Ameriwood HOME 5319340EBL User manual

5319341EBL(MagnoliaOak)

6DrawerDresser

5319340EBL(AndoverOak)

‐Unitcantipovercausingsevereinjuryordeath.

‐Anchorunittostudinwall(ifinstructedto).

‐DoNotallowchildrentoclimbonunit.

‐Putheavyitemsonlowershelvesordrawers.

B345319000EBL0

THISINSTRUCTIONBOOKLETCONTAINS

IMPORTANT

SAFETYINFORMATION.PLEASEREADANDKEEPFORFUTUREREFERENCE.

WARNING

FollowAmeriwoodHome

Tube

You

DateofPurchase___/___/___

LotNumber:

DoNotReturnThisProduct!

Contactourcustomerserviceteamforhelpfirst.

Call:1‐800‐489‐3351(tollfree)

Monday‐Friday9am‐5pmCST

Visit:www.ameriwoodhome.com

AssemblyDifficultyMeter

Easy Tough

ContactUs!

HelpfulHints

2

ameriwoodhome.com

DoNOTreturnthisproduct!

Contactourfriendlycustomerserviceteamfirstforhelp.

Callus!

1‐800‐489‐3351

Monday‐Friday

9am‐5pmCST

Visitameriwoodhome.comtoviewthe

limitedwarrantyvalidintheU.S.andCanada.

AssemblyTips

‐Openyouritemintheareayouplantokeepittoavoidexcessiveheavylifting.



‐Identify,sortandcountthepartsbeforeattemptingassembly.



‐Compressiondowelsarelightlytappedinwithahammer.



‐Slidesarelabeledwitha

(right)and

L

(left)forproperplacement.



‐MakesuretoalwaysfacethepointonthetopoftheCamLocktowardsthe

outeredge.



‐Useallthenailsprovidedforthebackpanelandspreadthemoutequally.



‐Backpanelmustbeusedtomakesureyourunitissturdy.



‐DoNOTuseharshchemicalsorabrasivecleanersonthisitem.



‐Neverpush,pull,ordragyourfurniture.

Tube

You

Tube

You

PEOPLENEEDEDFORASSEMBLY:1‐2

ESTIMATEDASSEMBLYTIME:1HOUR

3

ameriwoodhome.com

BeforeYouStart



Quick

Tip

Assembly



CamLockFasteningSystem

ThisCamLockFasteningSystemwillbeusedthroughouttheassemblyprocess.

Tube

You

Readthrougheachstepcarefullyandfollowtheproperorder



Separateandcountallyourpartsandhardware



Giveyourselfenoughroomfortheassemblyprocess



Havethefollowingtools:FlatHeadScrewdriver,#2PhillipsHead

ScrewdriverandHammer

Caution:Ifusingapowerdrillorpowerscrewdriverforscrewing,

pleasebeawaretoslowdownandstopwhenscrewistight.

Failuretodosomayresultinstrippingthescrew.



4

ameriwoodhome.com

BoardIdentification

5319340EBL(AndoverOak)PartsList

Tube

You

LeftPanel

35319340010

RightPanel

35319340020

Partition

35319340030

Top

35319340040

ABCD

Bottom

35319340050

LeftFrontMolding

35319340060

RightFrontMolding

35319340070

RearMolding

35319340080

DrawerFront

35319340090

DrawerBottom

35319331100

DrawerBrace

35319000110

x12

DrawerSide

39991167346200C

FGH

DWR

SIDE

5

ameriwoodhome.com

Tube

You

BoardIdentification

5319341EBL(MagnoliaOak)PartsList

ACD

LeftPanel

35319341010

RightPanel

35319341020

Partition

35319341030

Top

35319341040

Bottom

35319341050

LeftFrontMolding

35319341060

RightFrontMolding

35319341070

RearMolding

35319341080

x12

DrawerSide

39991167346200C

DrawerBrace

35319000110

DrawerBottom

35319331100

DrawerFront

35319341090

6

ameriwoodhome.com

BoardIdentification

Notactualsize

Tube

You

DrawerBack

39991167056150B

BackPanel

K531900000

Thispieceispaperboard

construction.Itisnotmade

fromwood,butisrequiredfor

theassemblyofyourunit.

Drawersides,anddrawerback

arelabeledwiththepart

description.

DWR

BACK

DWR

SIDE

DWR

BACK

DWR

SIDE

7

ameriwoodhome.com

PartList

ActualSize

Tube

You

NotActualSize

456

789

11 12

13a

13b

13c

13d

14a

14b

14c

14d

(x18)

#A22620

camlock

(x18)

#A22610

cambolt

(x4)

#A22900(white)

#A22920(black)

connector

(x4)

#A22910

connector bolt

(x3)

#A21660

wood dowel (x6)

#A23030

confirmatscrew

(x60)

#A11080

7/16"flathead

(x48)

#A12120

7/16"panhead

(x12)

#A12930

1‐1/8"panhead

(x36)

#A21970

drivefastener

(x12)

#A17030

5/16"bolt

(x32)

#A21110

nail

LeftCabinetMember

RightCabinetMember

LeftDrawerMember

RightDrawerMember

(x6)

#A56750(black)

#A56770(linen)

DrawerSlideKit

(x1)

#A84050

SafetyBracketKit

(x12)

#A54520

DrawerBracket

(x6)

#A50408

handle

(x4)

#A44410

(AndoverOak)

#A44420

(MagnoliaOak)

foot

(x1)

#A43105(black)

#A43106(white)

plasticfoot

(x2)

#A43490(black)

#A43495(white)

spacer

17 18

15 16

Note that your unit may contain extra hardware

8

ameriwoodhome.com

STEP1

Proper orientation of CAM LOCK

Tip

Assembly

Quick

(x2)

#A22620

(x2)

#A22900(white)

#A22920(black)

(x1)

#A21660

Youwillneedtotaptheconnector

(3)withahammertofullyinsert.

Besuretheconnectorispositioned

asshownbeforepushingintohole.

9

ameriwoodhome.com

STEP2

13a

Attachthreeleftcabinetmembers(13a)totheleftpanel(A)withscrews(7)asshown.

(x9)

#A11080 (x3)

#A56750(black)

#A56770(linen)

LeftCabinetMember

Marked with a "L".

13a

10

ameriwoodhome.com

STEP3

Attachtherearmolding(H)totheleftpanel(A)withtwoscrews(9)asshown.

Note:Youwillscrewintothegrooveoftherearmolding(H).

Besurethetopedgeoftheleftpanel(A)and

rearmolding(H)areflushwitheachother.

(x2)

#A12930
