Q: What is the purpose of using TPE-101I?

A:TPE-101I can supply power and data together from the existing network to a Power over Ethernet

(IEEE 802.3af standard) enabled device.

TPE-101I F.A.Q.

Q: How much power does TPE-101I supply?

A:

Q: Can a TPE-101I work alone without a PoE splitter?

A:

Q: What PoE devices are compatible with the TPE-101I?

A:

Q: What PoE devices are compatible with the TPE-101I?

A:

Q: What TRENDnet products are compatible with the TPE-101I?

A:

Q: Why would I need the TPE-101I?

A:

TPE-101I supplies 48V power and any PoE devices that use the IEEE 802.3af standard should be

compatible.

Yes, it can work alone but it has to work with compatible PoE devices.

Since the TPE-101I uses the IEEE 802.3af standard, any PoE device that uses the IEEE 802.3af

standard will work.

Since the TPE-101I uses the IEEE 802.3af standard, any PoE device that uses the IEEE 802.3af

standard will work.

The TEW-453APB

You would need the TPE-101I when a PoE device, such as an access point, has no access to

power cabling. Using theTPE-101I will allow any PoE device to be placed anywhere, independent

from power outlets, extensions cords, or other power cabling because the TPE-101I will supply the

PoE device with power and data through a CAT 5e networking cable.

Q: How can the TPE-101I be applied to home or business solutions?

A:

Q: Why is the POWER GOOD LED off on the TPE-101I?

A:

Q: I connected my non-POE device into the TPE-102S, but my switch does not

recognize the device.

A:

Below are a couple of scenarios that make the TPE-101I an ideal solution.

a. When you want to network two buildings wirelessly, you would place a PoE Access Point in a

location, such as a roof, to communicate with the other building’s PoE Access Point, and use

the TPE-101I to deliver power and data to these PoE Access Points.

b. When a user decides to use a PoE IP Camera as security camera, the TPE-101I will supply

your IP Camera with power and data through a CAT 5e networking cable.

c. When you want to place a PoE IP Camera or PoE Access Point in an office where power

outlets are unavailable, the TPE-101I can inject power and data through a CAT 5e networking

cable to these devices.

Make sure that the POE splitter or POE device is connected properly to the TPE-101I.

Power cycle the non-POE device by either pulling out the power adapter connector from the POE

injector or disconnecting the CAT 5 cable from the “POE OUT” port. Reinsert the connection after

5-10 seconds have elapsed.

TPE-101I F.A.Q.
