Installation Instructions

Micro800 Remote LCD

Catalog Number 2080-REMLCD

http://rockwellautomation.com/literature

Cette publication est disponible en français

sous forme électronique (fichier PDF). Pour la

télécharger, rendez-vous sur la page Internet

indiquée ci-dessus.

Esta publicação está disponível em portugués

como PDF. Vá ao endereço web que aparece

acima para encontrar e fazer download da

publicação.

IT Questa pubblicazione è disponibile in

Italiano in formato PDF. Per scaricarla

collegarsi al sito Web indicato sopra. ZH

Diese Publikation ist als PDF auf Deutsch

verfügbar. Gehen Sie auf die oben genannte

Web-Adresse, um nach der Publikation zu

suchen und sie herunterzuladen.

Esta publicación está disponible en español

como PDF. Diríjase a la dirección web

indicada arriba para buscar y descarga esta

publicación.

Table of Contents

Topic Page

Important User Information 2

North American Hazardous Location Approval 4

Additional Resources 6

Overview 7

Additional Resources 6

Install the Micro800 Remote LCD 9

Mount the Module 10

RS232 Port 16

USB Port 16

Connect Power 14

Specifications 18

2Micro800 Remote LCD

Rockwell Automation Publication 2080-IN010B-EN-P – May 2015

Important User Information

Solid state equipment has operational characteristics differing from those of electromechanical equipment. Safety Guidelines

for the Application, Installation and Maintenance of Solid State Controls (Publication SGI-1.1 available from your local Rockwell

Automation sales office or online at http://rockwellautomation.com/literature) describes some important differences between

solid state equipment and hard-wired electromechanical devices. Because of this difference, and also because of the wide

variety of uses for solid state equipment, all persons responsible for applying this equipment must satisfy themselves that each

intended application of this equipment is acceptable.

In no event will Rockwell Automation, Inc. be responsible or liable for indirect or consequential damages resulting from the use

or application of this equipment.

The examples and diagrams in this manual are included solely for illustrative purposes. Because of the many variables and

requirements associated with any particular installation, Rockwell Automation, Inc. cannot assume responsibility or liability for

actual use based on the examples and diagrams.

No patent liability is assumed by Rockwell Automation, Inc. with respect to use of information, circuits, equipment, or software

described in this manual.

Reproduction of the contents of this manual, in whole or in part, without written permission of Rockwell Automation, Inc., is

prohibited.

Throughout this manual, when necessary, we use notes to make you aware of safety considerations.

WARNING: Identifies information about practices or circumstances that can cause an explosion in a

hazardous environment, which may lead to personal injury or death, property damage, or economic loss.

ATTENTION: Identifies information about practices or circumstances that can lead to personal injury or

death, property damage, or economic loss. Attentions help you identify a hazard, avoid a hazard and

recognize the consequences.

SHOCK HAZARD: Labels may be on or inside the equipment (for example, drive or motor) to alert people

that dangerous voltage may be present.

BURN HAZARD: Labels may be on or inside the equipment (for example, drive or motor) to alert people

that surfaces may reach dangerous temperatures.

IMPORTANT

IMPORTANT: Identifies information that is critical for successful application and understanding of the

product.

Micro800 Remote LCD 3

Rockwell Automation Publication 2080-IN010B-EN-P – May 2015

Environment and Enclosure

Prevent Electrostatic Discharge

ATTENTION: This equipment is intended for use in a Pollution Degree 2

industrial environment, in overvoltage Category II applications (as defined in IEC

60664-1), at altitudes up to 2000 m (6562 ft) without derating.

This equipment is not intended for use in residential environments and may not

provide adequate protection to radio communication services in such

environments.

This equipment is supplied as open-type equipment. It must be mounted within

an enclosure that is suitably designed for those specific environmental

conditions that will be present and appropriately designed to prevent personal

injury resulting from accessibility to live parts. The enclosure must have suitable

flame-retardant properties to prevent or minimize the spread of flame,

complying with a flame spread rating of 5VA or be approved for the application if

nonmetallic. The interior of the enclosure must be accessible only by the use of

a tool. Subsequent sections of this publication may contain additional

information regarding specific enclosure type ratings that are required to comply

with certain product safety certifications.

In addition to this publication, see:

• Industrial Automation Wiring and Grounding Guidelines, Rockwell

Automation publication 1770-4.1, for additional installation requirements.

• NEMA Standard 250 and IEC 60529, as applicable, for explanations of the

degrees of protection provided by different types of enclosure.

