Ascentac OPM110 User manual
Copyright
© Copyright 2020 Ascentac Inc (hereinafter Ascentac). All rights reserved.
No part of this publication may be reproduced, stored in a retrieval system or
transmitted in any form or by any means, electronic, mechanical, photocopying,
recording or otherwise, without prior permission of Ascentac.
Disclaimer
Ascentac shall not be liable for errors contained herein or for incidental or
consequential damages in connection with the furnishing, performance, or use of
this user guide.
The material in this document is subject to change without notice. For the latest
information regarding this product, please visit our website at
http://www.ascentac.com.
All other trademarks and registered trademarks which appear herein are for
reference purposes only and are the property of their respective owners.
Warranty
Ascentac warrants the product against defects in material and workmanship within
(1) year from the date of delivery. Under normal use and service, the product will be
free from physical defects in material and workmanship during the warranty period,
or the product will be repaired or replaced as determined solely by Ascentac.
Please contact Ascentac to request a Return Material Authorization (RMA) number.
For warranty service or repair, the product must be returned to a service center
designated by Ascentac. You shall prepay the charges, including shipping,
insurance, duties, taxes, import fees or others which may be caused.
This warranty provides you with specific legal rights. You may have additional rights
which may vary from state to state and country to country. Because of individual
state and country regulations, some of the above limitations and exclusions may not
apply to you.
If any of the following conditions takes place, the warranty shall be null and void.
Defects or malfunction caused by human factors, accident, improper use not
conforming to product manual instructions, abuse or unauthorized alteration,
modification or repair of the product.
The label with S/N has been altered or damaged.
Notice: Ascentac makes no warranty of any kind with regard to the content in this
document, including, but not limited to, the implied warranties of merchantability
and fitness for a particular purpose.
Service & Support
If you have any questions or need any assistance, please contact our service
center.
Kaohsiung Office
TEL: +886-7-398-1000
FAX: +886-7-398-3965
Address: 11F.-1, No.80, Minzu 1st Rd., Sanmin Dist., Kaohsiung City 80761, Taiwan
(R.O.C.)
Please prepare below information before you contact us and describe the
problems.
Product model and S/N
Warranty information
i
Content
1. Safety Information .....................................................................................................................1
2. Introduction ................................................................................................................................2
2.1 Features ................................................................................................................................................3
2.2 Application...........................................................................................................................................3
3. Layout .........................................................................................................................................4
3.1 Appearance ........................................................................................................................................4
3.2 Instruction .............................................................................................................................................5
4. Display.........................................................................................................................................6
5. Operation ...................................................................................................................................7
5.1 Power-on...............................................................................................................................................7
5.2 Power-off (Default: 10 mins)..............................................................................................................7
5.3 Switching Wavelength .......................................................................................................................8
5.4 Setting Measurement Units (Default: dBm) ....................................................................................8
5.5 Turning on VFL (Default: Off) .............................................................................................................9
5.6 Setting VFL Modulation Output (Default: CW) ..............................................................................9
5.7 Setting Reference Value (Default: OFF) .......................................................................................10
5.8 Saving Measurement Result............................................................................................................11
6. Specification ............................................................................................................................12
6.1 Optical Power Meter (OPM) ...........................................................................................................12
6.2 Visual Fault Locator (VFL) ................................................................................................................12
6.3 Other....................................................................................................................................................13
1|OPM110
1. Safety Information
Read all safety information carefully before using this product to ensure personal
safety and proper use.
Assure the power supply conforming to the specification of this product and
qualified for the country of use.
Use batteries that meet the specifications of this product.
Do not use damaged power cords, accessories or other peripheral
equipment.
Make sure the product is operated on the permitted ambient conditions.
Never directly look into the optical outputs interface.
Dangerous laser radiation:
2|OPM110
2. Introduction
Ascentac OPM110 Series, Optical Power Meter, is widely with 7 wavelength
selections, including 85onm, 1300nm, 1310nm, 1490nm, 1550nm, 1625nm & 1650nm.
The dynamic range from +26 to -50 dBm or +6 to -70 dBm provides high accuracy for
optical power measurement in fiber-optic networks. It can be used for absolute and
relative optical power measurement.
Ascentac OPM110 Series has built-in visual fault locator (VFL) and features excellent
mobility owing to its mini-size and light weight. It can be powered by dry batteries. Its
low power consumption and auto shutdown function allow extended operation in
the field.
The high resolution OLED display makes measured values read easily. The interface
with clearly labeled and intuitive key pad is easy for use. What‘s even better is that
Ascentac OPM110 Series is fairly budget-friendly.
3|OPM110
2.1 Features
7 calibration wavelengths
Maximum Dynamic Range of 76 dB
Wavelength memory function
Auto shutdown for extending the battery life
Display Units: dB, dBm, mW
2.2 Application
Optical power or loss measurement in telecom or CATV installation and
maintenance
4|OPM110
3. Layout
3.1 Appearance
Front
Back
5|OPM110
3.2 Instruction
Button
Function
Description
Power on/off
Long press to turn on/off the meter.
Wavelength selection
Short press to switch wavelength.
1. Measurement unit
selection
2. Cancel REF setting
Short press to switch measurement unit
or cancel REF setting.
dBm dB mW
1. VFL on/off
2. VFL modulation
output
Long press to turn on VFL or switch its
modulation output.
(CW 1 Hz 2Hz Off CW)
REF setting
Short press to set reference value.
Data saving
Long press to save measurement results.
Item
Function
Description
1
VFL optical connector
Universal 2.5mm
2
OPM optical connector
Universal 2.5mm
3
Battery
Dry batteries: AAA-size x 3
4
USB Type C interface
Power supply
