Black 22” Single Top Laptop Desk Riser

Scan the QR code with your mobile device or follow the link

for helpful videos and specifications related to this product.

Instruction Manual

https://vivo-us.com/products/desk-v000a

SKU: DESK-V000A

[email protected]om www.vivo-us.com 309-278-5303

Chat live with an agent!

GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST

2

If you do not understand these directions, or if you have any doubts about the safety of the

installation, please call a qualified technician. Check carefully to make sure there are no missing or

defective parts. Improper installation may cause damage or serious injury. Do not use this product

for any purpose that is not explicitly specified in this manual and do not exceed weight capacity.

We cannot be liable for damage or injury caused by improper mounting, incorrect assembly, or

inappropriate use.

PACKAGE CONTENTS

TOOLS NEEDED

Scissors

DO NOT EXCEED WEIGHT CAPACITY.

Failure to do so may result in serious injury.

ASSEMBLY STEPS

WARNING!

A (x1)

Adjustable

Desktop

B(x1)

4mm Allen

Wrench

STEP 1

Carefully remove desk (A) from packaging and

set on a flat surface.

33lbs

14.97kg

C(x2)

Bolt

D(x1)

Cable Clip

E(x2)

Cable Tie

F(x2)

Foot Pad

A

3

STEP 2

Cut shipping ties from desk. Turn desk upside down, and rotate front feet to extend forward. Secure

feet using bolts (C) and tighten with Allen wrench (B). Apply pads (F) to underside of frame near the

back as shown. Use cable clip (D) and cable ties (E) to manage cables.

S=4mm

C

F

Raise desktop

slowly to keep

items stable.

Keep monitor and

laptop base fully on

the desktop.

Leave enough slack

in cable to allow for

full range of vertical

motion (15” / 38 cm).

Follow the cable

routing instructions to

avoid the potential to

pinch cables.

CAUTION!

Failure to follow these instructions may result in property damage and/or personal injury.

LAST UPDATED: 03/04/2020
