Ameriwood HOME 5759354COM User manual
5759354COM
Nightstand
B345759354COM9
THISINSTRUCTIONBOOKLETCONTAINS
IMPORTANT
SAFETYINFORMATION.PLEASEREADANDKEEPFORFUTUREREFERENCE.
FollowAmeriwoodHome
Tube
You
DateofPurchase___/___/___
LotNumber:
AssemblyDifficultyMeter
Easy Tough
SecureYourFurniture
Keepyourhomeandfamilysafe
withthewallanchorkitthatis
includedwiththeproduct.
Seriousorfatalcrushinginjuriescan
occurfromtippingfurniture.
WARNING:Manufacturerassumesnoliability
forimproperinstallationorexcessiveloads
placedonscrewsorbracket.Thiswallanchor
isnotasubstituteforproperadultsupervision.
DoNotReturnThisProduct!
Contactourcustomerserviceteamforhelpfirst.
Call:1‐800‐489‐3351(tollfree)
Monday‐Friday9am‐5pmCST
Visit:www.ameriwoodhome.com
ContactUs!
HelpfulHints
2
ameriwoodhome.com
DoNOTreturnthisproduct!
Contactourfriendlycustomerserviceteamfirstforhelp.
Callus!
1‐800‐489‐3351
Monday‐Friday
9am‐5pmCST
Visitameriwoodhome.comtoviewthe
limitedwarrantyvalidintheU.S.andCanada.
AssemblyTips
‐Openyouritemintheareayouplantokeepittoavoidexcessiveheavylifting.
‐Identify,sortandcountthepartsbeforeattemptingassembly.
‐Compressiondowelsarelightlytappedinwithahammer.
‐Slidesarelabeledwitha
R
(right)and
L
(left)forproperplacement.
‐MakesuretoalwaysfacethepointonthetopoftheCamLocktowardsthe
outeredge.
‐Useallthenailsprovidedforthebackpanelandspreadthemoutequally.
‐Backpanelmustbeusedtomakesureyourunitissturdy.
‐DoNOTuseharshchemicalsorabrasivecleanersonthisitem.
‐Neverpush,pull,ordragyourfurniture.
Tube
You
Tube
You
PEOPLENEEDEDFORASSEMBLY:1‐2
ESTIMATEDASSEMBLYTIME:1HOUR
3
ameriwoodhome.com
BeforeYouStart
Quick
Tip
Assembly
CamLockFasteningSystem
ThisCamLockFasteningSystemwillbeusedthroughouttheassemblyprocess.
1
3
2
4
Tube
You
Readthrougheachstepcarefullyandfollowtheproperorder
Separateandcountallyourpartsandhardware
Giveyourselfenoughroomfortheassemblyprocess
Havethefollowingtools:FlatHeadScrewdriver,#2PhillipsHead
ScrewdriverandHammer
Caution:Ifusingapowerdrillorpowerscrewdriverforscrewing,
pleasebeawaretoslowdownandstopwhenscrewistight.
Failuretodosomayresultinstrippingthescrew.
4
ameriwoodhome.com
BoardIdentification
Notactualsize
Tube
You
LeftPanel
35759354010
RightPanel
35759354020
Top
35759354030
Bottom
35759354040
UpperRail
35759354050 LowerRail
35759354060 VerticalMolding(2)
35759354070
DrawerFront
35759354089
DrawerBottom
39991340037710D
DrawerBack
39991167036740B LeftDrawerSide
39991167346300L
BackPanel
K575935400
This piece is paperboard construction.
it is not made from wood, but is
required for the assembly of your unit.
DWR
BACK
DWR
BTM
RightDrawerSide
39991167346300R
LEFT
DWR
SIDE
RIGHT
DWR
SIDE
K
ABC
D
EF
G
H
5
ameriwoodhome.com
BoardIdentification
Notactualsize
Tube
You
A
B
C
D
E
F
G
G
H
K
Thispieceispaperboardconstruction.
itisnotmadefromwood,butis
requiredfortheassemblyofyourunit.
DWR
BACK
DWR
BTM
LEFT
DWR
SIDE
RIGHT
DWR
SIDE
6
ameriwoodhome.com
PartList
ActualSize
Tube
You
NotActualSize
(x4)
#A21660
wood dowel
(x4)
#A22920
connector
(x4)
#A22910
connector bolt
(x8)
#A22610
cam bolt
(x8)
#A22620
cam lock
(x18)
#A21110
nail
(x8)
#A15600
drawer screw
(x4)
#A21970
drive fastener
(x6)
#A12950
#8x1-1/8"
flat head
(x10)
#A11080
7/16" flat head
(x2)
#A17100
bolt
(x4)
#A53760
drawer bracket
(x1)
#A50485
pull
(x1)
#A84050
anti-tip kit
(x1)
#A56750
drawer slide kit
left cabinet
member
left drawer
member
right cabinet
member
right drawer
member
1
2
34
56
789
10 11
13
14
15a 15b
15d
15c
16a
16b 16d
16c
15 16
7
ameriwoodhome.com
STEP1
Tube
You
(x2)
#A22620
*rawedgesareshaded
(x2)
#A22610 (x3)
#A11080
(x3)
#A12950
(x1)
#A21660
(x1)
#A56750
A
endview
G
G
123
16a
810 16a
16a
10
10
10
22
1
1
3
8
8
8
Markedwith
a"L"
A
Proper orientation of CAM LOCK
Tip
Assembly
Quick
8
ameriwoodhome.com
STEP2
Tube
You
*rawedgesareshaded
(x2)
#A22620
(x2)
#A22610 (x1)
#A21660
(x3)
#A12950
(x3)
#A11080
(x1)
#A56750
B
G
G
B
endview
123810 16b
10
22
8
8
8
10
10
1
1
3
Markedwith
a"R"
Proper orientation of CAM LOCK
Tip
Assembly
Quick
9
ameriwoodhome.com
STEP3
Tube
You
(x4)
#A22620
(x2)
#A21660
(x2)
#A22920
D
Youwillneedtotaptheconnector
withahammertofullyinsert.Be
suretheconnectorispositionedas
shownbeforepushingintoholes.
1
34
1
1
1
1
3
3
4
4
*rawedgesareshaded
Proper orientation of CAM LOCK
Tip
Assembly
Quick
10
ameriwoodhome.com
STEP4
Tube
You
(x2)
#A22910
F
D
F
Turmscrewclockwise
tolockinplace.
5
5
*rawedgesareshaded
