Vivo CART-V00LW User manual

White Pneumatic Mobile Workstation

Follow along step-by-step with our video walk through by scanning

the QR code with your mobile device or by following the product

link: vivo-us.com/products/cart-v00lw

Instruction Manual

SKU: CART-V00LW

ASSEMBLY VIDEO AVAILABLE:

[email protected]om www.vivo-us.com

309-278-5303

PERSONABLE CUSTOMER SUPPORT

Our friendly product support team is here to help!

DO NOT RETURN ITEM

We’re Here for You!

Missing a Part?

Our customer-minded support team is here for YOU,

Monday-Friday 7am-7pm CST.

We oer immediate assistance with rapid response times

from customer service agents and product techncians to

help you every step of the way!

Monday-Friday

Chat Us:

www.vivo-us.com

Give us a Call:

309-278-5303

Email Us:

[email protected]om

If any parts are received damaged / defective OR you are

missing a part, please reach out to us within 30 days of

product delivery to have it replaced at no cost.

We are happy to replace parts to ensure you have a fully

functioning product

7AM - 7PM

If you do not understand these directions, or if you have any

doubts about the safety of the installation, please call a qualified

technician. Check carefully to make sure there are no missing

or defective parts. Improper installation may cause damage or

serious injury. Do not use this product for any purpose that is

not explicitly specified in this manual. Do not exceed weight capacity. We

cannot be liable for damage or injury caused by improper mounting, incorrect

assembly or inappropriate use.

PRE-ASSEMBLY | BEFORE YOU BEGIN

Product Warranty

Returns | Product Didn’t Work Out?

For the most up to date details on your product’s warranty, please visit

the product’s listing on our website or reach out to customer support.

vivo-us.com/products/cart-v00lw

We oer a hassle-free 30 day return on all products. Contact customer

support at 309-278-5303 or [email protected]om. Please note: For items

ordered in error or no longer needed, the return shipping charges will

be at the buyer’s expense.

WARNING: CHOKING HAZARD

SMALL PARTS - NOT FOR CHILDREN UNDER 3 YEARS. ADULT SUPERVISION IS

REQUIRED.

SERIOUS OR FATAL CRUSHING INJURIES CAN OCCUR FROM TIPOVER. TO HELP

PREVENT TIPOVER:

• NEVER ALLOW CHILDREN TO CLIMB, STAND, HANG, OR PLAY ON ANY PART

OF TV OR TV CART.

• USE TIPOVER RESTRAINT OR ANCHOR STAND TO WALL

USE OF TIPOVER RESTRAINTS MAY ONLY REDUCE, BUT NOT ELIMINATE RISK

OF TIPOVER.

TIPOVER WARNING

WEIGHT CAPACITY

DO NOT EXCEED WEIGHT CAPACITY. Failure to do so may result in serious injury.

17.6lbs

(8kg)

PACKAGE CONTENTS

NOTE: SOME HARDWARE INCLUDED MAY NOT BE USED

Please consult the parts list below and ensure you have everything you need to assemble

your product. If parts are missing or damaged, please contact us.

Phillips Screwdriver

TOOLS NEEDED:

DIFFICULTY LEVEL

A (x1)

Leg

B(x1)

Base

C (x1)

Desktop

D (x1)

Support Bracket

E (x2)

Locking Caster

F(x2)

Caster

S-A (x4)

M6x60mm Screw

S-B (x4)

M6x12mm Screw

S-C (x4)

M6x12mm Flat

Head Screw

S-D (x4)

Washer

T-A (x1)

4mm Allen

Wrench

T-B (x1)

5mm Allen

Wrench

T-C (x1)

Wrench

STEP 1: Install Casters

Screw Locking Casters (E) and Casters (F) into Base (B) using Wrench (T-C).

ASSEMBLY STEPS

T-C

Locking Caster

Caster

Base

T-C

Wrench

STEP 2: Assemble Leg to Base

Assemble Leg (A) to Base (B) using M6x60mm Screws (S-A) and Washers (S-D), making sure

the foot pedal is facing forward. Tighten with the 5mm Allen Wrench (T-B).

Leg

S-A

M6x60mm Screw

S-A

T-B

S-D

Washer

T-B

5mm Allen Wrench

Mount Support Bracket (D) to the top of the Leg (A) using M6x12mm Screws (S-B). Tighten

with the 4mm Allen Wrench (T-A).

STEP 3: Install Support Bracket

Support Bracket

S-B

M6x12mm Screw

T-A

4mm Allen Wrench

S-B

T-A

Assemble Desktop (C) to Support Bracket (D) using the M6x12mm Flat Head Screws (S-C),

making sure the longer end of Desktop (C) is facing forward. Tighten with the 4mm Allen

Wrench (T-A).

STEP 4: Secure Desktop

Desktop

S-C

M6x12mm Flat Head Screw

S-C

T-A

4mm Allen Wrench

Step on the foot pedal to unlock the leg and adjust the desktop height.

STEP 5: Adjust Height
