Atmel AT32UC3A3256S User manual

Features

•High Performance, Low Power 32-bit Atmel®AVR®Microcontroller

– Compact Single-Cycle RISC Instruction Set Including DSP Instruction Set

– Read-Modify-Write Instructions and Atomic Bit Manipulation

– Performing up to 1.51DMIPS/MHz

• Up to 126 DMIPS Running at 84MHz from Flash (1 Wait-State)

• Up to 63 DMIPS Running at 42MHz from Flash (0 Wait-State)

– Memory Protection Unit

•Multi-Layer Bus System

– High-Performance Data Transfers on Separate Buses for Increased Performance

– 8 Peripheral DMA Channels (PDCA) Improves Speed for Peripheral

Communication

– 4 generic DMA Channels for High Bandwidth Data Paths

•Internal High-Speed Flash

– 256KBytes, 128KBytes, 64KBytes versions

– Single-Cycle Flash Access up to 36MHz

– Prefetch Buffer Optimizing Instruction Execution at Maximum Speed

– 4ms Page Programming Time and 8ms Full-Chip Erase Time

– 100,000 Write Cycles, 15-year Data Retention Capability

– Flash Security Locks and User Defined Configuration Area

•Internal High-Speed SRAM

– 64KBytes Single-Cycle Access at Full Speed, Connected to CPU Local Bus

– 64KBytes (2x32KBytes with independent access) on the Multi-Layer Bus System

•Interrupt Controller

– Autovectored Low Latency Interrupt Service with Programmable Priority

•System Functions

– Power and Clock Manager Including Internal RC Clock and One 32KHz Oscillator

– Two Multipurpose Oscillators and Two Phase-Lock-Loop (PLL),

– Watchdog Timer, Real-Time Clock Timer

•External Memories

– Support SDRAM, SRAM, NandFlash (1-bit and 4-bit ECC), Compact Flash

– Up to 66 MHz

•External Storage device support

– MultiMediaCard (MMC V4.3), Secure-Digital (SD V2.0), SDIO V1.1

– CE-ATA V1.1, FastSD, SmartMedia, Compact Flash

– Memory Stick: Standard Format V1.40, PRO Format V1.00, Micro

– IDE Interface

•One Advanced Encryption System (AES) for AT32UC3A3256S, AT32UC3A3128S,

AT32UC3A364S, AT32UC3A4256S, AT32UC3A4128S and AT32UC3A364S

– 256-, 192-, 128-bit Key Algorithm, Compliant with FIPS PUB 197 Specifications

– Buffer Encryption/Decryption Capabilities

•Universal Serial Bus (USB)

– High-Speed USB 2.0 (480Mbit/s) Device and Embedded Host

– Flexible End-Point Configuration and Management with Dedicated DMA Channels

– On-Chip Transceivers Including Pull-Ups

•One 8-channel 10-bit Analog-To-Digital Converter, multiplexed with Digital IOs.

•Two Three-Channel 16-bit Timer/Counter (TC)

•Four Universal Synchronous/Asynchronous Receiver/Transmitters (USART)

– Fractionnal Baudrate Generator

32-bit AVR

Microcontroller

AT32UC3A3256S

AT32UC3A3256

AT32UC3A3128S

AT32UC3A3128

AT32UC3A364S

AT32UC3A364

AT32UC3A4256S

AT32UC3A4256

AT32UC3A4128S

AT32UC3A4128

AT32UC3A464S

AT32UC3A464

32072H-AVR32–10/2012

32072H–AVR32–10/2012

AT32UC3A3

– Support for SPI and LIN

– Optionnal support for IrDA, ISO7816, Hardware Handshaking, RS485 interfaces and Modem Line

•Two Master/Slave Serial Peripheral Interfaces (SPI) with Chip Select Signals

•One Synchronous Serial Protocol Controller

– Supports I2S and Generic Frame-Based Protocols

•Two Master/Slave Two-Wire Interface (TWI), 400kbit/s I2C-compatible

•16-bit Stereo Audio Bitstream

– Sample Rate Up to 50 KHz

•QTouch®Library Support

– Capacitive Touch Buttons, Sliders, and Wheels

– QTouch and QMatrix Acquisition

•On-Chip Debug System (JTAG interface)

– Nexus Class 2+, Runtime Control, Non-Intrusive Data and Program Trace

•110 General Purpose Input/Output (GPIOs)

