Ameriwood HOME 7926080 User manual

7926080

StorageCabinet

B34792608000

THISINSTRUCTIONBOOKLETCONTAINS

IMPORTANT

SAFETYINFORMATION.PLEASEREADANDKEEPFORFUTUREREFERENCE.

FollowAmeriwoodHome

Tube

You

DateofPurchase___/___/___

LotNumber:

DoNotReturnThisProduct!

Contactourcustomerserviceteamforhelpfirst.

Call:1‐800‐489‐3351(tollfree)

Monday‐Friday9am‐5pmCST

Visit:www.ameriwoodhome.com

AssemblyDifficultyMeter

Easy Tough

SecureYourFurniture

Keepyourhomeandfamilysafe

withthewallanchorkitthatis

includedwiththeproduct.



Seriousorfatalcrushinginjuriescan

occurfromtippingfurniture.

WARNING:Manufacturerassumesnoliability

forimproperinstallationorexcessiveloads

placedonscrewsorbracket.Thiswallanchor

isnotasubstituteforproperadultsupervision.

ContactUs!

HelpfulHints

2

ameriwoodhome.com

DoNOTreturnthisproduct!

Contactourfriendlycustomerserviceteamfirstforhelp.

Callus!

1‐800‐489‐3351

Monday‐Friday

9am‐5pmCST

Visitameriwoodhome.comtoviewthe

limitedwarrantyvalidintheU.S.andCanada.

AssemblyTips

‐Openyouritemintheareayouplantokeepittoavoidexcessiveheavylifting.



‐Identify,sortandcountthepartsbeforeattemptingassembly.



‐Compressiondowelsarelightlytappedinwithahammer.



‐Slidesarelabeledwitha

(right)and

L

(left)forproperplacement.



‐MakesuretoalwaysfacethepointonthetopoftheCamLocktowardsthe

outeredge.



‐Useallthenailsprovidedforthebackpanelandspreadthemoutequally.



‐Backpanelmustbeusedtomakesureyourunitissturdy.



‐DoNOTuseharshchemicalsorabrasivecleanersonthisitem.



‐Neverpush,pull,ordragyourfurniture.

Tube

You

Tube

You

PEOPLENEEDEDFORASSEMBLY:1‐2

ESTIMATEDASSEMBLYTIME:1HOUR

3

ameriwoodhome.com

BeforeYouStart



Quick

Tip

Assembly



CamLockFasteningSystem

ThisCamLockFasteningSystemwillbeusedthroughouttheassemblyprocess.

Tube

You

Readthrougheachstepcarefullyandfollowtheproperorder



Separateandcountallyourpartsandhardware



Giveyourselfenoughroomfortheassemblyprocess



Havethefollowingtools:FlatHeadScrewdriver,#2PhillipsHead

ScrewdriverandHammer

Caution:Ifusingapowerdrillorpowerscrewdriverforscrewing,

pleasebeawaretoslowdownandstopwhenscrewistight.

Failuretodosomayresultinstrippingthescrew.



4

ameriwoodhome.com

BoardIdentification

Notactualsize

Tube

You

This part is paperboard

construction.

It is not made from wood,

but is required for the

assembly of your unit.

LeftPanel

37926080010

RightPanel

37926080020

Top

37926080030

Bottom

37926080040

FixedShelf

37926080050

AdjustableShelf

37926080060

kick

37926080070

Door

37926080080

Backpnel

K792608000

DEFG

5

ameriwoodhome.com

BoardIdentification

Notactualsize

Tube

You

This part is paperboard

construction.

It is not made from wood,

but is required for the

assembly of your unit.

6

ameriwoodhome.com

PartList

ActualSize

Tube

You

NotActualSize

(x12)

#A22620

camlock

(x12)

#A22610

cambolt

(x12)

#A21660

wood dowel

(x34)

#A12210

#8x1/2"screw

(x12)

#A11080

#6 x 7/16" screw

(x2)

#A17400

8‐32x7/8"screw

(x3)

#A53600

anglebracket

(x12)

#A80250

shelfsupport

(x40)

#A21110

nail

(x6)

#A60260

hinge

(x2)

#A50250

knob

(x1)

#A84050

safetybracketkit

12 3 45

6789

11 12a

12b

12c

12d

(x4)

#A30030

plasticcatchkit

13a

13b

7

ameriwoodhome.com

STEP1

(x6)

#A22610

finishededge

Note:Pleaseuseholesshown.

8

ameriwoodhome.com

STEP2

finishededge

Note:Pleaseuseholesshown.

(x6)

#A22610

9

ameriwoodhome.com

STEP3

Proper orientation of CAM LOCK

Tip

Assembly

Quick

13413a

(x4)

#A22620

(x4)

#A21660

(x4)

#A12210

(x1)

#A84050

12b

12a

(x2)

#A30030

12a

12b

Donotfullytightenscrew(12b).

finishededge

13a

"rawsurface"

"finishedsurface"

10

ameriwoodhome.com

STEP4

13a

(x4)

#A22620

(x4)

#A21660

(x10)

#A12210

(x3)

#A53600

(x2)

#A30030

Proper orientation of CAM LOCK

Tip

Assembly

Quick

13a

endview

finishededge

"finishedsurface"

"rawsurface"
