Getting Started
The EVM ships with a Power On Self Test (POST)
flashed into I2C EEPROM. The POST automati-
cally executes when the board is powered ON.
POST performs memory test and internal EMAC
loopback test. At power ON, the user LEDs are
OFF by default. The LEDs blink and turn OFF to
indicate successful DSP booting.
After booting, User LED-1 turns ON to indicate
successful RAM test and User LED-2 turns ON to
indicate successful internal EMAC loop-back
test. These LEDs remain ON to indicate success
of both the tests.
Please refer to the EVM User Guide for software
installation and other details.
Important Notes when handling the
EVM
•Plug in all the cables before powering ON the
EVM to ensure proper grounding.
•Do not unnecessarily flex the boards, while
inserting cables. Excessive flexing can break
the PCB traces.
•Use proper ESD procedures when handling the
EVM.
•Warning: Some components on the EVM may
be too hot to touch with your bare hand when
power is on.
Online Documentation
•TMS320C6670 processor website
http://focus.ti.com/docs/prod/folders/print/tm
s320c6678.html
•MCSDK website for updates
http://focus.ti.com/docs/toolsw/folders/print/
bioslinuxmcsdk.html
•CCS v5
http://processors.wiki.ti.com/index.php/Categ
ory:Code_Composer _Stu dio_v5
C6670 EVM Information:
http://www.advantech.com/Support/TI-
EVM/default.aspx
This link contains
•Hardware & Software details
•User Guide
•Technical Reference Manual
•TMS320C6670 Datasheet
C6670 EVM Support:
Please write to
technical queries related to this EVM.