– Standard or High Speed mode

– Toggle capability: up to 84MHz

•Packages

– 144-ball TFBGA, 11x11 mm, pitch 0.8 mm

– 144-pin LQFP, 22x22 mm, pitch 0.5 mm

– 100-ball VFBGA, 7x7 mm, pitch 0.65 mm

•Single 3.3V Power Supply

32072H–AVR32–10/2012

AT32UC3A3

1. Description The AT32UC3A3/A4 is a complete System-On-Chip microcontroller based on the AVR32 UC

RISC processor running at frequencies up to 84MHz. AVR32 UC is a high-performance 32-bit

RISC microprocessor core, designed for cost-sensitive embedded applications, with particular

emphasis on low power consumption, high code density and high performance.

The processor implements a Memory Protection Unit (MPU) and a fast and flexible interrupt con-

troller for supporting modern operating systems and real-time operating systems. Higher

computation capabilities are achievable using a rich set of DSP instructions.

The AT32UC3A3/A4 incorporates on-chip Flash and SRAM memories for secure and fast

access. 64 KBytes of SRAM are directly coupled to the AVR32 UC for performances optimiza-

tion. Two blocks of 32 Kbytes SRAM are independently attached to the High Speed Bus Matrix,

allowing real ping-pong management.

The Peripheral Direct Memory Access Controller (PDCA) enables data transfers between

peripherals and memories without processor involvement. The PDCA drastically reduces pro-

cessing overhead when transferring continuous and large data streams.

The Power Manager improves design flexibility and security: the on-chip Brown-Out Detector

monitors the power supply, the CPU runs from the on-chip RC oscillator or from one of external

oscillator sources, a Real-Time Clock and its associated timer keeps track of the time.

The device includes two sets of three identical 16-bit Timer/Counter (TC) channels. Each chan-

nel can be independently programmed to perform frequency measurement, event counting,

interval measurement, pulse generation, delay timing and pulse width modulation. 16-bit chan-

nels are combined to operate as 32-bit channels.

The AT32UC3A3/A4 also features many communication interfaces for communication intensive

applications like UART, SPI or TWI. The USART supports different communication modes, like

SPI Mode and LIN Mode. Additionally, a flexible Synchronous Serial Controller (SSC) is avail-

able. The SSC provides easy access to serial communication protocols and audio standards like

I2S.

The AT32UC3A3/A4 includes a powerfull External Bus Interface to interface all standard mem-

ory device like SRAM, SDRAM, NAND Flash or parallel interfaces like LCD Module.

The peripheral set includes a High Speed MCI for SDIO/SD/MMC and a hardware encryption

module based on AES algorithm.

The device embeds a 10-bit ADC and a Digital Audio bistream DAC.

The Direct Memory Access controller (DMACA) allows high bandwidth data flows between high

speed peripherals (USB, External Memories, MMC, SDIO, ...) and through high speed internal

features (AES, internal memories).

The High-Speed (480MBit/s) USB 2.0 Device and Host interface supports several USB Classes

at the same time thanks to the rich Endpoint configuration. The Embedded Host interface allows

device like a USB Flash disk or a USB printer to be directly connected to the processor. This

periphal has its own dedicated DMA and is perfect for Mass Storage application.

AT32UC3A3/A4 integrates a class 2+ Nexus 2.0 On-Chip Debug (OCD) System, with non-intru-

sive real-time trace, full-speed read/write memory access in addition to basic runtime control.

32072H–AVR32–10/2012

AT32UC3A3

2. Overview

2.1 Block Diagram

Figure 2-1. Block Diagram

AVR32UC

CPU

NEXUS

CLASS 2+

OCD

INSTR

INTERFACE

DATA

INTERFACE

TIMER/COUNTER

0/1

INTERRUPT

CONTROLLER

REAL TIME

COUNTER

PERIPHERAL

DMA

CONTROLLER

256/128/64

FLASH

HSB-PB

BRIDGE B

HSB-PB

BRIDGE A

MEMORY INTERFACE

MM M

EXTERNAL

INTERRUPT

CONTROLLER

HIGH SPEED

BUS MATRIX

FAST GPIO

GENERAL PURPOSE IOs

64 KB

SRAM

GENERAL PURPOSE IOs

A[2..0]

