TW Audio BSX User manual

Operation manual

BSX

Operation manual BSX

Introduction

So far the Big-Subwoofer-eXtender is the biggest TW AUDiO sub to date.

Equipped with two powerful 21“ drivers with a peak performance potential of 10kW per dri-

ver, this speaker is able to reproduce a truly massive bass foundation.

Thanks to the hybrid enclosure principle its efﬁciency is maximised so that the energy is still

perceptible even at a great distance. Primarily the BSX functions as a true sub bass exten-

sion.

Because of its extremely stiff yet lightweight membranes the BSX is able to deliver frequen-

cies of up to 120 Hz clean and true to its impulses. As a full range sub the BSX is directly

combinable with the M, T, C or VERA systems.

Instructions in this user manual

NOTE

TIP

CAUTION

WARNING

Thank you for choosing a high-quality product “MADE IN GERMANY” from the brand

TW AUDiO.

If you lend your product to another party, inform that party of the safety-related operating pro-

cedures and hand over this assembly guide. If you require additional copies of this manual,

you can obtain them free of charge from TW AUDiO or download them from www.twaudio.de

Strictly adhere to the instructions contained in this operating manual that are marked as

follows:

This symbol in combination with the signal word “Warning” identiﬁes a potentially hazardous

situation. Failure to comply with this safety instruction can lead to serious injury or even death.

This symbol in combination with the signal word “Warning” identiﬁes a potentially hazardous

situation for persons with a pacemaker. Failure to comply with this safety instruction can lead

to serious injury or even death.

This symbol in combination with the signal word “Caution” identiﬁes a potentially hazardous

situation. Failure to comply with this safety instruction can lead to light or moderate injury.

This symbol in combination with the signal word “Note” identiﬁes a potentially hazardous

situation. Failure to comply with this safety instruction can lead to product damage.

This symbol in combination with the signal word “Tip” identiﬁes additional information or

notes that will simplify working with TW AUDiO products on the basis of practical experience.

Operation manual BSX

Notes on the products

Read manual

before use!

Before using the device, carefully read the operating manual and keep it with the BSX loudspe-

aker.

General information

Operation manual: OM-BSX

Version 2.1 en, 07/2023

All information contained in this operating manual was correct to the best of our knowledge

at the time of printing.

Quality warranties or assurance of suitability for a certain type of use based on the technical

speciﬁcations, dimensions and weights are not granted by TWAMBO.

TWAMBO also shall not assume liability for any secondary damage (property damage and/or

personal injury) nor for the failure to comply with this operating manual!

TWAMBO reserves the right to update this document based on recent developments.

TWAMBO GmbH

Karl-Hofer-Str. 42

14163 Berlin

Germany

Phone : + 49 (0) 71 41-48 89 89 0

Fax: + 49 (0) 71 41-48 89 89 99

E-Mail: [email protected]

WWW: www.twaudio.de

Operation manual BSX

Content

1. Safety | Intended use...................................................................................................... 5

2. Overview ........................................................................................................................ 7

2.1 Components ........................................................................................................... 7

2.2 Operation modes..................................................................................................... 8

2.2.1 Full ..................................................................................................................... 8

2.2.2 Infra.................................................................................................................... 8

3. Technical specifications .................................................................................................. 9

3.1 Data sheet............................................................................................................... 9

3.2 Connection diagram ................................................................................................ 9

4. Commissioning............................................................................................................. 10

4.1 Setup .................................................................................................................... 10

4.2 Operation .............................................................................................................. 11

4.3 Connecting the cable............................................................................................. 11

4.4 Wind load .............................................................................................................. 12

4.5 Possible vertical system setups ............................................................................. 12

4.5.1 T24(N) loudspeaker on BSX loudspeaker.......................................................... 13

4.5.2 B30 loudspeaker on BSX loudspeaker ............................................................. 13

4.5.3 Two BSX loudspeakers on top of each other .................................................... 14

4.6 Possible horizontal system setups ......................................................................... 15

4.6.1 Two B18 loudspeaker on BSX loudspeaker ...................................................... 15

4.6.2 Variant 1: two B18 loudspeaker laid on BSX loudspeaker ................................. 16

4.6.3 Variant 2: two B18 loudspeaker laid on BSX loudspeaker ................................. 16

4.6.4 Two B30 loudspeaker laid on BSX loudspeaker................................................ 17

4.6.5 Three B30 loudspeaker on BSX loudspeaker.................................................... 17

4.6.6 Variant 1: two VERA S32 loudspeaker on BSX loudspeaker .............................. 18

4.6.7 Variant 2: two VERA S32 loudspeaker on BSX loudspeaker .............................. 18

4.6.8 Two VERA S33 loudspeaker on BSX loudspeaker ............................................. 19

4.6.9 One VERA S33 loudspeaker on BSX loudspeaker............................................. 19

4.6.10 BSX loudspeaker laid on BSX loudspeaker..................................................... 20

4.6.11 Variant 1: two BSX loudspeaker placed on BSX loudspeaker.......................... 21

4.6.12 Variant 2: two BSX loudspeaker placed on BSX loudspeaker.......................... 21

4.6.13 One VERA L24 loudspeaker on BSX loudspeaker ........................................... 22

5. Transport and Storage.................................................................................................. 23

6. CE Conformity Declaration............................................................................................ 24

7. Disposal ....................................................................................................................... 25

Operation manual BSX

1. Safety | Intended use

The BSX loudspeaker was developed for use in professional sound systems. The loudspea-

ker may only be used by trained and qualiﬁed personnel.

