Vivo STAND-V101C User manual

    

Instruction Manual

Email: help@vivo-us.com

Live chat: www.vivo-us.com

Call: 1-800-371- 6 4

-  

 

phillips screwdriver

 

Scan the QR code with your mobile device or follow the link

to helpful videos and specifications related to this product.

- - !! "#   !

E (x1)

Pole

B (x1)

C-Clamp

C (x1)

Plastic Cap D (x1)

Clips

A (x1)

VESA Plate

F (x1)

Base Cover

G (x1)

Grommet

Base

H (x )

Soft Pads

I (x1)

Metal Pad

J (x1)

3mm Allen

Key

K (x1)

mm Allen

Key

L (x1)

6mm Allen

Key

M-C (x4)

M6x14

N (x2)

VESA

Bracket

O(x8)

M x12

P (x8)

M-A (x4)

M4x12

M-B (x4)

M x12

M (x2)

VESA

Bracket

M-D (x4)

M8x20

M-E (x4)

M-F (x4)

M-G (x8)

Spacer

#$% 

 

Attach plastic cap (C) to pole (E).

 &

' 

Slide cable management clip (D) and base cover (F) on to bottom of pole (E). Attach pads (H)

to clamp (B) as shown in the diagram. Thread pole (E) onto clamp (B). Tighten grub screws in

bottom of clamp (B) using 3mm allen key (J). Secure clamp (B) to desktop as shown in

diagram.

' (

Remove screw from top of bolt in clamp (B). Stick soft pads (H) to bottom of grommet

base (G). Slide cable management clip (D) and base cover (F) on to bottom pole (E).

Thread pole (E) onto grommet base (G). Tighten grub screws in bottom of grommet

base (G) using 3mm allen key (J). Slide metal pad (I) over bolt and slide through

grommet hole in bottom of desktop. Thread into bottom of pole (E).

- '  

 )

- '  &

- '  )

Attach VESA bracket (A) to pole (E) using mm allen key (K).

Attach two bolts (M-A or M-B) and washers (M-E) to top mounting holes of

monitor, making sure to leave 3mm of threads exposed. Align bolts (M-A or M-B)

in VESA plate. Secure using two more bolts (M-A or M-B) and washers (M-E) in the

bottom two holes. Tighten all four bolts using phillips screwdriver.

Adjust tension in bracket

using 6mm allen key (L).

- '  * - '  +

Store allen keys (L,K) in

cable management clip (D)

for future adjustments.

Adjust as desired.

- ' ( )

- ' ( *

Attach VESA bracket (A) to pole (E) using mm allen key (K).

Adjust tension in bracket using 6mm allen key (L).

 ) ,-  ) ,-  ) ,-  ) ,-

 ) ,-

- ' ( 

- ' ( &

Mount VESA extension (M,N) to VESA bracket (A) using the

M x12 bolt (O) and the M nut (P) in 200mmx200mm or

200mmx100mm orientations according to mounting holes on

your monitor.

Attach VESA bracket (A) to back of monitor using bolts (M-C or M-D) and

washers (M-F). Spacer (M-G) may be required.

If you do not understand these directions, or if you have any

doubts about the safety of the installation, please call a

qualified technician. Check carefully to make sure there are no

missing or defective parts. Improper installation may cause

damage or serious injury. Do not use this product for any

purpose that is not explicitly specified in this manual. We

cannot be liable for damage or injury caused by incorrect

assembly or inappropriate use.

Email: help@vivo-us.com

Live chat: www.vivo-us.com

Call: 1-800-371- 6 4

For more VIVO products, check out our

website at

www.vivo-us.com.

If any parts are received damaged or defective, please contact

us. We are happy to replace parts to ensure you have a fully

functioning product.

.% /

  

Last updated: 0 /1 /18 4

- ' ( +

Store allen keys (L,K) in cable management clips (D) for future adjustments.

- ' ( 0 Adjust as desired.

 ) ,-
