Topfield TF-T5000HD PVR User manual

TF-T5000HD PVR

User Manual

High Deﬁnition

Digital Terrestrial Receiver

Personal Video Recorder

Default PIN: 2010

Full Guide is available at http://www.i-topfield.com

Precautions

• Clean with a dry cloth only.

• Do not block any of the ventilation openings.

• When placed in a cabinet, make sure there is a minimum

space of 10 centimetres around it.

• Do not install near any heat sources or in direct sunlight as

this will impair cooling.

• Do not operate this product near water.

• Do not try to change the plug or defeat its safety purpose.

• This product is designed for indoor use only.

• Place the digital receiver on a ﬁrm and level surface.

• Do not lay any objects such as magazines on this unit.

• Do not overload power outlets. Doing so may result in a risk

of ﬁre or electrical shock.

• Never open this unit’s casing under any circumstances, or the

warranty will be void.

• Unplug this unit during lightning storms or when unused for

long periods of time.

• Refer all servicing to qualiﬁed service personnel. Reverse en-

gineering or disassembly is prohibited.

• Batteries, including those which contain no heavy metals,

may not be disposed with other household wastes. Please dis-

pose of used batteries in an environmentally sound manner.

Find out the legal regulations which apply in your area.

• The mains plug shall remain readily operable so that it can be

removed easily to disconnect the power.

• Operate the digital receiver at temperatures between 0 to

45 ◦C.

• Check the mains voltage before plugging the digital receiver

to the wall socket. For the power speciﬁcation, refer to the

table below.

Input voltage 100 to 240 V AC, 50/60 Hz

Power consumption 24 W at maximum in active

• This receiver does not support passive standby mode, since it

is a Complex set top box that features Ethernet.

Front Panel

Rear Panel

HDMI USBLANS/PDIF DC IN

IN - ANT - OUT VIDEOR - AUDIO - L

PrYPb

ANT IN Terrestrial broadcasting signal input socket

(5V, Max.100mA)

ANT OUT Terrestrial broadcasting signal output socket through the ANT IN socket

for another digital receiver

Y/Pb/Pr Component video output socket for the television set (green/blue/red)

AUDIO L/R Stereo audio output socket for the television set or the audio-video re-

ceiver

(white/red)

VIDEO Composite video output socket for the television set (yellow)

S/PDIF Digital audio output socket for the audio-video receiver

HDMI Audio and video output socket for the high deﬁnition television set

LAN Local area network port

USB port for ﬁrmware update/data transfer

(USB 2.0 Host, 5V DC, 500mA Max.)

DC IN Power jack

Remote Control

NOTE

The actual images and the number of buttons could be diﬀerent depending on the type of

remote control provided by the manufacturer.

• button switches the digital receiver between standby mode and active mode.

• mutes the sound. Press again to switch it back on.

• changes video resolution.

• changes aspect ratio.

• not used in this model.

• switches over between television services and radio services.

• Numeric buttons are used to enter a service number for service change or to specify

values for menu options.

• switches over between the current service and the previously viewed one.

• displays the service information box. Also, displays more information about a

programme.

• has diﬀerent functions per menu.

• selects subtitle track.

• displays teletext.

• selects audio track or sound mode.

• displays the favourite lists.

• displays the electronic programme guide.

• , buttons switch to the previous or next service. Also, navigate in menus and

interactive screens

• displays the services list. Also, selects menu items.

• , buttons decrease or increase the volume. Also, change values for menu options.

• displays the main menu. Also, returns to the previous menu from a submenu.

• exits a menu or hides on-screen information.

•







V−,







V+buttons decrease or increase the volume.

• sets a sleep timer in 10 minute increments.

• displays the list of recorded programmes that are stored in the internal hard

drive.

•







P−,







P+buttons switch to the previous or next service.

• has diﬀerent functions per menu.

• makes a bookmark on playback or time-shift.

• jumps to next bookmark position.

• not used in this model.

• starts recording.

• stops playback, recording, or jumps back to live television from time-shifted tele-

vision.

• has multi purpose functions.

• not used in this model.

• starts reverse playback. Subsequent presses increase the rewind speed.

• pauses live television or playback of a recorded programme.

• resumes normal playback speed, or displays the progress bar for navigation on

playback or time-shift.

• starts fast forward playback. Subsequent presses increase the playback speed.

• jumps back to the beginning of the recording during playback.

• starts slow motion playback. Subsequent presses change the playback speed.

• has diﬀerent functions per menu.

• jumps to the end of the recording during playback.

Functions of the colour buttons will be guided on the screen.

Connecting the TV

Connect any components before plugging the power cord into the wall outlet. If you

encounter any problems setting up your product, please contact your local retailer.

1 Connect the antenna cable to the ANT IN socket.

2 Choose a setup that matches the connection ports on your TV.

– We recommend using the HDMI connection for the highest quality HD picture.

– For a higher quality use the component connection.

– For a basic connection to your television use the composite connection.

a) HDMI connection (HDMI)

b) Component connection (YPbPr)

c) Composite connection (VIDEO)

First Time Installation

1 After having connected the appropriate cables from the digital receiver to your TV, make

sure the power cord of the digital receiver is plugged into a wall socket.

2 Check that your TV set is turned on.

3 Check that your TV set is on the correct video channel so that you can see the Menu from

the Digital Receiver.

4 Insert the batteries into the remote control.

5 Press the button on the remote control to turn the Digital Receiver on.

6 The language menu will appear on your

screen.

Select the language and press 







OK but-

ton.

7 Set the Search Mode to Auto then move

down to Start Search and press 







OK but-

ton.

8 Once all the channels have been

searched you will be told how many

channels have been found.

Press 







OK button and then 







EXIT button.

Setting up your Time

1 Press the 







MENU button, and then go to

Settings, press OK.

2 Press OK on top of Time.

3 Make sure the Mode is set to Auto. Use

left or Right keys beside OK button.

4 Now head down to Time oﬀset and ad-

just it to the following depending on

which state you reside.

• NSW, TAS, VIC: Time oﬀset = 10:00

• SA, NT: Time oﬀset = 09:30

• QLD: Time oﬀset = 10:00

• WA: Time oﬀset = 08:00

NOTE

With daylight saving you will need to add 1 hour to the above settings, or turn ’Daylight

Saving Time’ to On.

Network settings

You need to set up a network connection to enjoy web-enabled features on this unit.

Connect your Ethernet cable from your router to the digital receiver.

1 Press 







MENU >Installation >Network

Setting >IP Setting.

2 It is recommended to use a dynamic IP

address by the router therefore select

DHCP as the connection type. How-

ever if a static connection is set then

please refer to your router for an IP ad-

dress, Subnet Mask, Gateway, Primary

DNS, Secondary DNS.

3 Go to activate proﬁle and press 







OK on

the remote.

Watching TV

TV services list

1 Now that the service search is com-

plete, press the 







OK button to view the

services list.

2 On the services list, press the or

button to navigate your desired

service.

You can also switch to your desired

service by entering its service number

with the numeric buttons.

3 To select a service to watch, press the









OK button.