ATTENTION: This equipment is sensitive to electrostatic discharge, which can

cause internal damage and affect normal operation. Follow these guidelines

when you handle this equipment:

• Touch a grounded object to discharge potential static.

• Wear an approved grounding wriststrap.

• Do not touch connectors or pins on component boards.

• Do not touch circuit components inside the equipment.

• Use a static-safe workstation, if available.

• Store the equipment in appropriate static-safe packaging when not in use.

4Micro800 Remote LCD

Rockwell Automation Publication 2080-IN010B-EN-P – May 2015

North American Hazardous Location Approval

The following modules are North American Hazardous Location approved: 2080-REMLCD.

The following information applies when

operating this equipment in hazardous

locations:

Informations sur l’utilisation de cet

équipement en environnements

dangereux:

Products marked "CL I, DIV 2, GP A, B, C, D" are

suitable for use in Class I Division 2 Groups A, B,

C, D, Hazardous Locations and nonhazardous

locations only. Each product is supplied with

markings on the rating nameplate indicating the

hazardous location temperature code. When

combining products within a system, the most

adverse temperature code (lowest "T" number)

may be used to help determine the overall

temperature code of the system. Combinations

of equipment in your system are subject to

investigation by the local Authority Having

Jurisdiction at the time of installation.

Les produits marqués "CL I, DIV 2, GP A, B, C,

D" ne conviennent qu'à une utilisation en

environnements de Classe I Division 2 Groupes

A, B, C, D dangereux et non dangereux.

Chaque produit est livré avec des marquages

sur sa plaque d'identification qui indiquent le

code de température pour les environnements

dangereux. Lorsque plusieurs produits sont

combinés dans un système, le code de

température le plus défavorable (code de

température le plus faible) peut être utilisé

pour déterminer le code de température global

du système. Les combinaisons d'équipements

dans le système sont sujettes à inspection par

les autorités locales qualifiées au moment de

l'installation.

WARNING: EXPLOSION

HAZARD

• Do not disconnect equipment

unless power has been removed or

the area is known to be

nonhazardous.

• Do not disconnect connections to

this equipment unless power has

been removed or the area is known

to be nonhazardous. Secure any

external connections that mate to

this equipment by using screws,

sliding latches, threaded

connectors, or other means

provided with this product.

• Substitution of any component may

impair suitability for Class I,

Division 2.

• If this product contains batteries,

they must only be changed in an

area known to be nonhazardous.

WARNING: RISQUE

D’EXPLOSION

• Couper le courant ou s'assurer

que l'environnement est classé

non dangereux avant de

débrancher l'équipement.

• Couper le courant ou s'assurer

que l'environnement est classé

non dangereux avant de

débrancher les connecteurs. Fixer

tous les connecteurs externes

reliés à cet équipement à l'aide

de vis, loquets coulissants,

connecteurs filetés ou autres

moyens fournis avec ce produit.

• La substitution de tout composant

peut rendre cet équipement

inadapté à une utilisation en

environnement de Classe I,

Division 2.

• S'assurer que l'environnement est

classé non dangereux avant de

changer les piles.

Micro800 Remote LCD 5

Rockwell Automation Publication 2080-IN010B-EN-P – May 2015

• Make sure all connectors are securely tightened to properly seal the

connections against leaks and maintain IP enclosure type requirements.

• The USB port is intended for temporary local programming purposes only and

not intended for permanent connection.

• The USB cable is not to exceed 3.0 m (9.84 ft) and must not contain hubs.

• The RS232 and Power cables are not to exceed 3.0 m (9.84 ft).

• Do not place the module in direct sunlight. Prolonged exposure to sunlight may

degrade the LCD.

• The USB cap must be in place to maintain IP65 rating.

• If you connect or disconnect the RS232 cable with power applied to this module

or the serial device on the other end of the cable, an electrical arc can occur.

This could cause an explosion in hazardous location installations.

Be sure that power is removed or the area is nonhazardous before proceeding.

• If you connect or disconnect the communications cable with power applied to

this module or any device on the network, an electrical arc can occur. This could

cause an explosion in hazardous location installations.

Be sure that power is removed or the area is nonhazardous before proceeding.

• When used in a Class I, Division 2, hazardous location, this equipment must be

mounted in a suitable enclosure with proper wiring method that complies with

the governing electrical codes.

• The USB port is intended for temporary local programming purposes only and

not intended for permanent connection. If you connect or disconnect the USB

cable with power applied to this module or any device on the USB network, an

electrical arc can occur. This could cause an explosion in hazardous location

installations.

Be sure that power is removed or the area is nonhazardous before proceeding.

