheitssysteme GmbH Installation manual 2018.08 | 23 | F.01U.168.332

1 Introduction

1.1 Short information

This manual describes the installation, wiring, initial set-up and maintenance of the MAP 5000

system.

It is applicable for all MAP 5000 kits and the following main panels including all accessory

MAP 5000 products:

– MAP Main Panel (ICP-MAP5000-2)

– MAP Main Panel with IP Communicator (ICP-MAP5000-COM) including the MAP GSM

module (ITS-MAP0008).

– MAP Main Panel Small (ICP-MAP5000-S)

– MAP Main Panel Small with IP Communicator (ICP-MAP5000-SC) including the MAP GSM

module (ITS-MAP0008).

1.2 Listings and approvals

The system is designed to comply with the certifications and approvals listed here.

Region Agency Certification

Germany VdS Class C, VdS G 111040

Europe CE Conformité Européene

Europe EN EN 50131-1:2006 + A1:2009

EN 50131-3:2009

EN 50131-6:2008

EN 50136-2/SP4/DP3

EN 50131-10

Switzerland SES Association of Swiss Installers of Security Systems

Edition V3 / 01.01.2011-d

France AFNOR / CNPP

Cert.

NF&A2P Grade 3

Certificate Number ICP-MAP5000-2: 1133400003

Certificate Number ICP-MAP5000-COM: 1230200016

According to NF324-H58

1.3 Battery handling

The battery terminals must be covered after installation in order to avoid short circuits.

Suitable terminal covers are included in the scope of delivery of the power supply.

Danger!

Electrictity

Do not short-circuit the battery in the host alarm system. A short-circuited battery can deliver

large currents that might result in serious burns or create a fire hazard.

Further information is available at http://www.boschsecurity.com/standards.

1.4 Installation considerations

– When installing this system, ensure that all local and national wiring codes are met.

– Only authorized service personnel is allowed to install this system.

– Use only the installation material recommended by BOSCH Security Systems to ensure

error-free operation.

6en | Introduction MAP 5000

2018.08 | 23 | F.01U.168.332 Installation manual Bosch Sicherheitssysteme GmbH

– Follow anti-static procedures when handling system components. Ensure that you are

properly grounded to discharge any static charge before you work with system

components.

– Install all components in dry, maintained interior rooms.

– Install the system in a centrally located room that is near the AC Power MAINS.

– Because the panel is permanently connected equipment, a readily accessible disconnect

device must be included into the building installation wiring.

Danger!

Electric shock

Danger of electric shock if live parts are touched. The alarm system is designed for an IT-

power distribution system (230 V). Switch off the power supply of the alarm system before

carrying out maintenance or installation work.

1.5 Planning the system

MAP control panel enclosure kit

The ICP-MAP0111 panel enclosure kit is the main system enclosure. This enclosure is designed

to contain the following components:

– ICP-MAP5000 main panel1

– ICP-MAP0007 DE module1

– ICP-MAP0010 LSN gateway1

– ICP-MAP0012 CAN splitter1

– AT 2000 communicator2

– IPP-MAP0005 power supply3

– ICP-MAP0065 AC terminal block4

– ICP-MAP0050 control panel enclosure tamper switch

– Two batteries (maximum 45 Ah each)

Use the ICP-MAP0120 expansion enclosure kit when the system requirements for power and /

or other remote devices exceed the capacity provided by the ICP-MAP0111 panel enclosure

kit6.

MAP expansion enclosure kit

The ICP-MAP0120 expansion enclosure kit is designed to contain the following components:

– IPP-MAP0005 power supply3

– ICP-MAP0010 LSN gateway5

– ICP-MAP0012 CAN splitter1

– ICP-MAP0065 AC terminal block4

– ICP-MAP0055 expansion enclosure tamper switch

– Two batteries (maximum 18 Ah each)

Use the ICP-MAP0115 power enclosure kit when system power requirements exceed the

power capacity of the ICP-MAP0111 panel enclosure kit6.

MAP power enclosure kit

The ICP-MAP0115 power enclosure kit is designed to contain the following components:

– IPP-MAP0005 power supply3

– ICP-MAP0065 AC terminal block4

– ICP-MAP0050 control panel enclosure tamper switch

– Four batteries (maximum 40 Ah each)

MAP 5000 Introduction | en 7

Bosch Sicherheitssysteme GmbH Installation manual 2018.08 | 23 | F.01U.168.332

1 This module mounts on the ICP-MAP0025 hinged mounting plate.

2 This module mounts on the ICP-MAP0020 accessory mounting plate, which mounts to the

back of the enclosure.

3 When determining the number of power supplies, it is also necessary to take into account

the inrush current of loads (refer to Planning the system with IPP-MAP0005 power supply, page

7).

4 This assembly is only required if the IPP-MAP0005 power supply is installed.

5 When one or more ICP-MAP0010 LSN gateways are operated remotely, there must be one

IPP-MAP0005 power supply in the same enclosure.

6 Mount the enclosure directly under or at the side (top edge flush) of the control panel

enclosure.

1.5.1 Planning the system with IPP-MAP0005 power supply

Number of power supplies

To guarantee a reliable system booting, take into account the following:

– Inrush current of the connected loads

– Current limit of the IPP-MAP0005 power supply

– Current limit of the ICP-MAP5000 main panel

Notice!

The normal operating condition is not the subject of these considerations.

Load inrush current

– IUI-MAP0001-2 control center: max. 800 mA

– ICP-MAP0010 LSN module: max. 1000 mA, AUX is switched on later

– ICP-MAP0007-2 DE module: negligible

Current limitation

– Power supply per output A / B (short-time): 3.2 A

– Main panel at external BDB: 1.6 A

Refer to Typical configuration with ICP-MAP0111 panel enclosure, page 8.

