Xerox 4213 User manual

XEROX

Xerox 4213 Laser Printer

User Guide Update

720P86022

July 1992

Xerox Corporation

701 South Aviation Boulevard

El Segundo, CA 90245

copyrightable material and information now allowed by statutory

or judicial law or hereinafter granted, including without limitation,

material generated from the software programs which are

displayed on the screen, such as icons, screen displays, looks,

etc.

July 1992

720P86022

Printed in the United States of America

Xerox®, 4213 and all Xerox products mentioned in this

publication are trademarks of Xerox Corporation.

Centronics and all Centronics products mentioned in this

publication are trademarks of Centronics Data Computer

Corporation.

Data Products and all Data Products products mentioned in this

publication are trademarks of Hewlett-Packard Company.

IBM and all other IBM products mentioned in this publication are

trademarks of International Business Machines.

Hewlett-Packard and HP are registered trademarks of Hewlett-

Packard Company.

Microsoft is a U.S. registered trademark of Microsoft

Corporation.

PostScript® and all PostScript products mentioned in this

publication are trademarks of Adobe systems.

PostScript font trademarks: Times, Helvetica, New Century

Schoolbook, and Palatino are registered trademarks of Linotype

Corporation.

ITC Avant Garde Gothic, ITC Zapf Chancery, ITC Zapf Dingbats,

and ITC Bookman are registered trademarks of International

Typeface Corporation.

WordPerfect is a registered trademark of WordPerfect

Corporation.

Changes are periodically made to this document. Changes,

technical inaccuracies, and typographic errors will be corrected in

subsequent editions.

This document was created on the Xerox 6085 Professional

Computer System using ViewPoint 2.0 software. The typeface is

Optima.

–––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––

4213 Laser Printer

User Guide Update

Printable area

The 4213 and HPLJ printers use slightly different printable areas

on a page. Some jobs, e.g. those without margins, may be

affected. On a letter size page, the HPLJ starts printing 50 dots

from the border of the page, while the 4213 starts printing at 40

dots.

Using the adjustable tray in the PostScript emulation

When using the adjustable tray with the PostScript emulation,

refer to the PostScript emulation section in the appendix for

appropriate page size requests.

Preventing paper jams or recurring messages using the adjustable paper tray

Refer to the section “Using the adjustable paper tray,” in

appendix A1, if you are having paper jams or recurring messages

while using the adjustable paper tray. This information will be

added to the Troubleshooting section in the next revision.

Saving Postscript configurations

Unlike either XES or LJ2D, PostScript emulation settings are saved

permanently by setting the emulation to ON and pressing

ONLINE. For example, if DUPLEX or TUMBLE is set to ON, and

ONLINE is pressed, the new settings have become permanent.

Powering off the printer does not affect the saving of the

changes.

Handling communication error messages

If any communication error messages (COMM ERR PRESS*)

appear on the user interface, the user must press the WARNING

(*) button to complete printing each time this message occurs.

The 4213 printer cannot be placed offline to make changes in the

configuration to correct the problem. The buffer must be

cleared of all data prior to making the configuration changes.

Fonts in landscape orientation

The font status sheet does not print a list of landscape fonts,

however all 4213 fonts are available in the landscape orientation.

XEROX 4213 LASER PRINTER USER GUIDE UPDATE 1

UPDATE

Clear paper path message with HCF installed

If you get a “CLEAR PAPER PATH” message when the High

Capacity Feeder is installed, check to see if the HCF door is

open.

2XEROX 4213 LASER PRINTER USER GUIDE UPDATE

XEROX

Xerox 4213 Laser Printer

Programmer Reference Update

720P86031

July 1992

Xerox Corporation

701 South Aviation Boulevard

El Segundo, CA 90245

copyrightable material and information now allowed by statutory

or judicial law or hereinafter granted, including without limitation,

material generated from the software programs which are

displayed on the screen, such as icons, screen displays, looks,

etc.

July 1992

720P86031

Printed in the United States of America

Xerox®, 4213 and all Xerox products mentioned in this

publication are trademarks of Xerox Corporation.

Centronics and all Centronics products mentioned in this

publication are trademarks of Centronics Data Computer

Corporation.

Data Products and all Data Products products mentioned in this

publication are trademarks of Hewlett-Packard Company.

IBM and all other IBM products mentioned in this publication are

trademarks of International Business Machines.

Hewlett-Packard and HP are registered trademarks of Hewlett-

Packard Company.

Microsoft is a U.S. registered trademark of Microsoft

Corporation.

PostScript® and all PostScript products mentioned in this

publication are trademarks of Adobe systems.

PostScript font trademarks: Times, Helvetica, New Century

Schoolbook, and Palatino are registered trademarks of Linotype

Corporation.

ITC Avant Garde Gothic, ITC Zapf Chancery, ITC Zapf Dingbats,

and ITC Bookman are registered trademarks of International

Typeface Corporation.

WordPerfect is a registered trademark of WordPerfect

Corporation.

Changes are periodically made to this document. Changes,

technical inaccuracies, and typographic errors will be corrected in

subsequent editions.

This document was created on the Xerox 6085 Professional

Computer System using ViewPoint 2.0 software. The typeface is

Optima.

4213 Laser Printer

Programmer Reference Update

LJ2D Paper Source commands and the high capacity feeder

When the optional high capacity feeder is installed and selected

as a paper source through the user interface, the Paper Source

commands as described in chapter 3 of the Xerox 4213 Laser

Printer Programmer Reference may select a different paper tray.

The following table illustrates these differences:

Table 1. Paper source values with high capcity feeder

selected

Tray sequence

(through user

interface) Paper source command effect

HCF The high capacity feeder is addressed as the default tray and is

accessed by the E &l0H command. All the other paper tray

source commands work as described in the 4213 Programmer

Reference.

HCF-TRAY1 The high capacity feeder is addressed as both the default tray

and tray 1; therefore, the HCF is accessed by either the E

&l0H or the E &l1H command. The paper tray 2 command (E

&l4H) works as described in the 4213 Programmer Reference.

HCF-TRAY2 The high capacity feeder is addressed as both the default tray

and tray 2; therefore, the HCF is accessed by either the E

&l0H or the E &l4H command. The paper tray 1 command (E

&l1H) works as described in the 4213 Programmer Reference.

HCF-TRAY1-2 The high capacity feeder is addressed as the default tray no

matter which paper source command (E &l0H, E &l1H, or E

&l4H) is sent.

Font selection

If “best fit” does not give the font you expect, choose the font

by font ID or define the correct criteria for the desired font.

XEROX 4213 LASER PRINTER PROGRAMMER REFERENCE UPDATE 1
