Apure RP-3000 User manual
RP-3000
Microcomputer
PH
Oxidation-reduction potential
Transmitter
Apure RP-3000
AM 12:00
2017.01.01
1000
mV Relay1
16.00mA
7.00
pH Relay2
12.00mA
MTC
25.0 ℃
Industrial pH/ORP controller
Apure RP-3000
AM 12:00
2017.01.01
1000
mV Relay1
16.00mA
7.00
pH Relay2
12.00mA
MTC
25.0 ℃
Industrial pH/ORP controller
ESCESCESC
Apure RP-3000
AM 12:00
2017.01.01
1000
mV Relay1
16.00mA
7.00
pH Relay2
12.00mA
MTC
25.0 ℃
Industrial pH/ORP controller
ESC DownDown UpUp RightRight EnterEnterEnterEnter
Apure RP-3000
AM 12:00
2017.01.01
1000
mV Relay1
16.00mA
7.00
pH Relay2
12.00mA
MTC
25.0 ℃
Industrial pH/ORP controller
ESC Down Up Right Enter
Initial password：0000
Note: Please kindly read this operation manual
Thank you for purchasing our products, to continuously improve quality and enhance
the function of the analyzer, the company reserves the right to modify the content
and display of icons at any time, the actual display and operation manual may have
differences, so the actual situation of the machine as the subject. In the use of this
analyzer, please follow the functions described in the operating manual and the
installation method, the company is not responsible for any loss or damage caused
by improper use of any person or entity. If you have any questions or find that the
operating manual is missing or wrong, please contact the company's business
personnel.
Safety and precautions
1. Please read this manual before installing, avoid the wrong records cause security
problems and equipment damage.
2. Please avoid high temperature, high humidity, corrosive environment to install the
transmitter, and avoid direct sunlight.
3. Electrode signal transmission line must use a special coaxial wire, the proposed
use of the company provided by the coaxial line, can’t use the general wire instead.
4. The use of power, should avoid power interference, especially in the use of
three-phase power, we should use ground (if there is a power surge interference
phenomenon occurs, the power supply and control device of the transmitter such as:
dosing machine, mixer and other separate power transmitter with a separate power
source, or coil of the electromagnetic switch and all the power control device
connected with the surge absorber to eliminate the surge).
5. The transmitter output contact bearing alarm and control function. Based on
safety and protection reasons, please be sure to carry out external resistance enough
current value relay to carry, in order to protect the safety of the use of the
instrument.
Catalog
一． Summary
二． Combination and installation
2.1 Host fixed
2.2 Cabinet installation reference drawing
2.3 Wall mounted installation reference drawing
2.4 Electrode and protection tube
三． Electrode and electrical wiring
3.1 Wiring diagram
3.2 Back contact function
3.3 Terminal wiring instructions
四． Panel introduction
4.1 Panel introduction
4.2 Button description
4.3 Display screen description
五． Operation
5.1 Measuring
5.2 Parameter setting mode
六． Setting
6.1 Enter parameter setting mode
6.2 Language setting mode
6.3 Password setting mode
6.4 Electrode type setting mode
6.5 Calibration setting mode
6.6 Temperature setting mode
6.7 Relay setting mode
6.8 Current output setting mode
6.9 Real time clock setting mode
6.10 Backlight setting mode
6.11 Communication setting mode
6.12 Restore factory settings
七． Default factory settings
八． Maintain
Schedule 1
一． Summary
It is new model, intelligent and flexible, which can simultaneously measure
the temperature and PH/ORP, widely used in the city sewage treatment plant,
water supply, electricity, medicine, chemical, food and other industries, the
value of continuous measurement of solution PH/ORP.
