ZyXEL Communications NWD210N User manual

Lightning-fast Wireless Power!

Benefits

Ł

Complies with 802.11n Standard,Backwards Compatible

with 802.11b/g

Ł

Wi-Fi Multimedia (WMM) Support for Quality Video &

Voice Streaming over Wireless Connection

Ł

Advanced Wireless Security Transmission with

WPA/WPA2 and 802.1x Support

Ł

Support WPS (Wi-Fi Protected Setup) for Simple

Security Setup

Wireless N USB Adapter

NWD210N

WIRELE

Enjoy Online Content and Entertainment at Data Rates

of Up to 300 Mbps

The ZyXEL NWD210N USB Adapter brings you a better Internet experience

over existing 802.11g networks.With data rates of up to 300 Mbps,you can

enjoy a breathtaking high-speed connection at home or in the office. It is an

excellent solution for daily activities such as file transfers, music

downloading,video streaming and online gaming.

Greater Coverage

By taking advantage of multiple radio channels and according reflections,

the exciting new NWD210N USB Adapter creates robust signals reaching up

to 4 times farther that eliminate most dead zones. Not only does the

NWD210N USB Adapter provides you the speed and coverage advantages,

it also works with the existing 802.11b or 802.11g network.

Setup a Secure Wireless Network with

Ease and Confidence

Establishing a secure wireless network is no longer a headache.The WPS

(Wi-Fi Protected Setup) takes only a few seconds, letting you set up a secure

wireless network without any complicated procedure or lengthy call to a

help desk involved.You can either connect to your WPS-supported access

point by simply pushing a configuration button (PBC: Push Button

Configuration) or enter a 4- to 8-digit code, given by the NWD210N USB

Adapter or your access point, to create a simple but safe wireless network.

System Specifications

•

Complies with 802.11n draft specification,

war

s Compati

e wit

IEEE 802.11

•

Wi-Fi Multimedia (WMM) Support for Quality Video

Voice Streaming over Wire

ess Connection

•

vance

Wire

ess Security Transmission wit

WPA/WPA2 and 802.1x Suppor

•

ort WPS (Wi-Fi Protected Setu

) for sim

ecur

setup

Hardware Specifications

• Operation Voltage: DC 5 V

•

Two internal antennas

•

One Link/Act LED

•

One USB 2.0 male jack

Physical Specifications

• Dimensions: 30 (W) x 95 (D) x 16 (H) mm

• Weight: 35 g

Environmental Specifications

• Operating temperature: -5ºC ~ 55ºC

• Operating humidity: 20% ~ 95% (Non-condensing)

• Storage temperature: -30ºC ~ 60ºC

• Storage humidity: 20% ~ 95% (Non-condensing)

Certification

• FCC/CE/C-Tick/NCC/IC

Specifications

Wireless N USB Adapter

NWD210N

Enhanced Wireless Security and Privacy

ion

In additio

’

s wireless network adapter NWD210N features the latest

’

ed wireless security mechanisms such as IEEE 802.1x authentication and Wi-Fi Protected Access

anced

enhanc

/WPA2).The enhanced security functions protect wireless communication and only allow authorized

WPA/W

(WP

s to access your network.This protects your network from unexpected break-ins and information theft.

users

Application Diagram

NWD310N

Wireless N PCI Adapter

Repeater

Mode

Modem

DSL M

NBG417N

Wireless N Router

Internet

NWD210N

Wireless N USB Adapter

ANT1106

6 dBi Omni-Directional

Antenna

NWA570N

Wireless N AP

For more product information, visit us on the web at www.ZyXEL.com

65-100-021002B 01/08

product names, or trademarks mentioned are the property of their respective owners. All specifications are subject to change without notice.
