TW Audio M15 User manual

M15 Operating Manual

Operating Manual M15

Introduction

Thank you for choosing a high quality product "MADE IN GERMANY" from TW AUDiO.

The M15 multifunctional speaker is a real all-rounder.

You can use it as a full-range stand-alone box at a party. Or as a delay line speaker. Or

for voice reinforcement. Or as a monitor on stage. Or in combination with one of our pas-

sive loudspeakers with B15 as a drum fill or small club PA. Or actively driven with the

B18, B30 or even BSX. And much more.

And in addition, the M15 is equipped with air cargo rigging tracks over which double stud

fittings or flying brackets can easily be mounted without the help of tools.

Mount it. Click it in. Done.

If you lend your product to another party, inform that party of the safety-related operating

procedures and hand over this operating manual. If you therefore require additional cop-

ies of this operating manual, they can be obtained free of charge from TW AUDiO or

downloaded from: www.twaudio.de

Strictly adhere to the instructions contained in this operating manual that are marked as

follows:

Instructions in the operating manual

WARNING

This symbol in combination with the signal word "Warning" identifies a potentially haz-

ardous situation. Failure to comply with this safety instruction can lead to serious injury

or even death.

WARNING

This symbol in combination with the signal word "Warning" identifies a potentially haz-

ardous situation for persons with a pacemaker. Failure to comply with this safety instruc-

tion can lead to serious injury or even death.

CAUTION

This symbol in combination with the signal word "Caution" identifies a potentially hazard-

ous situation. Failure to comply with this safety instruction can lead to light or moderate

injury.

NOTE

This symbol in combination with the signal word "Note" identifies a potentially hazardous

situation. Failure to comply with this safety instruction can lead to product damage.

TIP

This symbol in combination with the signal word "Tip" identifies additional information or

notes that will simplify working with TW AUDiO products on the basis of practical experi-

ence.

Operating Manual M15

Operating manual: OM-M15

Version 1.1 en, 09/2016

All information contained in this operating manual was correct to the best of our knowl-

edge at the time of printing.

Quality warranties or assurance of suitability for a certain type of use based on the tech-

nical specifications, dimensions and weights are not granted by TW AUDiO.

TW AUDiO also shall not assume liability for any secondary damage (property damage

and/or personal injury) nor for the failure to comply with this operating manual.

TW AUDiO reserves the right to make changes that take into account the latest engi-

neering advancements.

TW AUDiO is pleased to receive suggestions for improvement and recommendations on

this operating manual. Please send us any feedback you may have to the following e-

mail address.

[email protected]

TW AUDiO GmbH

Osterholzallee 140-2

71636 Ludwigsburg, Germany

Telephone: +49 (0) 71 41 - 48 89 89 0

Telefax: +49 (0) 71 41 - 48 89 89 99

Notes on the products

Read manual

before use!

Before setting up the device, read the operating manual carefully and keep this docu-

ment in a safe place together with the M15 loudspeaker.

General information

Operating Manual M15

Content

Safety | Intended use .....................................................................................................1

Overview ........................................................................................................................3

Components ....................................................................................................................... 3

Variants .............................................................................................................................. 4

Technical data ................................................................................................................5

Data sheet .......................................................................................................................... 5

Wiring diagram ................................................................................................................... 5

Setting up the loudspeaker ..........................................................................................6

Setup .................................................................................................................................. 6

Rotating the horn ................................................................................................................ 6

Connecting cables ..............................................................................................................7

Operation ............................................................................................................................ 7

Transport and storage ..................................................................................................8

CE Conformity Declaration ...........................................................................................9

Disposal ........................................................................................................................10

Operating Manual M15

1. Safety | Intended use

Please adhere to the following safety instructions to avoid risks when operating the loud-

speakers.

The M15 loudspeaker was developed for professional use in sound systems. The loud-

speaker may only be used by trained and qualified personnel.

Note the operating modes described in this operating manual.

Other uses are not permissible.

TW AUDiO GmbH shall not be held liable for any damage that ensues from unintended

use.

WARNING

Loudspeakers generate an electromagnetic field. Persons with pacemakers are not per-

mitted to remain in the immediate vicinity of loudspeakers as the electromagnetic fields

can cause pacemakers to malfunction.

WARNING

When working with heavy loads over 20 kg [44,09 lb], use suitable aids (dollies, hoisting

slings, etc.). Multiple people may be required depending on the situation.

Ensure that the units are in a stable position and are firmly attached. A falling loud-

speaker can result in serious personal injury and property damage.

