TRENDnet TBW-105UB User manual
TBW-105UB
Quick Installation Guide
Table of Contents
(Version 08.28.2006)
English ......................................................................................................
Troubleshooting .........................................................................................
1
1
2
4
6
1. Before You Start
2. How to Install .....................................................................................
3. Configuring the Bluetooth Adapter ....................................................
................................................................................
System Requirements
1. Before You Start
English
1
Package Content
TBW-105UB
Quick Installation Guide
Utility & Driver CD-ROM
CD-ROM drive
Computer With An Available USB 1.1 or 2.0 Port
CPU: Pentium 300MHz or Above
Memory: 256 MB or Above
Hard Drive Space: 50MB or Above
Windows 2000/XP
Application
* Backwards compatible with USB 1.1 at 12Mbps
PDA
Bluetooth
Headset Printer
(TBW-105UB)
Compact Bluetooth USB 2.0 Adapter
Cell Phone
Note: Do not insert the TBW-105UB USB adapter until instructed to do so.
Note: For Windows 98SE and ME, refer to the User's Guide.
2. How to Install
English
2
1. Insert the Utility & Driver
CD-ROM into your CD-ROM drive
and click Install Utility.
3. Select I accept the terms in the
license agreement. Click Next
2. Click Next.
4. Click OK.
6. Click Finish.
7. Click Yes (Windows 2000 only).
English
3
5. When you reach this screen,
connect the TBW-105UB into the
computer's USB port. Then click
OK.
Your installation is now complete.
For detailed information regarding the TBW-105UB configuration and
advanced settings, please refer to the User's Guide included on the Utility &
Driver CD-ROM or TRENDnet's website at www.trendnet.com
English
4
3. Configuring the Bluetooth Adapter
1. Double-click the Bluetooth icon on
your system tray.
4. When you reach this screen, click
Skip.
2. Click Next.
3. Click Next.
Note: Make sure your Bluetooth device is powered on and in pairing mode.
English
5
9. Type in a Bluetooth security
code (for example: 0000. Please
consult your Bluetooth device's
manual for more information) and
then click OK. Then put in the
same Bluetooth security code on
your Bluetooth device.
10. Double left-click on your
Bluetooth device to show the
available services.
Your configuration is now complete.
For detailed information regarding the TBW-105UB configuration and
advanced settings, please refer to the User's Guide included on the Utility &
Driver CD-ROM or TRENDnet's website at www.trendnet.com
6. Double-click the My Bluetooth
Places icon.
7. Click Bluetooth -> Search For
Devices.
8. Right click on your Bluetooth
device and then click Pair.
5. Click Finish.
Q1:
A1:
Q2:
A2:
Q3:
A3:
Q4:
A4:
Windows is unable to recognize my hardware. What should I do?
First, make sure your computer meets the minimum requirements as specified
in Section 1 of this Quick Installation Guide. Second, you must install the Bluetooth utility
BEFORE you physically install your Bluetooth Adapter. Third, plug the adapter into a
different USB slot.
The Bluetooth software is unable to detect my Bluetooth-enabled device. What should I
do?
First, disable any software firewall programs such as ZoneAlarm or Norton Internet
Security. If your have Windows XP installed on your computer, make sure to disable the
built-in XP firewall. Second, make sure your Bluetooth device is powered on.
I cannot pair my Bluetooth device to the TBW-105UB USB Adapter. What should I do?
First, make sure your Bluetooth device is powered on. Second, make sure that your
Bluetooth device is in pairing mode. Third, make sure to put in the same Security Code on
both devices.
I am not receiving 3Mbps data rate through the adapter. What should I do?
In order to get the full data rate, your Bluetooth device must support Bluetooth v2.0 with
Enhanced Data Rate (EDR)
If you still encounter problems or have any questions regarding the TBW-105UB, please refer to
the User's Guide included on the Utility & Driver CD-ROM or contact TRENDnet's Technical
Support Department.
6
Troubleshooting
Certifications
This equipment has been tested and found to comply with FCC and CE Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received. Including interference that may
cause undesired operation.
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV
INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS
EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO
OPERATE THE EQUIPMENT.
Waste electrical and electronic products must not
be disposed of with household waste. Please
recycle where facilities exist. Check with you Local
Authority or Retailer for recycling advice.
ADVERTENCIA
En todos nuestros equipos se mencionan claramente las caracteristicas del adaptador de
alimentacón necesario para su funcionamiento. El uso de un adaptador distinto al
mencionado puede producir daños fisicos y/o daños al equipo conectado. El adaptador
de alimentación debe operar con voltaje y frecuencia de la energia electrica domiciliaria
existente en el pais o zona de instalación.
Copyright ©2006. All Rights Reserved. TRENDnet.
Product Warranty Registration
Please take a moment to register your product online.
Go to TRENDnet’s website at http://www.trendnet.com
TRENDnet Technical Support
US Canada
24/7 Tech Support
Toll Free Telephone: 1(866) 845-3673
Europe (Germany France Italy Spain Switzerland UK)
English/Espanol - 24/7
Francais/Deutsch - 11am-8pm, Monday - Friday MET
English/Espanol - 24/7
Francais/Deutsch - 11am-8pm, Monday - Friday MET
Worldwide
Telephone: +(31) (0) 20 504 05 35
Toll Free Telephone: +00800 60 76 76 67
.
. . . . .
20675 Manhattan Place
Torrance, CA 90501
USA