B[2..0]

CLK[2..0]

EXTINT[7..0]

SCAN[7..0]

NMI

GCLK[3..0]

XIN32

XOUT32

XIN0

XOUT0

RESET_N

EXTERNAL BUS INTERFACE

(SDRAM, STATIC MEMORY, COMPACT

FLASH & NAND FLASH)

CAS

RAS

SDA10

SDCK

SDCKE

SDWE

NCS[5..0]

NRD

NWAIT

NWE0

DATA[15..0]

USB HS

INTERFACE

DMA

VBOF

DMFS, DMHS

32 KHz

OSC

115 kHz

RCSYS

OSC0

PLL0

USART3

SERIAL

PERIPHERAL

INTERFACE 0/1

TWO-WIRE

INTERFACE 0/1

DMA

DMADMA

RXD

TXD

CLK

MISO, MOSI

NPCS[3..1]

TWCK

TWD

USART1

DMA

RXD

TXD

CLK

RTS, CTS

DSR, DTR, DCD, RI

USART0

USART2

DMA

RXD

TXD

CLK

RTS, CTS

SYNCHRONOUS

SERIAL

CONTROLLER

DMA

TX_CLOCK, TX_FRAME_SYNC

RX_DATA

TX_DATA

RX_CLOCK, RX_FRAME_SYNC

ANALOG TO

DIGITAL

CONVERTER

DMA

AD[7..0]

WATCHDOG

TIMER

XIN1

XOUT1 OSC1

PLL1

SPCK

JTAG

INTERFACE

MCKO

MDO[5..0]

MSEO[1..0]

EVTI_N

EVTO_N

TCK

TDO

TDI

TMS

POWER

MANAGER

RESET

CONTROLLER

ADDR[23..0]

SLEEP

CONTROLLER

CLOCK

CONTROLLER

CLOCK

GENERATOR

FLASH

CONTROLLER

CONFIGURATION REGISTERS BUS

MEMORY PROTECTION UNIT

HSB

NWE1

NWE3

PBA

PBB

NPCS0

LOCAL BUS

INTERFACE

AUDIO

BITSTREAM

DAC

DMA

DATA[1..0]

DATAN[1..0]

MULTIMEDIA CARD

& MEMORY STICK

INTERFACE

CLK

CMD[1..0]

DATA[15..0]

DMA

AES

DMA

CFCE1

CFCE2

CFRW

NANDOE

NANDWE

32KB RAM

HRAM0/ 1

DPFS, DPHS

USB_VBIAS

USB_VBUS

VDDIN

VDDCORE

GNDCORE

DMACA

1V8

Regulator

TWALM

32072H–AVR32–10/2012

AT32UC3A3

2.2 Configuration Summary

The table below lists all AT32UC3A3/A4 memory and package configurations:

Table 2-1. Configuration Summary

Feature AT32UC3A3256/128/64 AT32UC3A4256/128/64

Flash 256/128/64 KB

SRAM 64 KB

HSB RAM 64 KB

EBI Full Nand flash only

GPIO 110 70

External Interrupts 8

TWI 2

USART 4

Peripheral DMA Channels 8

Generic DMA Channels 4

SPI 2

MCI slots 2 MMC/SD slots 1 MMC/SD slot

+ 1 SD slot

High Speed USB 1

AES (S option) 1

SSC 1

Audio Bitstream DAC 1

Timer/Counter Channels 6

Watchdog Timer 1

Real-Time Clock Timer 1

Power Manager 1

Oscillators

PLL 80-240 MHz (PLL0/PLL1)

Crystal Oscillators 0.4-20 MHz (OSC0/OSC1)

Crystal Oscillator 32 KHz (OSC32K)

RC Oscillator 115 kHz (RCSYS)

10-bit ADC

number of channels 1

JTAG 1

Max Frequency 84 MHz

Package LQFP144, TFBGA144 VFBGA100

32072H–AVR32–10/2012

AT32UC3A3

3. Package and Pinout

3.1 Package The device pins are multiplexed with peripheral functions as described in the Peripheral Multi-

plexing on I/O Line section.

