TRENDnet TEG-PCBUSR User manual

TRENDnet

TRENDware, USA

What's Next in Networking

TEG-PCBUSR

Version 07.27.05

Gigabit Ethernet PC Card Adapter

Quick Installation Guide

Gigabit Ethernet PC Card Adapter

Ghid de Instalare rapida

Table of Contents

English ................................................................................. 1

1. Prepare for Installation ..................................................

2. Product Detail ................................................................

3. Hardware Installation .....................................................

4. Driver Installation ...........................................................

5. Verify Installation ...........................................................

1. Pregatiti-va pentru instalare ...........................................

2. Detalii Produs ..............................................................

3. Instalarea Hardware .....................................................

4. Instalarea Driverelor ......................................................

5. Verificarea Instalarii .......................................................

Troubleshooting ....................................................................

Românǎ .........................................................................................

Thank you for purchasing TRENDnet's TEG-PCBUSR Gigabit Ethernet PC

Card Adapter.

This guide will help you set up your Gigabit Ethernet PC Card Adapter.

Following the installations should be quick and easy. If you run into problems,

please refer to the Troubleshooting section. If you need further technical

support, please visit www.TRENDNET.com or call technical support by phone.

Verify Package Contents

Please make sure you have everything in the box:

1. Prepare for Installation

English QIG

English

Minimum System Requirements

1. Pentium 266Mhz or faster processor

2. 64MB RAM or more

3. Available 32-bit CardBus Type II slot

4. Windows XP, 2000, ME, 98SE, Microsoft Network Client for DOS (NDIS 2

driver), or NetWare Client for DOS (ODI driver)

TEG-PCBUSR Quick Instllation Guide Driver CD-ROM

TRENDnet

TRENDware, USA

What's Next in Networking

TEG-PCBUSR

Version 07.27.05

Gigabit Ethernet PC Card Adapter

Quick Installation Guide

Gigabit Ethernet PC Card Adapter

Ghid de Instalare rapida

2. Product Detail

The Gigabit Ethernet CardBus Adapter has a RJ-45 connector, and two LEDs

that indicate data rate and network activity.

English

RJ-45

connector

LED that indicates

data rate

LED that indicates

network activity

3. Hardware Installation

English

1. Boot up your laptop PC and make sure Windows's Desktop is properly

loaded.

2. Insert the TEG-PCBUSR into an available PC Card slot.

3. Make sure the TEG-PCBUSR is inserted all the way to the end of the slot.

4. Your laptop should emit a beeping sound that indicates newly installed

hardware.

4English

4. Driver Installation

After inserting the TEG-PCBUSR, the “Found New Hardware Wizard” will

appear. Windows will automatically detect and ask you to install the Gigabit

Ethernet Driver for the TEG-PCBUSR.

1. Insert the TEG-PCBUSR Driver CD-ROM into your computer's CD-ROM

drive.

2. Click Install from a list or specific location (Advanced). Click Next.

3. Click Search for the best driver, click location:, and type a:\winxp in the

text box. Click Next.

Windows XP

5English

4. NOTE: TRENDnet's Gigabit Ethernet PC Card has been fully tested under all

supported Windows Operating Systems and has been approved for their

functionality; click Continue Anyway.

5. Click Finish.

Your driver installation is now complete.

NOTE: If you would like to verify the TEG-PCBUSR has been installed

properly for your windows, go to the Verify Installation section.

6English

After inserting the TEG-PCBUSR, the “Found New Hardware Wizard” will

appear. Windows will automatically detect and ask you to install the Gigabit

Ethernet Driver for the TEG-PCBUSR.

1. Insert the TEG-PCBUSR Driver CD-ROM into your computer's CD-ROM

drive.

2. Click Next.

Windows 2000

3. Click Search for a suitable driver for my device (recommended). Click

Next.

7English

4. Click Specify a location. Click Next.

5. Type a:\win2k in the text box. Click OK.

6. Click Next.

8English

7. Click Yes.

8. Click Finish.

Your driver installation is now complete.

NOTE: If you would like to verify the TEG-PCBUSR has been installed

properly for your windows, go to the Verify Installation section.
