TRENDnet TBW-101UB User manual
Copyright ©2004. All Rights Reserved. TRENDware International, Inc.
TRENDnet
TRENDware, USA
What's Next in Networking
TBW-101UB
Version 11.18.04
Compact Bluetooth USB Adapter
Quick Installation Guide
Guide d'installation rapide de
l'adaptateur USB Bluetooth
Kurzanleitung zur Installation des
Bluetooth USB-Adapters
Guía de instalación rápida del
adaptador USB Bluetooth
Table of Contents
English ......................................................................................................
Troubleshooting ..........................................................................................
1
1
2
6
10
13
1. Prepare for Installation .......................................................................
2. Install Bluetooth Utility .......................................................................
3. Verify Installation ................................................................................
4. Bluetooth Settings ..............................................................................
Thank you for purchasing the TBW-101UB Compact Bluetooth USB Adapter.
This adapter will allow you to share files, resources, and an internet connection
between multiple Bluetooth-enabled devices.
This guide will help you set up and configure your Bluetooth adapter. Following
the installation instructions should be quick and easy. If you run into problems,
please refer to the Troubleshooting section or User's Guide on the CD-ROM. If
you need further technical support, please visit www.trendnet.com or call us by
phone.
Verify Equipment
Before installing the Bluetooth adapter, you should have a personal computer
with:
· Windows 98SE, ME, 2000 or XP installed
· One USB 1.1 port available
· A CD-ROM Drive
Verify Package Contents
Please make sure you have everything in the box:
1English
1. Prepare for Installation
English QIG
Quick Installation Guide
CD-ROM
TBW-101UB
Copyright ©2004. All Rights Reserved. TRENDware International, Inc.
TRENDnet
TRENDware, USA
What's Next in Networking
TBW-101UB (V.2)
Version 11.10.04
High-Power Bluetooth USB Adapter
Quick Installation Guide
Guide d'installation rapide de
l'adaptateur USB Bluetooth
Kurzanleitung zur Installation des
Bluetooth USB-Adapters
Guía de instalación rápida del
adaptador USB Bluetooth
USB Cable
2
1. Turn on your computer.
2. Insert the Utility CD-ROM into your CD-ROM Drive.
3. The Auto-Run function will automatically start the software installation
wizard. If the Auto-Run function does not start automatically, please browse
the installation CD to find the "Setup.exe" file. Double-click setup.exe to
continue.
4. Click Next.
2. Install Bluetooth Utility
NOTE: You must install the Bluetooth Utility program before you install
the Bluetooth USB Adapter.
English
3
5. Click I accept the terms in the license agreement, and click Next.
6. Click Next.
English
7. Click Install.
4
Windows 98SE users will see the following message. Insert your Windows
98SE CD-ROM into your CD-ROM drive, click OK, and select CD-ROM. This
will allow your system to update the appropriate files.
English
Windows 2000/XP users will see the following message. Click OK to continue.
8. During installation, the following window will appear.
5
9. When you see the above message, insert the Bluetooth USB Adapter
into your USB port and click OK to continue.
English
10. Click Finish.
NOTE: For Windows 98SE/ME/2000 users, the Windows will prompt
you with a message to restart your PC. Click Yes to restart the
computer.
6English
Windows 98SE/ME
3. Verify Installation
1. Click Start, highlight Settings and click Control Panel.
2. Double-Click the System Icon and the System Properties box will
appear.
3. Go to the Device Manager tab, and double-click on BTW. The Bluetooth
USB Adapter will be listed in this category.
This section is to ensure that your Bluetooth USB Adapter is installed and is
working properly.
7
5. Your Bluetooth USB Adapter is properly installed and ready for use.
English
4. Right-click on Bluetooth USB Adapter, and select Properties. The Device
Status field will say “This device is working properly.” If it doesn't, refer to the
Troubleshooting section (Q1).
8English
1. Click Start, and then click Control Panel.
2. Double-Click the System Icon and the System Properties Box will appear.
3. Click the Hardware Tab. Then, click the Device Manager button; the Device
Manager Window will appear. Double-click Bluetooth Devices. Bluetooth
USB Adapter will be listed in this category.
Windows 2000/XP