Basic function
1. English interface, can be free to switch to Chinese, easy to operate
2. Automatic and manual temperature compensation, to meet the needs of
users
3. Two way 4-20MA output, corresponding to the PH/ORP value and
temperature, adopt isolation technology, strong anti-interference ability
4. Two relays can be switched freely at high and low points, and the amount
of hysteresis can be adjusted freely
5. Adopt 220V alternating current and 24V DC double power input
6. 480*800 IPS LCD, display clear, 5-100% brightness free settings
7. Protection level IP65, suitable for outdoor use
8. Password management function to prevent non professional staff misoperation
Instrument technical parameters
Measurement: PH (0-14PH); ORP ( -2000 - +2000 MV)
Accuracy: ±0.01 pH; ±1 mV
Resolution: 0.01pH; 1mV
Stability: ≤ 0.02 pH/24hours; ≤ 3 mV/24hours
PH buffer solution: 4.00-6.86, 6.86-9.18, 4.00-7.00, 7.00-10.00 four groups
Temperature compensation: 0–100 ℃ Manual/Auto(PT1000)
Signal output: 4-20mA isolation protection output, independent of the
corresponding PH/ORP or temperature maximum load of 500Ω
Alarm output: Two groups can be arbitrarily corresponding to the alarm
(3A/250 VAC), normally open contact relay
Power: AC 220V and DC 24V
Power consumption: ≤5W
Environment condition: (1) Temp: 0-60 ℃ (2) Humidity: ≤85%RH
Dimension: 144×144×115mm（H×W×D）
Opening size: 138×138mm（H×W）
Protection level: IP65
Specifications
Model RP-3000
Test item PH/ORP/TEMP
Test range
PH 0.00～14.00PH
ORP -2000～2000mv
TEMP -30.0～130.0℃
Resolution
PH 0.01 PH
ORP 1 mV
TEMP 0.1 ℃
Accuracy
PH ±0.01 PH（±1 Digit）
ORP ±0.1％（±1 Digit）
TEMP ±0.2 ℃（±1 Digit）
Temperature
compensation
NTC30K/PT1000 Automatic temperature compensation
Manual temperature compensation
Correction mode Custom single and double point correction and preset Tech, NIST
standard liquid, two-point or three automatic correction
Working
environment
temperature
0～50 ℃
Storage
temperature -20～70 ℃
Input impedance ＞ Ω
Display screen Backlit large LCD display, equipped with light sensors for automatic
and manual backlight selection
Current output
one
Isolated type 0/4-20mA, can set corresponding PH/ORP measuring
range, maximum load 500Ω
Current output
two
Isolated type 0/4-20mA, can set corresponding TP measuring
range, maximum load 500Ω
Control
Contact
output RELAY ON/OFF contact, 240VAC 0.5A Max
Setting HI/LO Two independent control points
Cleaning settings Contact output, ON 0～9999 seconds/OFF 0～999.9 hours
Voltage output DC±12 V
Protection level IP65
Power supply 100 V～240 VAC±10％, 50/60 Hz
Installation
method Wall mounted/Pipeline type/Panel
Dimension 144 mm×144 mm×115 mm (H×W×D)
Cut off
dimension 138 mm×138 mm (H×W)
Weight 0.8 Kg
二． Combination and installation
2.1 Host fixed
The transmitter can be wall mounted or panel installation
2.2 Cabinet installation reference drawing
Note: The surface of the installation, please first set aside 138mm*138mm square
hole in the distribution box panel, the transmitter from the distribution box
panel directly into, the transmitter attached to the fixed by the rear cover,
card into the fixed slot.
2.3 Wall mounted installation reference drawing
2.4 Electrode and protection tube
2.4.1 Electrode cable line and wiring method
1. The central axis of outer layer transparent conductive rubber layer and
the metal net layer, the line must be stripped of the conductive rubber
layer, and a metal mesh layer rolled wire.
2. The cable extends to the host, in addition to the intermediate junction
box outside the special can’t have any contact, directly to the central axis
of the cable to the GLASS node connected to the back of the host, as Ref
contact wire.
Pass cables and electrodes through the protective tube and into the
junction box. (main purpose: to prevent electrode line from contacting
liquid)
Glass body sensor method:
The sensor (glass) sheathed rubber holder, a glass electrode is about 5cm,
then PVC and sleeve screwed on the protection tube.
Plastic body sensor method:
Black (plastic) need to add a small amount of electrode rib tape, can be
directly screwed on the protection tube. The electrode cable terminal in the
terminal box, the cable and instrument line connecting terminal and is
connected to the above.
Note:
① Wiring must be stripped of the conductive black wire on the center line.
② The sensor cable is forbidden to contact with the liquid, otherwise the
sensor can be damaged (no maintenance), the signal can be short circuit,
and the instrument display fixed value has no change.
The electrode extension cable line method：
Configuration of coaxial cable：
Center line: + electrode wire line: - electrode reference line
The correct configuration diagram like up, the outer peel of the black rubber
mandrel guide be stripped off. Conductive rubber or aluminum foil electrode
signal line of the central axis and the cable must be stripped off. The cable
extends to the middle of the host, can’t have any contact, directly to the
central axis of the cable to the GLASS contact is connected to the back of the
host, the cable connected to the Ref contact.
Note: if the standard cable can’t meet the requirements, shall not extend
the cable, please contact the supplier to provide a dedicated cable,
otherwise the instrument produces adverse consequences to bear.
Recommended site not more than 30 meters to extend the cable, or need to
increase the signal amplifier.