• Do not connect directly to line voltage. Line voltage must be supplied by a

suitable, approved isolating transformer or power supply having short circuit

capacity not exceeding 100V A maximum or equivalent.

• Do not use the USB port in hazardous locations.

6Micro800 Remote LCD

Rockwell Automation Publication 2080-IN010B-EN-P – May 2015

Additional Resources

If you would like a manual, you can:

• download a free electronic version from the Internet:

http://rockwellautomation.com/literature

• purchase a printed manual by contacting your local Allen-Bradley distributor or

Rockwell Automation representative

Resource Description

Micro820 20-point Programmable

Controllers User Manual, publication

2080-UM005

A more detailed description of how to install and use your

Micro820 programmable controller.

Micro800 Plug-in Modules and Accessories

User Manual, publication 2080-UM004 Installation and wiring descriptions for the different Micro800

plug-in modules and accessories.

Micro820 Programmable Controllers

Installation Instructions, publication

2080-IN009

Information on how to install your Micro820

programmable controller.

Micro800 AC Power Supply Installation

Instructions, publication 2080-IN001 Information on wiring and installing the optional AC power supply.

Industrial Automation Wiring and

Grounding Guidelines, publication 1770-4.1 More information on proper wiring and grounding techniques.

Micro800 Remote LCD 7

Rockwell Automation Publication 2080-IN010B-EN-P – May 2015

Overview

The Micro800™ Remote LCD is a simple IP65 text display interface that allows configuration of

such settings as IP address on the Micro800 controller. It is an accessory to the Micro820

controller.

The remote LCD can be connected to the controller through an RS232 port. It can be mounted

through the front panel or on the same DIN rail as the controller.

Micro800 Remote LCD Overview

2080-REMLCD Description

Description Description

1 Logo casing(1)

(1) The module is shipped with the Allen-Bradley sticker label but you can customize the space with your

product logo. Dimensions for the logo casing and the sticker label are shown below.

6 DIN rail latch

2 Display screen 7 USB port

3 Function keys 8 RS232 port

4 Arrow keys 9 24V DC power port

5 ESC and OK keys

ESC

F4 F5

F1 F2 F3

34567

Front Back

Sticker label

36.70

4.70

Sticker casing

Measurements are in millimeters.

8Micro800 Remote LCD

Rockwell Automation Publication 2080-IN010B-EN-P – May 2015

Module Dimensions

ATTENTION: The length of RS232 and 24V DC power cable connection

to the 2080-REMLCD module must not exceed 3 m (9.84 ft.).

Catalog Number Height (a) Width (b) Depth (c)

2080-REMLCD 97 mm (3.82 in.) 130 (5.11 in.) 35.5 (1.40 in.)

ESC

F4 F5

F1 F2 F3

46258

RS232 and 24V DC power cable

connections must not exceed 3 m.

Micro820

controller Micro800

REMLCD

Power

supply

ESC

F4 F5

F1 F2 F3

Micro800 Remote LCD 9

Rockwell Automation Publication 2080-IN010B-EN-P – May 2015

Parts List

The Micro800 Remote LCD module ships with these items:

•Allen-Bradley sticker label

•Clamp accessories for panel mounting (4 pcs)

•Product Information (publication 2080-PC002)

Install the Micro800 Remote LCD

Before installing the Remote LCD through the front panel, review minimum clearances, panel

guidelines, panel cutout dimensions, and product dimensions.

Minimum Spacing

Maintain spacing from objects such as enclosure walls, wireways, and adjacent equipment. Allow

50.8 mm (2.0 in.) of space on all sides for adequate ventilation. If optional accessories/modules

are attached such as the optional power supply, 2080-PS120-240VAC, make sure that there is

50.8 mm (2.0 in.) of space on all sides after attaching the optional parts.

Plan for adequate space around the module, inside the enclosure, for ventilation and cabling.

Consider heat produced by other devices in the enclosure. The ambient temperature around the

module must be -20…50 °C (-4…122 °F).

Panel Guidelines

Supporting panels must be at least 16 gauge to provide proper sealing against water and dust and

to provide proper support. The panel surface must be flat and free of imperfections to maintain

an adequate seal and NEMA/IP Type ratings.

IMPORTANT

Most applications require installation in an industrial enclosure to

reduce the effects of electrical interference and environmental

exposure. Locate your device as far as possible from power lines, load

lines, and other sources of electrical noise such as hard-contact

switches, relays, and AC motor drives. For more information on proper

grounding guidelines, see the Industrial Automation Wiring and

Grounding Guidelines, publication 1770-4.1.

