TRENDnet TEW-401PC User manual

English

TEW-401PC & TEW-403PI

11g Wireless LAN Adapter

Quick Installation Guide

Version 1.0

No part of this publication may be reproduced, stored in a retrieval system, or

transmitted in any from or by any means, whether electronic, mechanical,

photocopying, recording, or otherwise without the prior writing of the publisher.

WLAN Adapter Quick installation Guide

Note: Do not insert the WLAN Adapter in your

computer until you have finished installing the

Utility and Driver.

Utility and Driver Installation

1. Turn “On” your computer. Insert the driver CD for the WLAN Card .The screen

shown below will appear.

2. Click “Driver Installation”

* Note: If the screen does not appear, you probably have the CD autoplay

function disable. Please run the autorun.exe from the CD-ROM.

3. Click on the model name of your WLAN card to install the driver.

4. Click “Next” and then follow the instructions on the screen to continue the

installation.

5. If Windows prompts “… the device has not pass Windows logo testing…” or

“…digital signature not found…”, click “Continue Anyway”.

6. Click the Finish button in this screen; both the driver and the Configuration Utility

are installed on your computer.

7. Shut down the computer.

Hardware Installation

For Card Bus or PCI WLAN cards, simply insert the card into the computer’s

PCMCIA or PCI slot after running the setup file, and then restart the computer.

After the computer boots back up, it will detect the wireless card and then start the

New Hardware Found wizard. Respond to the prompts displayed by the wizard, select

to allow Windows to install the driver, the operating system will find and load the

driver automatically.

If Windows prompts “… the device has not pass Windows logo testing…” or

“…digital signature not found…”, click “Continue Anyway”.

After the installation, find the configuration icon in the “task bar” on the lower right

hand corner of the desktop. Launch the configuration by left clicking the

Configuration Utility icon and selecting Advanced Configuration. (double-click the

icon for Win XP).

If the Configuration Utility icon is not displayed in the System Tray, you can restart

the Configuration Utility from the Start Menu by selecting “Start”, “Programs”,

“Wireless Network”, and then “Wireless Utility”.

The Configuration Utility consists of window with four tabs: Link Information,

Available Network, Profile Setting, and About. Please find information about these

tabs in the User Guide (from the CD Autorun menu, select User’s Guide and then

select the product).

Wireless Network Setup

1. Peer-to-Peer: Connects with other wireless client(s). This does not require

Access Point. Please make sure the “Network Name” (SSID or ESSID) and

“Peer-to-Peer” channel are the same for all clients in the same wireless

network. Double click on the Configuration Utility icon to open the utility.

- Click on “Profile Setting” tab and “Add” to create a new profile.

- Enter a name that the profile correspond, click “Next”.

- Enter the Network Name (SSID), at “Network Type”, click on the

drop-down arrow and select “Peer-to-Peer” (ad-hoc), and then at “Peer-to-Peer

Channel”, use the up/down arrows to select the channel number, and then click

“Next”.

- To enable Encryption, select “64 bits” or “128bits”, select “Open System”

or Shared Key” Authentication Mode, click “Next”, select “Input Method”

Alphanumeric: 5 characters for 64-bit and 13 characters for 128-bit.

Hexadecimal: 10 characters for 64-bit and 26 characters for 128-bit. The

characters needs to be 0 ~ 9 and A ~ F.

Passphrase: Type in an easy to remember phrase and the program will

generate the keys for you. The same phrase will generate the same keys.

Key Index: You can store up to 4 keys and then choose which key to use on

certain day. For example: use Key 1 for Monday and Key 2 for Tuesday.)

Click “Next”.

- On IP Setting select “Enable” or “Disable”. Click “Complete” to finish the

configuration.

Note: If selecting “Enable” and completed the IP address settings, the

Wireless Utility stores these settings for this specific profile. The next time you

connect to this wireless network with this profile, the Utility restores the IP

settings automatically to your adapter’s TCP/IP properties.

2. Access Point: Connects to wired Ethernet network via Access Point.

- Click “Available Networks” tab.

- Select the listed Wireless Network to Join.

- Click “Connect” to join the network.

* Note: If the Access Point is “WEP KEY” protected, please create a Profile

to connect to this Access Point.

Technical Support

You can find the most recent software and user documentation on the

TRENDware website. TRENDware provides free technical support for all

customers for the duration of the warranty period on this product.

TRENDware Technical Support

Tel: +1-310-891-1100

Fax: +1-310-891-1111

E-mail: suppo[email protected]

www.trendware.com

Support Hours: 7:30AM ~ 6:00PM,

Mon. ~ Fri. (except holidays)

Deutsch

TEW-401PC & TEW-403PI

11g Wireless LAN Adapter

Kurzinstallationsanleitung

Version 1.0

Ohne die Genehmigung des Herausgebers darf diese Publikation nicht, auch nicht

teilweise, vervielfältigt, veräußert oder an Dritte weitergegeben werden, sei es nun

elektronisch, mechanisch, durch Fotokopie oder Aufnahme oder in jeglicher anderen

Weise.

Kurzinstallationsanleitung WLAN-Adapter

Hinweis: Stecken Sie den WLAN-

Adapter nicht

ein, bevor Sie die Installation der

Anwendungssoftware und Treiber nicht

beendet haben.

Installation der Anwendungssoftware und Treiber

1. Schalten Sie den Computer ein. Legen Sie die Treiber-CD für den WLAN-Adapter

ein. Folgende Abbildung erscheint auf Ihrem Monitor.

2. Klicken Sie auf “Konfigurationsanwendungen installieren“ (Install Config

Utilities).

* Hinweis: Wenn diese Anzeige nicht erscheint, ist die Funktion CD-Autoplay

vielleicht deaktiviert. In diesem Fall geben Sie “autorun.exe“ im DOS-Modus

ein.

3. Klicken Sie auf den Typ von Adapter den Sie gerne installieren möchten.
