Advantech TREK-120 Series User manual
User Manual
for
LEO-S Cold Chain Management
(TREK-120 & USM-S62)
V1.2
Contents
Contents..............................................................................................................................2
Chapter 1 General Information........................................................ 1
1.1 Introduction....................................................................................................2
1.2 General Specification.....................................................................................2
1.3 Installation flowchart ......................................................................................3
Chapter 2 System Setup.................................................................. 4
2.1 A Quick Tour of the LEO-S CCM Hardware Kit –TREK-120G2.....................5
2.1.1 Outlook..................................................................................................5
2.1.2 LED behavior.......................................................................................5
2.1.3 Mounting Methods...............................................................................5
2.1.4 Battery Replacement..........................................................................6
2.2 A Quick Tour of LEO-S CCM Hardware Kit –USM110-S62...........................7
2.2.1 Outlook..........................................................................................................7
2.2.2 LED behavior.................................................................................................8
2.2.3 Mounting Methods .........................................................................................8
Chapter 3 Software Demo Utility Setup.......................................... 9
3.1 USM-S62 EdgeX-Go installation..................................................................10
3.2 Web-GUI......................................................................................................14
3.2.1 Login....................................................................................................14
3.2.2 Overview..............................................................................................14
3.2.3 Firmware Check & Update Method.....................................................16
3.2.3.1 USM-S62 Firmware Version Check....................................................16
3.2.3.2 USM-S62 Firmware Update Method...................................................17
3.2.3.3 LoRa Module Firmware Version Check..............................................19
3.2.3.4 LoRa Module Firmware Update Method.............................................20
3.2.4 USM-S62 Change Network ID (Unavailable feature).........................23
3.2.5 Insert Node List....................................................................................24
3.2.6 TREK-120 Connection Confirm..........................................................27
3.2.7 Cellular Network Setting (LTE version)..............................................27
3.2.8 Wi-Fi Network Setting (WLAN version) ............................................27
3.3 LEO-S TREK-120G2 Configuration Tool (Need TREK-120-ANR)................28
3.3.1 Basic Settings.......................................................................................31
3.3.2 Sensor Data..........................................................................................33
3.3.3 Upload backup data to Dash board......................................................37
3.3.4 WISE-PaaS Setting..............................................................................38
3.4 WISE-PaaS Dashboard Demo.....................................................................38
1
Chapter 1 General Information
2
1.1 Introduction
Advantech Cold Chain Management offer a full function of Temperature and
Humidity control analysis in supply chain. This LEO-S CCM Kit can apply in
many environments such as hypermarket, food factory, museum, warehouse,
medical management, etc. For use with us in-vehicle gateway, our LEO-S can
achieve Uninterrupted Real-time Cold Chain Management.
This LEO-S CCM kit content USM-S62 as gateway install inside the building, and
TREK-120G2 as sensor in every container or any place need temperature
management.
1.2 General Specification
3
1.3 Installation flowchart
4
Chapter 2 System Setup
5
2.1 A Quick Tour of the LEO-S CCM Hardware Kit –TREK-120G2
2.1.1Outlook
Figure 1 Front View of TREK-120G2
Figure 2 Back View of TREK-120G2
2.1.2LED behavior
Power/Status LED
Alarm LED
Standby
Green
N/A
Recording
Green
Green
Low Battery
Red
N/A
Over Critical
Green
Red
2.1.3Mounting Methods
Figure 3 Three Different Mounting Methods of TREK-120G2
Sensor
Start/Status Button
Power/Status LED
Alarm LED
Battery Cover
NFC Antenna
Mounting
Powerful magnet
3MTM VHBTM Tape
Screws
6
2.1.4Battery Replacement
Step 1. Release 4 Screws on battery cover
Step 2. Open battery cover
Step 3. Take off the battery
Step 4. Install the new battery
Figure 4 Replace battery of TREK-120
Note: NFC function is only Rx
7
2.2 A Quick Tour of LEO-S CCM Hardware Kit –USM110-S62
2.2.1Outlook
Figure 5 USM-S62 LTE/Wi-Fi Antenna Side View
Figure 6 USM-S62 Lo-Ra Antenna Side View
Figure 7 USM-S62 Card Socket View
RJ-45 Network Socket
12.0V⎓2.0A Adapter socket
LTE/Wi-Fi Conductor
LTE/Wi-Fi Conductor
USB 2.0 Socket
Lo-Ra Conductor
Lo-Ra Conductor
Micro SD Card Socket
Micro SIM Socket
8
2.2.2LED behavior
Figure 8 LED Behavior of USM-S62
Left LED
Right LED
Power On
Green
Blue
Initializing
Green Orange Cross
N/A
Ready
Orange
N/A
2.2.3Mounting Methods
Figure 9 Mounting Method of USM-S62
Screws
Screws
