Altimeters VISO II+ User manual
VISO II+™
MANUAL
REV. 02, SEPTEMBER 2022
VISO II+ is a trademark of LB Altimeters, Denmark.
LB Altimeters operates a policy of continuous development.
Therefore, we reserve the right to make changes and improvements to any of the
products described in this guide without prior notice.
3
FAILURE TO FOLLOW ALL WARNINGS, INSTRUCTIONS, AND REQUIRED
PROCEDURES MAY RESULT IN SERIOUS INJURY AND DEATH.
Always ensure your altimeter is adjusted to zero prior to jumping to account for any
changes in barometric pressure.
Altimeters may give erroneous readings if you are tumbling or the altimeter is in a
burble (wake), such as when sit ying or sky surng. Chest mount altimeters are more
vulnerable to this problem. If you are in doubt about how this limitation aects your
skydiving, consult a licensed instructor.
DO NOT use this equipment unless you are in, or have passed an approved skydiving
course.
Use the VISO II+™ at your own risk.
WARNING
4
Introduction .....................6
Description......................9
Display ........................10
Main Window ...................14
Altimeter Mode ................14
Speedometer Mode.............16
Road Map ......................18
Customise the VISO II+™ Settings . 19
Altimeter/Speedometer Selector ...22
Feet/Meter Selector.............23
Mph/Kmh Selector..............24
Altitude Oset .................25
Dive Type Selector .............26
True Airspeed (TAS)/
Skydiver’s Airspeed (SAS) .......28
Set Current Year Selector ........31
Set Current Date Selector ........32
Set Current Time Selector .......33
Preset Jump Counter Selector ....34
Reset Jump Counter Selector .....35
Turn VISO II+™ OFF Selector ....36
Lock Window ..................37
Backlight Setup Area ............38
Backlight ON/OFF ..............38
Zeroing the VISO II+™............39
Jump Mode.....................40
Daily Jump Counter..............41
Jump Data. .....................42
Logbook Area ..................42
Jump Number .................43
Exit Altitude ...................44
Deployment Altitude ............45
CONTENTS
5
Freefall Time ..................46
Max. Speed in Freefall ..........47
Max. Speed under Canopy .......48
Prole Area ....................50
Playback Altitude Versus Time ....51
Playback Speed Versus Time .....52
Air Filter .......................54
Resetting the VISO II+™ ..........55
Battery Replacement.............56
Battery Status ..................57
Firmware Version. . . . . . . . . . . . . . . . 58
Trouble-shooting ................59
Appendix ......................60
TAS and SAS .................60
Specications ..................63
Mechanical ...................63
Logbook......................63
Prole Storage.................64
Factory default settings ..........64
Other ....................... .65
Warranty .......................66
6
Congratulations on purchasing your new VISO II+™!
The VISO II+™ design is based upon the latest ndings in microcomputer technology
and freefall parameters. Please read ALL of the instructions prior to actual skydiving
use. The VISO II+™ consists of three instruments:
1 Digital Altimeter
Stores detailed altitude information about the last jump for later review
2 Digital Speedometer
Stores detailed speed information about the last jump for later review
3 Digital Logbook
Electronic logbook, storing and displaying information about the last 200 jumps.
• Can be used as an aid to track the amount of jumps made.
• Can be reset at any time, but time and date for the last reset remains stored and
cannot be erased.
INTRODUCTION
7
4 Daily Jump Counter
• Displays number of jumps completed on last date and/or 9 other jump dates.
Features
• Digital altimeter or speedometer
• Electroluminescent backlight for night jumping. Can remain ON for several hours
• Automatic calibration to local elevation
• LCD screen for easy and intuitive operation and information review
• Logbook with playback of altitude/speed prole for the last jump
• Operational at sub-zero temperatures
• Switches OFF automatically after 14 hours
8
Software & functions
• Stores up to 10 minutes of data from the last jump
Displays altitude and speed details from exit to landing
• Records and displays jump information about the last 200 jumps including exit
altitude, deployment altitude, freefall time, max. speed in freefall and max. speed
under canopy
• Choice of readings in feet or meter and mph or kmh
9
1 UP button
3 DOWN button
4 LCD display
5 Reset button
(on rear side)
2 Middle button
DESCRIPTION
10
The display has the following characteristics by default (normal usage):
Date/Time Area
1 Date icon
2 Time icon
DISPLAY
1
Date/Time Area
Altitude/Speed Area
Status Area
24
5
6
7
810
11
12
9
3
