Texas Instruments TPS652353 User manual

SLVUAZ0–November 2016

Evaluation Module for the TPS65235-1 LNB Voltage Regulator With I2C

Interface for DiSEqC2.x Application

User's Guide

SLVUAZ0–November 2016

Evaluation Module for the TPS65235-1 LNB Voltage

Regulator With I2C Interface for DiSEqC2.x Application

This document presents the information required to operate the TPS65235-1 for DiSEqC2.x application as

well as the support documentation including schematic, layout, hardware setup, software application, key

waveforms, and bill of materials.

Contents

1 Introduction ................................................................................................................... 2

2 Schematic..................................................................................................................... 3

3 Board Layout ................................................................................................................. 4

4 Bench Test Setup Conditions .............................................................................................. 6

4.1 Headers Description and Jumper Placement ................................................................... 6

4.2 Hardware Requirement ............................................................................................ 8

4.3 Hardware Setup..................................................................................................... 8

5 Software Installation......................................................................................................... 9

6 Software Operation.......................................................................................................... 9

6.1 Register Map Page................................................................................................ 10

6.2 Basic Settings...................................................................................................... 11

7 Test Procedure Example.................................................................................................. 12

7.1 Voltage output check ............................................................................................. 12

7.2 Tone Output ....................................................................................................... 12

8 Bill of Materials ............................................................................................................. 14

List of Tables

1 Input and Output Connection............................................................................................... 7

2 Jumpers and Switches...................................................................................................... 7

3 VLNB Output Control Without I2C Interface Connection................................................................ 7

4 I2C Address Selection...................................................................................................... 11

5 Bill of Materials ............................................................................................................. 14

Trademarks

Microsoft, Windows, Internet Explorer are registered trademarks of Microsoft Corporation.

VERISIGN is a registered trademark of VeriSign Incorporated.

All other trademarks are the property of their respective owners.

Introduction

www.ti.com

2SLVUAZ0–November 2016

Submit Documentation Feedback

Evaluation Module for the TPS65235-1 LNB Voltage Regulator With I2C

Interface for DiSEqC2.x Application

1 Introduction

The TPS65235-1 device is designed to provide 13-V and 18-V output voltage for satellite receiver, with an

operational range of 4.5 V to 16 V.

TPS65235-1 features I2C controlled output voltage from 11 V to 20 V with 16 options; output current limit

with ±10% accuracy is set by ISET pin connecting different resistors. The maximum output current limit is

up to 1 A.

TPS65235-1 can also run without I2C. In non-I2C mode, the SCL pin and VCTRL pin are used to control

13-V and 18-V output. These two pins can be controlled by GPIO from a processor. A dedicated enable

pin EN, is available to turn the LNB output on and off.

The evaluation module is designed to provide access to the features of the TPS65235-1 for DiSEqC2.x

application. While PWR747 is designed for DiSEqC1.x application, some modifications can be made to

this module to test performance at different input and output voltages, current, and switching frequency.

Contact TI Field Applications Group for advice on these matters.

GND

V3V

100k

VIN

GND

10k

GND

40V

3A D1

2 3

10μH

220uH

15.0

100μF

DNP

0.01μF

0.022μF

C12

1 Fμ

0.1μF

C13

DNP

100k

10k

100k

EXTM

VCTRL

LX 1

VIN

VCC

AGND 4

TCAP

ISET

FAULT 8

ADDR

VCTRL

SDA

11 SCL

EXTM

DOUT

DIN

VLNB 16

VCP 17

BOOST 18

GDR 19

PGND 20

EP 21

TPS65235-1RUKR

0.01μF

C14

1 2

3 4

5 6

TP6

TP8

1 2

3 4

5 6

7 8

9 10

0.022μF

1 Fμ

110k

1 Fμ

TP3

GND

28V

DNP

VCC

SCL

SDA 100k

33.0k

VCC

GND

BOOST

VCC

VCTRL

0.1μF

C10

GND

40V 2A

0.1μF

C11

40V2A

DNP

GND

VOUT

FAULT VCC

VOUT

VCC

GND

EXTM

SCL

SDA

ADDR

DIN

DOUT

VIN

VCC

ISET

TCAP

TP1

VCP

VLNB

GDR J1

ADDR

GND GND

TP5

TP7

22μF

10k

GND

TP2

22μF

TP4

GND

10μF

4.5V to 16V, 6A

11V to 20V, 1A

www.ti.com

Schematic

SLVUAZ0–November 2016

Evaluation Module for the TPS65235-1 LNB Voltage Regulator With I2C

Interface for DiSEqC2.x Application

2 Schematic

Figure 1 illustrates the EVM schematic.

