TRENDnet TU2-ETG User manual
TU2-ETG
Quick Installation Guide
Table of Contents
Table of Contents
Version 06.12.2007
English .....................................................................................................
Troubleshooting ........................................................................................
1
1
2
6
1. Before You Start
2. .....................................................................................
................................................................................
How to Install
System Requirements
Application
CD-ROM Drive
CPU: 300MHz or above/ 800MHz or above (Windows Vista)
Memory: 256 MB RAM or above/ 512 MB RAM or above (Windows Vista)
Computer With An Available USB 1.1 or 2.0 Port
Windows Vista/2003 Server/XP/2000/ME/98SE
TU2-ETG
Driver CD-ROM
Quick Installation Guide
Package Contents
1. Before You Start
English
1
USB 2.0 to 10/100/1000Mbps
Gigabit Ethernet Adapter
(TU2-ETG)
8-Port 10/100/1000Mbps
Gigabit Switch
(TEG-S80TXE)
Notebook with Gigabit
CardBus PC Card
(TEG-PCBUSR)
Workstation with PCI 10/100Mbps
Fast Ethernet Card
(TE100-PCIWA)
Internet
Gigabit Fast Ethernet
2. How to Install
English
2
1. Insert the CD-ROM into your
computer's CD-ROM Drive.
3. Connect the Adapter to an
available USB port on your
computer. The “Found New
Hardware Wizard” will appear.
Note: Do not connect the TU2-ETG to your computer until instructed to do so.
Note: For Windows Vista/ME/98SE drivers will automatically install. Proceed to
step 8. For Windows 2003 Server, XP and 2000, continue on to step 4.
2. Follow the InstallShield Wizard
instructions. Click Yes, I want to
restart my computer now and
then click Finish.
English
3
5. Click Install the
software automatically
(Recommended)
and then click Next.
Windows XP/2003 Server
4. Select No, not this
time, and then click
Next.
Windows 2000
4. Click Yes.
5. Proceed to step 8.
English
4
Windows XP/2003 Server
6. Click Continue
Anyway.
7. Click Finish.
English
5
8. Connect a Cat-5e or Cat-6 RJ-45
cable from the Adapter to a Switch,
Router or Cable/DSL Modem.
Your installation is now complete.
For detailed information regarding the TU2-ETG configuration and advanced
settings, please refer to User Guide on the Driver and User Guide CD-ROM.
Register Your Product
To ensure the highest level of customer service and support, please take a moment to
register your product Online at: www.trendnet.com/register
Thank you for choosing TRENDnet
6
Q1:
A1:
Q2:
A2:
Q3:
A3:
Q4:
Can I connect or disconnect the TU2-ETG while the computer is on?
Yes, you can connect or disconnect the TU2-ETG while the computer is on
because the USB interface is Plug-and-Play compliant and hot-pluggable.
Windows is unable to recognize my hardware. What should I do?
First, make sure your computer meets the minimum requirements as specified
in Section 1 of this Quick Installation Guide. Second, try plugging the adapter into
a different USB port.
Windows recognizes my new hardware, but I'm unable to connect to my
network. What should I do?
First, verify that the network cable is securely connected from your switch or
router to your adapter. Second, verify that the LEDs on your adapter are lit. Third,
verify that the TCP/IP settings are set to Obtain an IP address automatically.
When I connect the adapter to a gigabit switch, I am not getting gigabit
speeds. What should I do?
Make sure you are using CAT-5e or CAT-6 Ethernet Cables. Some CAT-5
cables are not rated to run in Gigabit.
If you still encounter problems or have any questions regarding the TU2-ETG, please
refer to the User's Guide included on the Driver CD-ROM or contact TRENDnet's
Technical Support Department.
A4:
Troubleshooting
Certifications
This equipment has been tested and found to comply with FCC and CE Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received. Including interference that may
cause undesired operation.
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV
INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS
EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO
OPERATE THE EQUIPMENT.
Waste electrical and electronic products must not
be disposed of with household waste. Please
recycle where facilities exist. Check with you Local
Authority or Retailer for recycling advice.
ADVERTENCIA
En todos nuestros equipos se mencionan claramente las caracteristicas del adaptador de alimentacón
necesario para su funcionamiento. El uso de un adaptador distinto al mencionado puede producir
daños fisicos y/o daños al equipo conectado. El adaptador de alimentación debe operar con voltaje y
frecuencia de la energia electrica domiciliaria existente en el pais o zona de instalación.
Copyright ©2007. All Rights Reserved. TRENDnet.
20675 Manhattan Place
Torrance, CA 90501
USA
Product Warranty Registration
Please take a moment to register your product online.
Go to TRENDnet’s website at http://www.trendnet.com/register
TRENDnet Technical Support
US Canada
24/7 Tech Support
Toll Free Telephone: 1(866) 845-3673
Europe (Germany France Italy Spain Switzerland UK)
English/Espanol - 24/7
Francais/Deutsch - 11am-8pm, Monday - Friday MET
English/Espanol - 24/7
Francais/Deutsch - 11am-8pm, Monday - Friday MET
Worldwide
Telephone: +(31) (0) 20 504 05 35
Toll Free Telephone: +00800 60 76 76 67
.
. . . . .