When using and assembling TW AUDiO loudspeakers, only use materials specified by

TW AUDiO. These tasks must be performed by qualified personnel. Adhere to the appli-

cable safety regulations.

NOTE

When using the loudspeakers, ensure that they are not exposed to the following ambient

conditions:

• Direct sunlight

• Moisture

• Jolting

•Dust

WARNING

Keep away from the immediate vicinity of loudspeakers that are operated at high sound

pressure levels. These loudspeaker systems are capable of endangering your health.

Sound levels beginning as low as approx. 90 dB SPL can lead to long-term hearing im-

pairment.

NOTE

Avoid:

• Feedback

• Distorted signals (clipping)

• Peaks that result when devices are switched on or hot plugged and unplugged.

These signals can lead to loudspeaker overload..

Operating Manual M15

Note that TW AUDiO does not provide a warranty for damage that can be attributed to

this type of overload and therefore cannot be held liable for any secondary damage.

WARNING

Ensure that the loudspeaker is not exposed to permanent thermal overloads. This may

cause a fire and result in serious personal injury and property damage.

NOTE

A permanent, magnetic field is present in the immediate vicinity of loudspeakers. Ensure

that objects which react sensitively to magnetic fields are not located in the immediate

vicinity of the loudspeaker. In particular, this applies to magnetic data carriers, EC cards

and CRT displays. A distance of approx. one meter is sufficient to avoid damage.

NOTE

Check loudspeakers and accessory parts regularly for visible wear. This is essential to

ensure fault-free operation on a permanent basis. Replace worn parts promptly. Spare

parts can be obtained from TW AUDiO.

Operating Manual M15

2. Overview

Figure 2.1 - Overview

1. Top rigging track

2. 15 mm multiplex enclosure – Warnex surface finish

3. Rotable horn with 1.4" compression driver

4. 15" cone driver

5. Rubber feet (4 pieces)

6. Rear rigging track

7. Connection panel with two SpeakON®connectors

8. Type label

9. Ergonomic carrying handles, top and bottom

10. Bottom rigging track with integrated cabinet flange

2.1 Components

Operating Manual M15

The M15 loudspeaker is available in right and left variants. These versions differ in the

side on which the slanted wedge is located on the enclosure.

Figure 2.2 - Left and right versions

2.2 Variants

left version right version

1,4" compression driver

Operating Manual M15

3. Technical data

Figure 3.2 - Wiring diagram

3.1 Data sheet

Components 1x 15" LF/1x 1.4" HF

Frequency response 50 – 19,000 Hz

Power handling, program/

peak 800/1600 W

Impedance 8Ω

Coverage angles (h × v) 75° x 50°

SPL max./1 m 131 dB

Dimensions (h × w × d) 706 x 440 x 374 mm [27,80 x 17,32 x 14,72 in]

Weight 24.9 kg [54,9 lb]

Finish Warnex texture paint

3.2 Wiring diagram

LF 15"

HF 1,4"

8 OHM

1,3 kHz

PIN 1+

PIN 1–

PIN 2+

PIN 2–

PIN 1+

PIN 1–

PIN 2+

PIN 2–

parallel

PASSIVE

X-OVER

Operating Manual M15

4. Setting up the loudspeaker

The M15 loudspeaker is designed for standing, vertical and horizontal operation. A vari-

ety of accessories is available from TW AUDiO to securely attach the loudspeaker, e.g.

on stands or suspended horizontally or vertically from trusses and motor lifts.

The horn of the M15 loudspeaker is mounted at the factory in such a way that the hori-

zontal coverage is 75° and the vertical coverage is 50°. In some situations, it may be ad-

vantageous to switch the coverage of the high frequency range. For this purpose, the

horn can be rotated. Proceed as follows.

1. Place the M15 loudspeaker with the wedge inclined toward you with the front grill

facing up. Ensure that the working surface is clean with a non-slip finish.

2. To remove the front grill of the loudspeaker, use a 3 mm hex key. Remove the four

fixing screws at the top and bottom of the loudspeaker enclosure.

3. Release the four screws of the horn using a 3 mm hex key. Pull the horn and the

compression driver upward out of the loudspeaker enclosure.

4. Check that the seal between the enclosure and horn is properly seated.

5. Rotate the horn carefully by 90° and reinsert the horn and driver back into the re-

cess. Screw it onto the enclosure using medium-strength thread locker.

6. Screw the front grill back on.

4.1 Setup

WARNING

Ensure that the loudspeakers are securely attached to prevent personal injury and prop-

erty damage.

NOTE

TW AUDiO recommends using only the accessories specified by TW AUDiO to secure

the loudspeakers.

4.2 Rotating the horn