TIP

The minimum spacing requirements are sufficient for connecting cables and inserting.

Plan for additional clearance if using the USB host port on the back of the unit.

10 Micro800 Remote LCD

Rockwell Automation Publication 2080-IN010B-EN-P – May 2015

Panel Cutout Dimensions

You can print the panel cutout template that comes at the end of this installation instructions.

Panel cutout dimensions are provided in the next table.

Mount the Module

There are two ways to mount the Micro800 Remote LCD, as described in the following sections:

•Mount the Module in a Panel

•Mount the Module on a DIN Rail

Catalog Number Height, Approx., mm (inches) Width, Approx., mm (inches)

2080-REMLCD 88.5 ± 0.5 (3.48 ± 0.02) 121.5 ± 0.5 (4.78 ± 0.02)

ATTENTION: Disconnect all electrical power from the panel before

making the panel cutout.

•Make sure the area around the panel cutout is clear.

•Take precautions so metal cuttings do not enter any components

already installed in the panel.

•Failure to follow these instructions may result in personal injury or

damage to panel components.

WARNING: If you connect or disconnect the RS232 cable with power

applied to this module or the RS232 device on the other end of the

cable, an electrical arc can occur. This could cause an explosion in

hazardous location installations.

Be sure that power is removed or the area is nonhazardous before

proceeding.

WARNING: When used in a Class I, Division 2, hazardous location, this

equipment must be mounted in a suitable enclosure with proper wiring

method that complies with the governing electrical codes.

Other manuals for Micro800

Table of contents

Other Allen-Bradley Controllers manuals

Allen-Bradley

Allen-Bradley CompactLogix 5380 User manual

Allen-Bradley

Allen-Bradley 1336 PLUS II User manual

Allen-Bradley

Allen-Bradley PowerFlex 70 User manual

Allen-Bradley

Allen-Bradley 160 SSC User manual

Allen-Bradley

Allen-Bradley PowerFlex40 User manual

Allen-Bradley

Allen-Bradley MicroLogix 1400 User manual

Allen-Bradley

Allen-Bradley ControlNet PLC-5 User manual

Allen-Bradley

Allen-Bradley FlexPak 3000 User manual

Allen-Bradley

Allen-Bradley 1747-PBASE Owner's manual

Allen-Bradley

Allen-Bradley PowerFlex 400 Operator's manual

Allen-Bradley

Allen-Bradley powerflex 700 Instruction manual

Allen-Bradley

Allen-Bradley GuardLogix 5570 User manual

Allen-Bradley

Allen-Bradley Studio 5000 Logix Emulate Owner's manual

Allen-Bradley

Allen-Bradley Pico 1760-L12AWA User manual

Allen-Bradley

Allen-Bradley ControlLogix 5570 User manual

Allen-Bradley

Allen-Bradley PowerFlex AFE User manual

Allen-Bradley

Allen-Bradley PowerFlex 700H User manual

Allen-Bradley

Allen-Bradley PowerFlex 400 User manual

Allen-Bradley

Allen-Bradley 7760 User manual

Allen-Bradley

Allen-Bradley CompactLogix 5480 User manual

Allen-Bradley

Allen-Bradley PowerFlex 755T User manual

Allen-Bradley

Allen-Bradley Studio 5000 Logix Emulate Owner's manual

Allen-Bradley

Allen-Bradley PowerFlex 700L User manual

Allen-Bradley

Allen-Bradley PowerFlex 4 User manual

Popular Controllers manuals by other brands

Digiplex

Digiplex DGP-848 Programming guide

YASKAWA

YASKAWA SGM series user manual

Sinope

Sinope Calypso RM3500ZB installation guide

Isimet

Isimet DLA Series Style 2 Installation, Operations, Start-up and Maintenance Instructions

LSIS

LSIS sv-ip5a user manual

Rockwell Automation

Rockwell Automation 1769-L31 installation instructions

Airflow

Airflow Uno hab Installation and operating instructions

ABB

ABB ACS580-01 drives Hardware manual

Panasonic

Panasonic GM1 Series Reference manual

Emerson

Emerson SW93 owner's manual

AutoAqua

AutoAqua Smart ATO micro SATO-120P manual

Panasonic

Panasonic FP? Positioning Unit RTEX Technical manual

Samson

Samson Type 5824 Mounting and operating instructions

Alpha IP

Alpha IP MIOB 21001 manual

Siemens

Siemens OpenAir GMA 1 Series Mounting instructions

Surecom

Surecom SR-629 user manual

Fishman

Fishman TriplePlay installation guide

Regulus

Regulus SRS1 T Installation and operation manual