Definition of power supply segment

A power supply segment is a power supply with all loads supplied by the power supply.

Power supply segment

4-wire cables are used for load connection within the power supply segment.

The following conditions must be taken into account when planning in order to guarantee a

reliable system booting:

8en | Introduction MAP 5000

2018.08 | 23 | F.01U.168.332 Installation manual Bosch Sicherheitssysteme GmbH

Condition 1

3-wire cables are always used for connections between power supply segments (without +28

V, red wire)

Figure1.1: Wiring of power supply segments

Condition 2

Charged batteries must be connected to the power supply to ensure reliable system start-up.

Figure1.2: Batteries for system booting

Condition 3

To ensure reliable system start-up, it is necessary to take into account the cable length and

wire gauge:

– between power supply and first control center

– between control centers

Refer to , page 10.

Typical configuration with ICP-MAP0111 panel enclosure

Main panel - DE module - 3 LSN gateway modules - max. 2 control centers

MAP 5000 Introduction | en 9

Bosch Sicherheitssysteme GmbH Installation manual 2018.08 | 23 | F.01U.168.332

ICP-MAP0111

Figure1.3: Wiring with ICP-MAP0111

Key Description

1 Current limitation

2 4-wire connection, take into account cable length

3 3-wire connection to the next power supply segment

4 Short-time current limitation to 3.2 A per output A / B

5 Current limitation to 1.6 A between internal and external BDB

Remote operation with ICP-MAP0120 expansion enclosure

Figure1.4: 2 LSN modules with up to 4 control centers

10 en | Introduction MAP 5000

2018.08 | 23 | F.01U.168.332 Installation manual Bosch Sicherheitssysteme GmbH

Figure1.5: Up to 8 control centers

Key Description

1 Current limitation

2 4-wire connection, take into account cable length, refer to , page 10

3 3-wire connection to the next power supply segment

4 Short-time current limitation to 3.2 A per output A / B

Cable length

The maximum number of control centers that can be supplied by one power supply depends

greatly on the length and diameter of the cable used.

Wire diameter Wire cross-

section

Length A Length B Length C Length D

0.8 mm 0.503 mm2 . 325 m - - - - - - - - -

0.8 mm 0.503 mm2 . 100 m 135 m - - - - - -

0.8 mm 0.503 mm2 . 50 m 225 m - - - - - -

0.8 mm 0.503 mm2 . 50 m 50 m 50 m - - -

1.0 mm 0.785 mm2 . 500 m - - - - - - - - -

1.0 mm 0.785 mm2 . 175 m 175 m - - - - - -

1.0 mm 0.785 mm2 . 100 m 325 m - - - - - -

1.0 mm 0.785 mm2 . 100 m 75 m 75 m - - -

1.0 mm 0.785 mm2 . 50 m 400 m - - - - - -

1.0 mm 0.785 mm2 . 50 m 125 m 125 m - - -

1.0 mm 0.785 mm2 . 50 m 50 m 50 m 50 m

Tab.1.1: Cable lengths

The following applies for VdS

For remote operation of the IPP-MAP0005 power supply, a control center assigned to the

same area must be provided for indication of power supply trouble (trouble in mains supply /

battery).

This manual suits for next models

Table of contents

Other Bosch Security System manuals

Bosch

Bosch Solution 16i User manual

Bosch

Bosch D9412GV4 User manual

Bosch

Bosch LTC 8900 Series User manual

Bosch

Bosch LBB 1946 User manual

Bosch

Bosch Solution 64 User manual

Bosch

Bosch AVIOTEC IPSTARLIGHT 8000 User manual

Bosch

Bosch Solution 64 User manual

Bosch

Bosch FMC-300RW-GSRRD User manual

Bosch

Bosch D1260 Series User manual

Bosch

Bosch Plena Power Amplifier Guide

Bosch

Bosch DINION 4000 Instructions for use

Bosch

Bosch OD850F1 Operation and maintenance manual

Bosch

Bosch VSS7902/00T Quick start guide

Bosch

Bosch CCS 800 Ultro User manual

Bosch

Bosch SOLUTION 3000 User manual

Bosch

Bosch AMAX 2100 User manual

Bosch

Bosch AVENAR all-in-one 4000 User manual

Bosch

Bosch PRAESENSA User manual

Bosch

Bosch DIVAR DIP-7080-00N User manual

Bosch

Bosch DIVAR IP 7000 2U User manual

Bosch

Bosch FRP-OW3000 User manual

Bosch

Bosch APC-AMC2-4W User manual

Bosch

Bosch AMAX panel 2000 ICP-AMAX-P User manual

Bosch

Bosch FLM-420-RLE-S User manual

Popular Security System manuals by other brands

Inner Range

Inner Range Concept 2000 user manual

Climax

Climax Mobile Lite R32 Installer's guide

CADDX

CADDX NX-6 user manual

FBII

FBII XL-31 Series installation instructions

Johnson Controls

Johnson Controls PENN Connected PC10 Install and Commissioning Guide

Aeotec

Aeotec Siren Gen5 quick start guide

Blaupunkt

Blaupunkt SA 2700 quick start guide

IDEAL

IDEAL Accenta Engineering information

AJAX

AJAX DoubleButton user manual

Swann

Swann SW-P-MC2 Specifications

Ecolink

Ecolink Siren+Chime user manual

Digital Monitoring Products

Digital Monitoring Products XR150 user guide

EDM

EDM Solution 6+6 Wireless-AE installation manual

Highway Safety Group

Highway Safety Group EA401 user manual

Siren

Siren LED GSM operating manual

Detection Systems

Detection Systems 7090i Installation and programming manual

Se-Kure Controls

Se-Kure Controls MicroMini SK-4841 instructions

Siemens

Siemens FDM273 manual