Figure 3-1. TFBGA144 Pinout (top view)

12111098765

PX40 PB00 PA28 PA27 PB03 PA29 PC02 PC04 PC05 DPHS DMHS USB_VBUS

PA09GNDPLLDMFS

USB_VBIAS

VDDIOPC03PB04VDDIOPB02PA31PB11PX10

PX09 PX35 GNDIO

PX37 PX36

PB01 PX16

PX47 PX19

PB08PA30PX13

PA02PB10PX12

PA10PA08

GNDCORE

DPFS

PB06PB07PA11PA26

VDDIN PA12

VDDCORE

PA07PA25

PA06 PA16PA13PA05PA04

PX53 VDDIO PB09PX15

PX49 PX48 GNDIOGNDIO

PX08

VDDIO PX54PX38

PX07 PX06PX39

PX50 PX51 GNDIOGNDIOPX05 PX59PX00

PX57 VDDIO PA17PC01VDDIO PX58PX01

PX56 PX55 PA15PA14PX02 PX34PX04

PX46 PC00 PX52PX17PX44 GNDIOPX03

PX20 VDDIO PX43PX18GNDIO PX45PX11

PX14 PX21 PX24PX23PX41 PX42PX22

PA23 PA01PA00PA03PA24

VDDIO PB05

VDDANA

PA22PA21

PA19 RESET_N

TDOTMSPA20

PA18 TCKPX29GNDIOPX27

VDDIN TDI

GNDANA

PX28PX26

PX25 PX33PX30PX31PX32

32072H–AVR32–10/2012

AT32UC3A3

Figure 3-2. LQFP144 Pinout

USB_VBUS1

VDDIO2

USB_VBIAS3

GNDIO4

DMHS5

DPHS6

GNDIO7

DMFS8

DPFS9

VDDIO10

PB0811

PC0512

PC0413

PA3014

PA0215

PB1016

PB0917

PC0218

PC0319

GNDIO20

VDDIO21

PB0422

PA2923

PB0324

PB0225

PA2726

PB0127

PA2828

PA3129

PB0030

PB1131

PX1632

PX1333

PX1234

PX1935

PX4036

PX1037

PX3538

PX4739

PX1540

PX4841

PX5342

PX4943

PX3644

PX3745

PX5446

GNDIO47

VDDIO48

PX0949

PX0850

PX3851

PX3952

PX0653

PX0754

PX0055

PX5956

PX5857

PX0558

PX0159

PX0460

PX3461

PX0262

PX0363

VDDIO64

GNDIO65

PX4466

PX1167

PX1468

PX4269

PX4570

PX4171

PX2272

TDI108

TCK107

RESET_N106

TDO105

TMS104

VDDIO103

GNDIO102

PA15101

PA14100

PC0199

PC0098

PX3197

PX3096

PX3395

PX2994

PX3293

PX2592

PX2891

PX2690

PX2789

PX4388

PX5287

PX2486

PX2385

PX1884

PX1783

GNDIO82

VDDIO81

PX2180

PX5579

PX5678

PX5177

PX5776

PX5075

PX4674

PX2073

PA21 109

PA22 110

PA23 111

PA24 112

PA20 113

PA19 114

PA18 115

PA17 116

GNDANA 117

VDDANA 118

PA25 119

PA26 120

PB05 121

PA00 122

PA01 123

PA05 124

PA03 125

PA04 126

PA06 127

PA16 128

PA13 129

VDDIO 130

GNDIO 131

PA12 132

PA07 133

PB06 134

PB07 135

PA11 136

PA08 137

PA10 138

PA09 139

GNDCORE 140

VDDCORE 141

VDDIN 142

VDDIN 143

GNDPLL 144

32072H–AVR32–10/2012

AT32UC3A3

Figure 3-3. VFBGA100 Pinout (top view)

Note: 1. Those balls are physically connected to 2 GPIOs. Software must managed carrefully the GPIO

configuration to avoid electrical conflict

1098765

PA28 PA27 PB04 PA30 PC02 PC03 PC05 DPHS DMHS USB_VBUS

GNDPLL

DMFS

DPFSPC04VDDIOVDDIOPA29PB02PB01PB00

PB11 PA31 GNDIO

PX10 PX13

PB03 PB09

PX16/

PX53(1) PB10

GNDIO

USB_VBIAS

PB08

PA09PB06PB07

PA10

PA11

VDDINVDDIN

PA06/

PA13(1) VDDCORE

PA04

PA08 GNDCORE

PA03

PX09 VDDIO PA16GNDIO

PX07 GNDIO PA26/

PB05(1)