Figure 1. TPS65235-1 EVM Schematic for DiSEqC 2.x Application

Board Layout

www.ti.com

4SLVUAZ0–November 2016

Submit Documentation Feedback

Evaluation Module for the TPS65235-1 LNB Voltage Regulator With I2C

Interface for DiSEqC2.x Application

In the TPS65235-1 application, the recommended ceramic capacitors rated are at least X7R and X5R, 35-

V rating and 1206 size for achieving lower LNB output ripple. For this EVM, two 22-μF, 35-V capacitors,

C8 and C9, are put at the output of the boost converter. If lower cost is demanded, a 100-μF electrolytic

(low ESR) and a 10-μF and 35-V ceramic capacitor also works well.

3 Board Layout

Figure 2 shows the component placement on the EVM. Figure 3 and Figure 4 illustrate the top and bottom

layers, respectively.

Figure 2. Component Placement (Top Layer)

www.ti.com

Board Layout

SLVUAZ0–November 2016

Evaluation Module for the TPS65235-1 LNB Voltage Regulator With I2C

Interface for DiSEqC2.x Application

Figure 3. Board Layout (Top Layer)

Figure 4. Board Layout (Bottom Layer)

VIN

Test Point A J7

EN Control

ADDR Control

VOUT

EXTM Control

SCL/I2C Power

I2C Interface to PC

VCTRL Control

Bench Test Setup Conditions

www.ti.com

6SLVUAZ0–November 2016

Submit Documentation Feedback

Evaluation Module for the TPS65235-1 LNB Voltage Regulator With I2C

Interface for DiSEqC2.x Application

4 Bench Test Setup Conditions

4.1 Headers Description and Jumper Placement

Figure 5 shows the header descriptions and jumper placement.

Figure 5. Headers Description and Jumper Placement

Test points:

A: LX for Boost

Notes:

• At non-I2C mode, P1 should be floating, J5 and J3 are used to set the output, refer to Table 3.

• At I2C mode, P1 is connected to the PC through the USB-TO-GPIO box, which makes the SCL signal

to be high. J5 can be used to set the default output when powered on, refer to Table 3.

• P1 and J3 cannot be connected at the same time.

Table 1 lists the I/O connections and Table 2 lists the EVM jumpers and switches.

www.ti.com

Bench Test Setup Conditions

SLVUAZ0–November 2016

Evaluation Module for the TPS65235-1 LNB Voltage Regulator With I2C

Interface for DiSEqC2.x Application

Table 1. Input and Output Connection

# Function Description

J1 VOUT Connector VLNB output

J2 Vin Connector Apply power supply through this connector

Table 2. Jumpers and Switches

# Function Placement Comment

Output voltage control (SCL)

If the IC is not controlled by I2C, VCTRL pin and SCL pin

are combined to control the VLNB output voltage. Refer

to Table 3.

Jumper J3-2 and J3-1 makes SCL to VCC connection

and gives VLNB with output 14.6 V or 19.4 V.

Jumper J3-2 and J3-3 makes SCL to GND connection

and gives VLNB with output 13.4 V or 18.2 V.

I2C Power

If the IC is controlled by I2C, this is used to provide the

I2C power which is connected to the SCL and SDA

through pull-up resistors.

Leaving non jumper connected sets the power to be 3.3

V from the I2C interface adapter.

Shorting the J3-1 and J3-2 by jumper sets the power to

be VCC.

On board VCC is 6.3 V

J4 Tone control (EXTM)

Toggle the EXTM signal (J4-2 to J4-3 and then J4-2 to

J4-1), the internal tone signal is superimposed at the

VLNB output VOUT.

EXTM to GND (J4-2 to J4-3), no internal tone signal is

superimposed at the VOUT.

J5 Output voltage control (VCTRL)

If the IC is not controlled by I2C, VCTRL pin and SCL pin

are combined to control the VLNB output voltage. Refer

to Table 3.

