Ameriwood HOME 7855340EBL User manual

7855340EBL

TVStand

B347855340EBL0

THISINSTRUCTIONBOOKLETCONTAINS

IMPORTANT

SAFETYINFORMATION.PLEASEREADANDKEEPFORFUTUREREFERENCE.

FollowAmeriwoodHome

Tube

You

DateofPurchase___/___/___

LotNumber:

AssemblyDifficultyMeter

Easy Tough

DoNotReturnThisProduct!

Contactourcustomerserviceteamforhelpfirst.

Call:1‐800‐489‐3351(tollfree)

Monday‐Friday9am‐5pmCST

Visit:www.ameriwoodhome.com

WARNING

‐Unitcantipovercausingsevereinjuryordeath.

‐Anchorunittostudinwall(ifinstructedto).

‐DoNotallowchildrentoclimbonunit.

‐Putheavyitemsonlowershelvesordrawers.

ContactUs!

HelpfulHints

2

ameriwoodhome.com

DoNOTreturnthisproduct!

Contactourfriendlycustomerserviceteamfirstforhelp.

Callus!

1‐800‐489‐3351

Monday‐Friday

9am‐5pmCST

Visitameriwoodhome.comtoviewthe

limitedwarrantyvalidintheU.S.andCanada.

AssemblyTips

‐Openyouritemintheareayouplantokeepittoavoidexcessiveheavylifting.



‐Identify,sortandcountthepartsbeforeattemptingassembly.



‐Compressiondowelsarelightlytappedinwithahammer.



‐Slidesarelabeledwitha

(right)and

L

(left)forproperplacement.



‐MakesuretoalwaysfacethepointonthetopoftheCamLocktowardsthe

outeredge.



‐Useallthenailsprovidedforthebackpanelandspreadthemoutequally.



‐Backpanelmustbeusedtomakesureyourunitissturdy.



‐DoNOTuseharshchemicalsorabrasivecleanersonthisitem.



‐Neverpush,pull,ordragyourfurniture.

Tube

You

Tube

You

PEOPLENEEDEDFORASSEMBLY:1‐2

ESTIMATEDASSEMBLYTIME:1HOUR

3

ameriwoodhome.com

BeforeYouStart



Quick

Tip

Assembly



CamLockFasteningSystem

ThisCamLockFasteningSystemwillbeusedthroughouttheassemblyprocess.

Tube

You

Readthrougheachstepcarefullyandfollowtheproperorder



Separateandcountallyourpartsandhardware



Giveyourselfenoughroomfortheassemblyprocess



Havethefollowingtools:FlatHeadScrewdriver,#2PhillipsHead

ScrewdriverandHammer

Caution:Ifusingapowerdrillorpowerscrewdriverforscrewing,

pleasebeawaretoslowdownandstopwhenscrewistight.

Failuretodosomayresultinstrippingthescrew.



4

ameriwoodhome.com

BoardIdentification

Notactualsize

37855340010

RightPanel

37855340020

Partition

37855340030

Top

37855340050

Bottom

37855340060

AdjustableShelves

37855340070

TVRail

37855340080

Back

37855340040

BottomSupport

37855340090

5

ameriwoodhome.com

BoardIdentification

Notactualsize

HorizontalRail

37855340100

VerticalMolding

37855340110

CenterMolding

37855340120

6

ameriwoodhome.com

PartList

ActualSize

NotActualSize

(x13)

#A22610

cam bolt

(x13)

#A22620

cam lock

(x6)

#A21660

wood dowel

(x4)

#A22910

connector bolt

(x4)

#A22920

connector

(x2)

#A23030

confirmat screw

(x24)

#A53510

angle bracket

(x4)

#A53520

molding bracket

(x72)

#A12120

7/16" pan head

(x8)

#A80250

shelf support

(x4)

#A54270

connecting plate

(x1)

#B64357

TV warning label

123

789

7

ameriwoodhome.com

STEP1

(x9)

#A22610

Adjust the connecting

plate (11) as far back

as possible keeping

the joint between the

top (E) and TV rail (H)

tight together.

(x16)

#A12120

(x4)

#A54270

8

ameriwoodhome.com

STEP2

(x6)

#A53510

(x12)

#A12120

Usinganglebrackets(7)andscrews(9),attachtwohorizontalrails(J)totheTVrail(H)asshown.

9

ameriwoodhome.com

STEP3

(x4)

#A22620

(x2)

#A21660 Proper orientation of CAM LOCK

Tip

Assembly

Quick

10

ameriwoodhome.com

STEP4

(x12)

#A12120

(x6)

#A53510

Usinganglebrackets(7)andscrews(9),attachtwohorizontalrails(J)tothebottom(F)asshown.
