BLOTZ B10-MW-001 User manual

B10-MW-001

10mm 3x2 Residential

Designed and made in the UK.

This is a model kit and is not intended for

ersons under 14 years old.

This kit consists of:

B10-MW-100: Foyer (2 sheets)

B10-MW-150: Middle (1 sheet)

B10-MW-200: Roof (1 sheet)

Blotz

90 Fullers Avenue

Cricklade

SN6 6EU

[email protected]

www.blotz.co.uk

10mm 3x2 Residential Foyer

B10-MW-100

Please read these instructions fully before starting construction.

PVA or equivalent glue will be required to stick sections together.

Sand paper can be used to gently clean any joints.

A sharp modelling knife will be required to remove sections from the sprue. Please use knives with due

care and remember to cut away from yourself at all times.

During the construction of this model you may find it convenient to use pegs / elastic bands to hold

pieces in place while you allow glue to dry.

Foyer (B10-MW-100)

Start by removing the sections shown above (left)

from the sprue. There are enough parts to create

both doorway sections.

Glue them together as shown in the image on the

right.

Glue each doorway to the back of the long sides using

the lugs/holes provided.

At the same time glue a triangular bracer to the

back of the long sides at each end. Leave these to

dry.

Glue the shorter end walls into place to give a hollow

rectangle. Once this is dry glue the decorative

columns and balconies into position.

10mm 3x2 Residential Middle

B10-MW-150

Please read these instructions fully before starting construction.

PVA or equivalent glue will be required to stick sections together.

Sand paper can be used to gently clean any joints.

A sharp modelling knife will be required to remove sections from the sprue. Please use knives with due

care and remember to cut away from yourself at all times.

During the construction of this model you may find it convenient to use pegs / elastic bands to hold

pieces in place while you allow glue to dry.

Mid-Section (B10-MW-150)

Remove the four walls and four triangular corner

bracers from the sprue. Glue the triangles to

non-etched side of the two long walls as shown

in the example above. Leave to dry.

Once the bracers are dry apply a little glue to the side

lugs and glue the shorter walls in place as shown

above. You should now have a hollow square

structure. Leave it to dry.

Now remove the four rectangles from the sprue.

Each of these has a line etched across it. Apply

glue to one side of the line only and attach it (as

shown) to the centre bottom edge of each wall.

Finally glue the balconies into position.