VDDIO

PX12

GNDIO PX08

PA02/

PX47(1)

VDDIO PX06

PX19/

PX59(1)

PX00 PX30 PA12/

PA25(1)

PA23/

PX46(1)

PX01 PX02PX05

PX25 PX31 TMS

PA22/

PX20(1)

PX21 GNDIOPX04

PX29 VDDIO PA15/

PX45(1)

VDDANA

PX24 PX26PX03

PX15/

PX32(1)

PC00/

PX14(1)

PA14/

PX11(1)

PC01PX27 PX28PX23

PA00/

PA18(1)

PA01/

PA17(1)

PA05

GNDANA PA07/

PA19(1)

PA20/

PX18(1)

TDO PA24/

PX17(1)

RESET_N

TDI PA21/

PX22(1)

TCK

32072H–AVR32–10/2012

AT32UC3A3

3.2 Peripheral Multiplexing on I/O lines

3.2.1 Multiplexed Signals

Each GPIO line can be assigned to one of the peripheral functions. The following table

describes the peripheral signals multiplexed to the GPIO lines.

Note that GPIO 44 is physically implemented in silicon but it must be kept unused and config-

ured in input mode.

Table 3-1. GPIO Controller Function Multiplexing

BGA

144 QFP

144 BGA

100 PIN

O Supply

Type

(2)

GPIO function

AB CD

G11 122 G8(1) PA00 0 VDDIO x3 USART0 - RTS TC0 - CLK1 SPI1 - NPCS[3]

G12 123 G10(1) PA01 1 VDDIO x1 USART0 - CTS TC0 - A1 USART2 - RTS

D8 15 E1(1) PA02 2 VDDIO x1 USART0 - CLK TC0 - B1 SPI0 - NPCS[0]

G10 125 F9 PA03 3 VDDIO x1 USART0 - RXD EIC - EXTINT[4] ABDAC - DATA[0]

F9 126 E9 PA04 4 VDDIO x1 USART0 - TXD EIC - EXTINT[5] ABDAC - DATAN[0]

F10 124 G9 PA05 5 VDDIO x1 USART1 - RXD TC1 - CLK0 USB - ID

F8 127 E8(1) PA06 6 VDDIO x1 USART1 - TXD TC1 - CLK1 USB - VBOF

E10 133 H10(1) PA07 7 VDDIO x1 SPI0 - NPCS[3] ABDAC - DATAN[0] USART1 - CLK

C11 137 F8 PA08 8 VDDIO x3 SPI0 - SPCK ABDAC - DATA[0] TC1 - B1

B12 139 D8 PA09 9 VDDIO x2 SPI0 - NPCS[0] EIC - EXTINT[6] TC1 - A1

C12 138 C10 PA10 10 VDDIO x2 SPI0 - MOSI USB - VBOF TC1 - B0

D10 136 C9 PA11 11 VDDIO x2 SPI0 - MISO USB - ID TC1 - A2

E12 132 G7(1) PA12 12 VDDIO x1 USART1 - CTS SPI0 - NPCS[2] TC1 - A0

F11 129 E8(1) PA13 13 VDDIO x1 USART1 - RTS SPI0 - NPCS[1] EIC - EXTINT[7]

J6 100 K7(1) PA14 14 VDDIO x1 SPI0 - NPCS[1] TWIMS0 - TWALM TWIMS1 - TWCK

J7 101 J7(1) PA15 15 VDDIO x1 MCI - CMD[1] SPI1 - SPCK TWIMS1 - TWD

F12 128 E7 PA16 16 VDDIO x1 MCI - DATA[11] SPI1 - MOSI TC1 - CLK2

H7 116 G10(1) PA17 17 VDDANA x1 MCI - DATA[10] SPI1 - NPCS[1] ADC - AD[7]

K8 115 G8(1) PA18 18 VDDANA x1 MCI - DATA[9] SPI1 - NPCS[2] ADC - AD[6]

J8 114 H10(1) PA19 19 VDDANA x1 MCI - DATA[8] SPI1 - MISO ADC - AD[5]

J9 113 H9(1) PA20 20 VDDANA x1 EIC - NMI SSC - RX_FRAME_SYNC ADC - AD[4]