WARNING

NOTE

Avoid:

• Feedback

• Distorted signals (clipping) and

• Peaks resulting from switching on devices, plugging in devices or unplugging devices during

operation.

Such signals can lead to loudspeaker overload and ultimately to loudspeaker failure.

Keep away from the immediate vicinity of loudspeakers that are operated at high sound pres-

sure levels. These loudspeaker systems are capable of endangering your health. Sound levels

beginning as low as approximately 90dB SPL can lead to long-term hearing impairment.

When setting up loudspeakers, ensure that they are not exposed to the following ambient

conditions:

• Direct sunlight

• Humidity

• Jolting

• Dust

When working with heavy loads exceeding 20 kg (44 lbs.), use suitable aids (dollies, hoisting

slings, etc.). Multiple persons may be required depending on the situation.

Ensure that the units are in a stable position and are ﬁrmly attached. A falling loudspeaker can

result in serious personal injury and property damage.

When using and assembling TW AUDiO loudspeakers, only use materials speciﬁed by

TW AUDiO. These tasks must be performed by qualiﬁed personnel. Adhere to the applicable

safety regulations.

Loudspeakers generate an electromagnetic ﬁeld. Persons with pacemakers are not permit-

ted to remain in the immediate vicinity of loudspeakers as the electromagnetic ﬁelds can

cause pacemakers to malfunction.

Please adhere to the following safety instructions to avoid risks when operating loudspeakers.

Note the operating modes described in this operating manual. Other uses are not permis-

sible.

Damage caused by improper use is not covered by TWAMBO.

Operation manual BSX

WARNING

NOTE

Check loudspeakers and accessory parts regularly for visible wear. This is essential to ensure

continuing fault-free operation. Worn parts should be replaced immediately. Spare parts are

available from TWAUDiO.

A permanent magnetic ﬁeld is present in the immediate vicinity of loudspeakers. Ensure that

objects which react sensitively to magnetic ﬁelds are not located in the immediate vicinity of

the loudspeaker. In particular, this applies to magnetic storage media, magnetic stripe cards

such as debit cards and CRT displays. A distance of approximately one meter is sufﬁcient to

avoid damage.

Note that TWAMBO does not provide a warranty for damage that can be attributed to this type

of overload and therefore cannot be held liable for any secondary damage.

Ensure that the loudspeaker is not exposed to permanent thermal overloads. Thermal over-

loads may cause a ﬁre and result in serious personal injury and property damage.

Operation manual BSX

2. Overview

2.1 Components

1. Milling for rubber feet for safely stacking loudspeakers

2. Ergonomic carrying handles (12 pieces)

3. 18 mm multiplex enclosure – polyurea surface ﬁnish

4. Rubber feet (8 pieces)

5. Type label

6. Standard connection panel

7. 100 mm castor with stopper (2 pieces)

8. 100 mm castor without stopper (2 pieces)

9. 21“ cone drivers

Figure 2.1 - Overview

Operation manual BSX

2.2 Operation modes

The BSX loudspeaker can be operated in two operation modes. The operation mode is selec-

ted by choosing the preset in the system ampliﬁer.

2.2.1 Full

In full mode, the BSX has a higher upper cutoff frequency. This mode is recommended for

operating the BSX with tops only.

2.2.2 Infra

Infra operating mode is recommended when using the BSX loudspeaker in a system with addi-

tional subwoofers. In this mode, the lower cutoff frequency results in a bass range extension.

Operation manual BSX

3. Technical speciﬁcations

3.1 Data sheet

Drivers 2x 21“ LF

Frequency response 27 - 120 Hz

Power handling (program/Peak) 2x 3600 / 2x 7200 W

Impedance 2x 4 Ω

Max. SPL / 1 m 142 dB

Dimensions (h x w x d) 606 x 1406 x 900 mm [23,86 x 55,35 x 35,43 in]

Weight 109 kg [240,3 lbs]

Surface Polyurea surface ﬁnish

3.2 Connection diagram

Figure 3.2 - Connection diagram

PIN 1+

PIN 1-

PIN 2+

PIN 2-

parallel

LF 21"

4 OHM

PIN 1+

PIN 1-

PIN 2+

PIN 2-

Operation manual BSX

4.1 Setup

The BSX loudspeaker is designed for standing, vertikal and horizontal operation.

WARNING

4. Commissioning

WARNING

Make sure that all system structures are located on a ﬁrm, level surface and that the surface

can bear the total weight!

Make sure the speakers are securely fastened to prevent personal injury and property damage.

Please note that setting up the system setups always requires two, preferably four persons!

TW AUDiO recommends using only the accessories speciﬁed by TWAUDiO for securing and

mounting loudspeakers.

Make sure that no unauthorized persons can access the system structures!

Cordon off the area professionally!

Any inﬂuences on your system setup, such as leaning against objects (or people) and ﬂying

objects around, be refrained from!

NOTE

WARNING

NOTE

Use all four rubber feets and insert them into the corresponding millings for rubber feets on

the BSX loudspeaker.

Note that the four black dots represent the rubber feets on the upper loudspeakers and the

millings for rubber feets on the BSX loudspeaker.
