Ameriwood HOME 3870335EBL User manual

3870335EBL

TVStand

B343870335EBL1

THISINSTRUCTIONBOOKLETCONTAINS

IMPORTANT

SAFETYINFORMATION.PLEASEREADANDKEEPFORFUTUREREFERENCE.

FollowAmeriwoodHome

Tube

You

DateofPurchase___/___/___

LotNumber:

DoNotReturnThisProduct!

Contactourcustomerserviceteamforhelpfirst.

Call:1‐800‐489‐3351(tollfree)



Visit:www.ameriwoodhome.com AssemblyDifficultyMeter

Easy Tough

WARNING

Thispieceoffurniturecanoverturnandcauseserious

injuries&ordeath.

Anchorthefurnituretoastudinthewall(ifthisisrequired).

Donotallowchildrentoclimbonfurniture

Keepheavieritemsonlowershelves.

ContactUs!

HelpfulHints

2

ameriwoodhome.com

DoNOTreturnthisproduct!

Contactourfriendlycustomerserviceteamfirstforhelp.

Callus!

1‐800‐489‐3351

Visitameriwoodhome.comtoviewthe

limitedwarrantyvalidintheU.S.andCanada.

AssemblyTips

‐Openyouritemintheareayouplantokeepittoavoidexcessiveheavylifting.



‐Identify,sortandcountthepartsbeforeattemptingassembly.



‐Compressiondowelsarelightlytappedinwithahammer.



‐Slidesarelabeledwitha

(right)and

L

(left)forproperplacement.



‐MakesuretoalwaysfacethepointonthetopoftheCamLocktowardsthe

outeredge.



‐Useallthenailsprovidedforthebackpanelandspreadthemoutequally.



‐Backpanelmustbeusedtomakesureyourunitissturdy.



‐DoNOTuseharshchemicalsorabrasivecleanersonthisitem.



‐Neverpush,pull,ordragyourfurniture.

Tube

You

PEOPLENEEDEDFORASSEMBLY:1‐2

3

ameriwoodhome.com

BeforeYouStart



Quick

Tip

Assembly



CamLockFasteningSystem

ThisCamLockFasteningSystemwillbeusedthroughouttheassemblyprocess.

Readthrougheachstepcarefullyandfollowtheproperorder



Separateandcountallyourpartsandhardware

Partsarelabeledonthesurfaceoredgeofthepart



Giveyourselfenoughroomfortheassemblyprocess



Havethefollowingtools:FlatHeadScrewdriver,#2PhillipsHead

ScrewdriverandHammer

Caution:Ifusingapowerdrillorpowerscrewdriverforscrewing,

pleasebeawaretoslowdownandstopwhenscrewistight.

Failuretodosomayresultinstrippingthescrew.



PresspartstogethersoCAMBOLTinserts

intoedgehole.

PressCAMBOLTintohole. PressCAMLOCKintohole.

Endhole

Usingascrewdriver,turntheCAMLOCKclockwiseto

locktheCAMLOCKandCAMBOLTintotheirholes

andfasteningpartstogether.

Arrowtopointtowardsend

holeinedgeofpart.

4

ameriwoodhome.com

BeforeYouStart

Quick

Assembly

Tip

PleaseNote:

Youmayneedtolightlytapthewooddowelsintotheholesduring

yourassemblyprocess.

5

ameriwoodhome.com

BoardIdentification

Notactualsize

LeftPanel

33870335010

RightPanel

33870335020

LeftPartition

33870335030

RightPartition

33870335040

Top

33870335050

Bottom

33870335060

Center

AdjustableShelf

33870335080

Side

AdjustableShelf(2)

33870335070

Thispieceispaperboard

construction.Itisnotmade

fromwood,butisrequired

fortheassemblyofyourunit.

BackPanel

K387033500

ABCD

BACK

PANEL

SolidBack

33870335090

6

ameriwoodhome.com

BoardIdentification

Notactualsize

Thispieceispaperboard

construction.Itisnotmade

fromwood,butisrequired

fortheassemblyofyourunit.

BACK

PANEL H

7

ameriwoodhome.com

PartList

ActualSize

NotActualSize

(x12)

#A22700

cam lock

(x12)

#A22710

cam bolt

(x10)

#A21660

wood dowel

(x4)

#A23030

confirmat screw

(x38)

#A21110

nail

(x12)

#A80250

shelfsupport

Notethatyourunitmaycontainextrahardware

(x1)

#A43490

spacer glide

#B64377

TVwarninglabel

(x2)

#A70310

grommet

8

ameriwoodhome.com

STEP1

(x2)

(x2) (x1)

Propercam

orientation

9

ameriwoodhome.com

STEP2

(x2)

(x2) (x1)

Propercam

orientation

10

ameriwoodhome.com

STEP3

(x2) (x1)

Propercam

orientation