H9 109 K10(1) PA21 21 VDDANA x1 ADC - AD[0] EIC - EXTINT[0] USB - ID

H10 110 H6(1) PA22 22 VDDANA x1 ADC - AD[1] EIC - EXTINT[1] USB - VBOF

G8 111 G6(1) PA23 23 VDDANA x1 ADC - AD[2] EIC - EXTINT[2] ABDAC - DATA[1]

G9 112 J10(1) PA24 24 VDDANA x1 ADC - AD[3] EIC - EXTINT[3] ABDAC - DATAN[1]

E9 119 G7(1) PA25 25 VDDIO x1 TWIMS0 - TWD TWIMS1 - TWALM USART1 - DCD

D9 120 F7(1)) PA26 26 VDDIO x1 TWIMS0 - TWCK USART2 - CTS USART1 - DSR

A4 26 A2 PA27 27 VDDIO x2 MCI - CLK SSC - RX_DATA USART3 - RTS MSI - SCLK

A3 28 A1 PA28 28 VDDIO x1 MCI - CMD[0] SSC - RX_CLOCK USART3 - CTS MSI - BS

A6 23 B4 PA29 29 VDDIO x1 MCI - DATA[0] USART3 - TXD TC0 - CLK0 MSI - DATA[0]

32072H–AVR32–10/2012

AT32UC3A3

C7 14 A4 PA30 30 VDDIO x1 MCI - DATA[1] USART3 - CLK DMACA - DMAACK[0] MSI - DATA[1]

B3 29 C2 PA31 31 VDDIO x1 MCI - DATA[2] USART2 - RXD DMACA - DMARQ[0] MSI - DATA[2]

A2 30 B1 PB00 32 VDDIO x1 MCI - DATA[3] USART2 - TXD ADC - TRIGGER MSI - DATA[3]

C4 27 B2 PB01 33 VDDIO x1 MCI - DATA[4] ABDAC - DATA[1] EIC - SCAN[0] MSI - INS

B4 25 B3 PB02 34 VDDIO x1 MCI - DATA[5] ABDAC - DATAN[1] EIC - SCAN[1]

A5 24 C4 PB03 35 VDDIO x1 MCI - DATA[6] USART2 - CLK EIC - SCAN[2]

B6 22 A3 PB04 36 VDDIO x1 MCI - DATA[7] USART3 - RXD EIC - SCAN[3]

H12 121 F7(1) PB05 37 VDDIO x3 USB - ID TC0 - A0 EIC - SCAN[4]

D12 134 D7 PB06 38 VDDIO x1 USB - VBOF TC0 - B0 EIC - SCAN[5]

D11 135 D6 PB07 39 VDDIO x3 SPI1 - SPCK SSC - TX_CLOCK EIC - SCAN[6]

C8 11 C6 PB08 40 VDDIO x2 SPI1 - MISO SSC - TX_DATA EIC - SCAN[7]

E7 17 C5 PB09 41 VDDIO x2 SPI1 - NPCS[0] SSC - RX_DATA EBI - NCS[4]

D7 16 D5 PB10 42 VDDIO x2 SPI1 - MOSI SSC - RX_FRAME_SYNC EBI - NCS[5]

B2 31 C1 PB11 43 VDDIO x1 USART1 - RXD SSC - TX_FRAME_SYNC PM - GCLK[1]

K5 98 K5(1) PC00 45 VDDIO x1

H6 99 K6 PC01 46 VDDIO x1

A7 18 A5 PC02 47 VDDIO x1

B7 19 A6 PC03 48 VDDIO x1

A8 13 B7 PC04 49 VDDIO x1

A9 12 A7 PC05 50 VDDIO x1

G1 55 G4 PX00 51 VDDIO x2 EBI - DATA[10] USART0 - RXD USART1 - RI

H1 59 G2 PX01 52 VDDIO x2 EBI - DATA[9] USART0 - TXD USART1 - DTR

J2 62 G3 PX02 53 VDDIO x2 EBI - DATA[8] USART0 - CTS PM - GCLK[0]

