Ameriwood HOME 1359903COM User manual

1359903COM

Hall Tree

- Unit can tip over causing severe injury or death.

- Anchor unit to stud in wall (if instructed to).

- Do Not allow children to climb on unit.

- Put heavy items on lower shelves or drawers.

B34 1359903 COM00SF

THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.

WARNING

Follow Ameriwood Home

Date of Purchase ___ / ___ / ___

Lot Number:

Do Not Return This Product!

Contact our customer service team for help first.

Call: 1-800-489-3351 (toll free)

Monday-Friday 9am - 5pm CST

Visit: www.ameriwoodhome.com

Assembly Difficulty Meter

Easy Tough

Follow Ameriwood Home

Helpful Hints

Do NOT return this product!

Contact our friendly customer service team first for help.

Call us!

1-800-489-3351

Monday-Friday

9am - 5pm CST

Visit ameriwoodhome.com

Assembly Tips

- Open your item in the area you plan to keep it to avoid excessive heavy lifting.

- Identify, sort and count the parts before attempting assembly.

- Compression dowels are lightly tapped in with a hammer.

- Slides are labeled with a R (right) and L (left) for proper placement.

- Make sure to always face the point on the top of the Cam Lock towards the

outer edge.

- Use all the nails provided for the back panel and spread them out equally.

- Back panel must be used to make sure your unit is sturdy.

- Do NOT use harsh chemicals or abrasive cleaners on this item.

- Never push, pull, or drag your furniture.

PEOPLE NEEDED FOR ASSEMBLY: 2

ESTIMATED ASSEMBLY TIME: 2 HOUR

ameriwoodhome.com

Before You Start

Quick

Tip

Assembly

Cam Lock Fastening System

This Cam Lock Fastening System will be used throughout the assembly process.

Read through each step carefully and follow the proper order

Separate and count all your parts and hardware

Give yourself enough room for the assembly process

Have the following tools: Flat Head Screwdriver, #2 Phillips Head

Screwdriver and Hammer

Caution: If using a power drill or power screwdriver for screwing,

please be aware to slow down and stop when screw is tight.

Failure to do so may result in stripping the screw.

ameriwoodhome.com

Board Identification

Not Actual Size

Hutch top

T1359903010SF

Hutch side panel

T1359903020SF

QTY: 2 PCS

Hutch left back panel

T1359903030SF

Hutch central back panel

T1359903040SF

ameriwoodhome.com

Board Identification

Not Actual Size

Hutch right back panel

T1359903050SF

Hutch upper support

T1359903060SF

Hutch top apron

T1359903070SF

Hutch lower support

T1359903080SF

Hutch tension support

T1359903090SF

QTY: 2 PCS

Hutch tension support

T1359903100SF

HIJ

ameriwoodhome.com

Board Identification

Not Actual Size

Base top

T1359903110SF

Base bottom

T1359903120SF

Base back panel

T1359903130SF

Base top apron

T1359903140SF

Base left side

T1359903150SF

ameriwoodhome.com

Board Identification

Not Actual Size

Base right side

T1359903160SF

Base partition

T1359903170SF

QTY: 3 PCS

Base left side rail

T1359903180SF

Base right side rail

T1359903190SF

Adjustable shelf

T1359903200SF

QTY: 2 PCS

Adjustable shelf

T1359903210SF

QTY: 2 PCS

Board Identification

Not Actual Size

ameriwoodhome.com

Actual Size

Part List

Hardware Bag Reference Number:

21359903COM0SF

x 52

Ø8X30mm

Wood dowel

TSF0501

Ø3.5X14mm

Screw

TSF1003

3x 19

x 8

Screw

TSF0613

4x 4

Ø4X20mm

Screw

TSF0608

Ø1/4X30mm

Bolt

TSF1403

5x 16 7 x 1

Screw

TSF1006

Ø4X38mm

Ø4X14mm

6 x 1

Screw

TSF1005

Ø3.5X14mm

ameriwoodhome.com

Part List

Not Actual Size

Hardware Bag Reference Number:

21359903COM0SF

x 1

Glue

TSF0015

x 16

Shelf support

TSF0008

Ø7X15mm(Nickel color)

Cam bolt

TSF0354

9x 56

Cam lock

TSF0307

10 x 56

x 4

Hook

TSF2630

Ø7 XØ16XT1.5mm

Washer

TSF2452

14 x 16

Ø7 X10XT1.5mm

Spring washer

TSF2451

15 x 16

Wall anchorl

TSF0025

16 x 1

Wall bracket

TSF2604

17 x 1

M4X54mm

11 x 1

Hex key

TSF2801