Jumper J5-2 and J5-1 makes VCTRL to VCC connection

and gives VLNB with output 18.2 V or 19.4 V.

Jumper J5-2 and J5-3 makes VCTRL to VCC connection

and gives VLNB with output 13.4 V or 14.6 V.

J6 I2C address set (ADDR)

This pin is the I2C address set pin: tie to VCC sets I2C

address with 0x08H; floating sets I2C address with

0x09H; tie to GND sets I2C address with 0x10H; Resistor

divider R9A and R9B make ADDR pin at the voltage to

set the I2C address with 0x11H. Refer to Table 4.

With 3 V-> VCC- 0.8 V will

set the I2C address 0x11H

J7 VLNB output enable (EN)

Jumper EN to GND disables the VLNB output (short J7-2

to J7-3).

Jumper EN to Vin through a 100-kΩresistor enables the

VLNB output (short J7-2 to J7-1).

Leaving J7 open also enables VLNB output.

Table 3. VLNB Output Control Without I2C Interface

Connection

EN SCL VCRTL VLNB

H H H 19.4 V

H H L 14.6 V

H L H 18.2 V

H L L 13.4 V

L X X 0 V

Host

Computer

USB Cable

USB

Interface

Adapter

Green LED

Indicates

Power

10-Pin

Ribbon

Cable

EVM Board

Bench Test Setup Conditions

www.ti.com

8SLVUAZ0–November 2016

Submit Documentation Feedback

Evaluation Module for the TPS65235-1 LNB Voltage Regulator With I2C

Interface for DiSEqC2.x Application

4.2 Hardware Requirement

This EVM requires an external power supply capable of providing 4.5 V to 16 V at 4 A.

The EVM kit includes USB-TO-GPIO interface box which, when installed on a PC and connected to the

EVM, allows the user to communicate with the EVM through a GUI interface. (The EVM and USB-TO-

GPIO interface box must be ordered separately.) The minimum PC requirements are:

• Microsoft®Windows®2000, Windows XP or Windows 7 operating system

• USB port

• Minimum of 30 MB of free hard disk space (100 MB recommended)

• Minimum of 256 MB of RAM

4.3 Hardware Setup

After connecting the power supply to J2, floating J7, connect J3, J4, and J5 to GND, J6 and P1 floating,

turning on the power supply, the EVM will regulate the output voltages to 13.4 V without tone

superimposed.

Perform the following steps to change the output voltage by sending the digital control signal through a PC

running the TPS65235-1 Controller software and USB-TO-GPIO interface box:

• Connect one end of the USB-TO-GPIO box to the PC using the USB cable and the other end to P1 of

the TPS65235-1 using the supplied 10-pin ribbon cable per Figure 6. The connectors on the ribbon

cable are keyed to prevent incorrect installation.

• Floating J3.

• Connect the power supply on J2, and turn on the power supply.

• Run the software as explained in Section 5.

Figure 6. USB Interface Adapter Quick Connection Diagram

Basic Information

About TPS65235-1

Status for USB

Adapter Connection

Main Control Panel

www.ti.com

Software Installation

SLVUAZ0–November 2016

Evaluation Module for the TPS65235-1 LNB Voltage Regulator With I2C

Interface for DiSEqC2.x Application

5 Software Installation

If installing from the TI Web site, visit SLVC651.

NOTE: This installation page is best viewed with Microsoft Internet Explorer®browser (it may not

work correctly with other browsers).

1. Click on the install button; the PC should display a security warning and ask if you want to install this

application. Select Install to proceed.

2. To run the software after installation, either use the desktop icon, which is created by the installer if the

user agrees to creating a desktop icon, or go to Start →All programs →Texas Instruments →

TPS65235-1.

At start-up, the software first checks the firmware version of the USB-to-GPIO adapter box. If an incorrect

firmware version is installed, the software automatically searches the Internet (if connected) for updates. If

a new update is available, the software notifies the user of the update then downloads and installs the

software. Note that after the firmware is updated, the user must disconnect and then reconnect the USB

cable between the adapter and PC, as instructed during the install process. The host PC software also

automatically searches on the Internet (if connected) for updates. If a new update is available, the

software notifies the user of the update and downloads and installs it. During future use of the software,

you are prompted to install a new version if one becomes available on the Web.