K1 63 J1 PX03 54 VDDIO x2 EBI - DATA[7] USART0 - RTS

J1 60 H1 PX04 55 VDDIO x2 EBI - DATA[6] USART1 - RXD

G2 58 G1 PX05 56 VDDIO x2 EBI - DATA[5] USART1 - TXD

F3 53 F3 PX06 57 VDDIO x2 EBI - DATA[4] USART1 - CTS

F2 54 F4 PX07 58 VDDIO x2 EBI - DATA[3] USART1 - RTS

D1 50 E3 PX08 59 VDDIO x2 EBI - DATA[2] USART3 - RXD

C1 49 E4 PX09 60 VDDIO x2 EBI - DATA[1] USART3 - TXD

B1 37 D2 PX10 61 VDDIO x2 EBI - DATA[0] USART2 - RXD

L1 67 K7(1) PX11 62 VDDIO x2 EBI - NWE1 USART2 - TXD

D6 34 D1 PX12 63 VDDIO x2 EBI - NWE0 USART2 - CTS MCI - CLK

C6 33 D3 PX13 64 VDDIO x2 EBI - NRD USART2 - RTS MCI - CLK

M4 68 K5(1) PX14 65 VDDIO x2 EBI - NCS[1] TC0 - A0

E6 40 K4(1) PX15 66 VDDIO x2 EBI - ADDR[19] USART3 - RTS TC0 - B0

C5 32 D4(1) PX16 67 VDDIO x2 EBI - ADDR[18] USART3 - CTS TC0 - A1

K6 83 J10(1) PX17 68 VDDIO x2 EBI - ADDR[17] DMACA - DMARQ[1] TC0 - B1

Table 3-1. GPIO Controller Function Multiplexing

BGA

144 QFP

144 BGA

100 PIN

O Supply

Type

(2)

GPIO function

AB CD

This manual suits for next models

Table of contents

Other Atmel Microcontroller manuals

Atmel

Atmel ATSAMB11 BluSDK SMART User manual

Atmel

Atmel AT91FR40162S User manual

Atmel

Atmel AT91SAM9 Installation and operating instructions

Atmel

Atmel AVR32918 User manual

Atmel

Atmel AVR461 User manual

Atmel

Atmel 80C51 Installation and operating instructions

Atmel

Atmel AVR ATtiny22 Instruction Manual

Atmel

Atmel develer DevelBoard Blue Quick user guide

Atmel

Atmel SAM4L Xplained Pro User manual

Atmel

Atmel SMARTCARD XPRO User manual

Atmel

Atmel AVR XMEGA E Installation and operating instructions

Atmel

Atmel ATmega324PB User manual

Atmel

Atmel AVR STK100 User manual

Atmel

Atmel ATmega645 Installation and operating instructions

Atmel

Atmel AVR262 Installation and operating instructions

Atmel

Atmel AVR042 Installation and operating instructions

Atmel

Atmel AVR1925 XMEGA-C3 Xplained User manual

Atmel

Atmel AVR1909 Installation manual

Atmel

Atmel AT01607 Installation and operating instructions

Atmel

Atmel ATmega48PV User manual

Atmel

Atmel MC320 User manual

Atmel

Atmel AT89C51 User guide

Atmel

Atmel AT88RF1354 User manual

Atmel

Atmel AVR XMEGA D Series User manual

Popular Microcontroller manuals by other brands

AMS

AMS AS7261 Demo Kit user guide

Novatek

Novatek NT6861 manual

Espressif Systems

Espressif Systems ESP8266 SDK AT Instruction Set

Nuvoton

Nuvoton ISD61S00 ChipCorder Design guide

STMicrolectronics

STMicrolectronics ST7 Assembler Linker user manual

Texas Instruments

Texas Instruments Chipcon CC2420DK user manual

Lantronix

Lantronix Intrinsyc Open-Q 865XR SOM user guide

NEC

NEC 78GK0S/K 1+ Series Application note

Mikroe

Mikroe SEMITECH N-PLC Click Application note

Intel

Intel Agilex user guide

Cypress

Cypress CY4607 HX2VL quick start guide

DIGITAL-LOGIC

DIGITAL-LOGIC MICROSPACE manual

Texas Instruments

Texas Instruments TMS320F2837 D Series Workshop Guide and Lab Manual

CYPRES

CYPRES CY14NVSRAMKIT-001 user guide

Texas Instruments

Texas Instruments INA-DUAL-2AMP-EVM user guide

Espressif Systems

Espressif Systems ESP8266EX Programming guide

Abov

Abov AC33M8128L user manual

Laird

Laird BL654PA user guide