NOTE: VERISIGN®Code Signing is used to prevent any malicious code from changing this

application. If at any time in the future the binaries are modified, the code will no longer

attempt to run.

6 Software Operation

This section provides descriptions of the EVM software.

The supplied software is used to communicate with the TPS65235-1EVM. Click on the icon on the host

computer to start the software. The software first displays the home page for the user interface. Two

entrances are available for the expert user or beginner.

Figure 7. Home Page for GUI Interface

Software Operation

www.ti.com

10 SLVUAZ0–November 2016

Submit Documentation Feedback

Evaluation Module for the TPS65235-1 LNB Voltage Regulator With I2C

Interface for DiSEqC2.x Application

By clicking on the Bbutton, the Basic information about TPS65235-1 page comes up which lists the

features and application information for TPS65235-1. Follow the steps to do the basic check for the EVM.

The GUI will guide the beginner to setup the EVM and GUI.

6.1 Register Map Page

By clicking the Ebutton, the Register Map interface comes out. See Figure 8.

Figure 8. Register Map Page for GUI

Single click on a register name to show FIELD VIEW. This shows the detail setting of each bit.

Double click on the bit to change the bit to 0 or 1.

Single click the ?for the register name to show the detail description page for the register.

For Write Registers option, when the Immediate option is selected, any change is sent to the EVM

immediately; otherwise, Write Registers button for each register must be clicked to send the control signal.

Registers or set the Auto Read option.

The Status for USB Adapter Connection, only shows the status for the adapter, not the EVM board. The

user can select the Write Registers on Register Map page to check whether the board communication is

ok or not.

This manual suits for next models

Table of contents

Other Texas Instruments Motherboard manuals

Texas Instruments

Texas Instruments DAC82002EVM User manual

Texas Instruments

Texas Instruments UCC27332Q1EVM User manual

Texas Instruments

Texas Instruments DDC264EVM User manual

Texas Instruments

Texas Instruments UCD90240EVM-704 User manual

Texas Instruments

Texas Instruments TLV3607 User manual

Texas Instruments

Texas Instruments DRV2700EVM-HV500 User manual

Texas Instruments

Texas Instruments THS6222RHFEVM User manual

Texas Instruments

Texas Instruments DAC5668EVM User manual

Texas Instruments

Texas Instruments DLP LightCrafter 6500 User manual

Texas Instruments

Texas Instruments BQ25172EVM User manual

Texas Instruments

Texas Instruments LMK00101BEVAL/NOPB User manual

Texas Instruments

Texas Instruments INA228 EVM User manual

Texas Instruments

Texas Instruments TRF3703 User manual

Texas Instruments

Texas Instruments ADC08060 User manual

Texas Instruments

Texas Instruments TPS54231 User manual

Texas Instruments

Texas Instruments TPS25944XEVM-635 User manual

Texas Instruments

Texas Instruments TUSS44 0 Series User manual

Texas Instruments

Texas Instruments 66AK2Gx User manual

Texas Instruments

Texas Instruments INA2191EVM User manual

Texas Instruments

Texas Instruments DRV8847 Series User manual

Texas Instruments

Texas Instruments TAS5110D6REF User manual

Texas Instruments

Texas Instruments AMC131M03EVM User manual

Texas Instruments

Texas Instruments DAC31 1EVM Series User manual

Texas Instruments

Texas Instruments AN-1975 LMP8640 User manual

Popular Motherboard manuals by other brands

DFI

DFI SD170 user manual

ASROCK

ASROCK ROMED8-2T user manual

Asus

Asus P2L97A user manual

Winmate

Winmate IC70 user manual

Asus

Asus MES-B user manual

Grantech

Grantech SYS8F377VGGA-3OMN user manual

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR user guide

Gigabyte

Gigabyte GA-9IVDT user manual

Commell

Commell MS-C73 user manual

IBT Technologies

IBT Technologies MB860 user manual

Nvidia

Nvidia TEGRA DG-04927-001_V01 user guide

Biostar

Biostar M7VIT Bravo Description

Intel

Intel D33217CK specification

Asus

Asus F1A55-M LX PLUS R2.0 user manual

EPC

EPC EPC9147C quick start guide

Asus

Asus EX-B760M-V5 D4 quick start guide

EPOX

EPOX MU-8KHA0010 user manual

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 user guide
